Data-center-optimized, high-performance 1GbE switches
Optimized for high-performance data center environments, Dell Networking S-Series 1GbE switches: - Deliver low latency, superb performance and high density with hardware and software redundancy
- Offer Active Fabric designs using S- or Z-Series core switches to create a two-tier, 1/10/40 GbE data center network architecture
- Provide ideal solutions for ToR applications in enterprise, Web 2.0 and cloud service providers’ data center networks Optimized for the open networking era
Get more agility, more choices and lower costs than proprietary networks with select, open-standards-based ON (open networking) switches. - Disaggregated-hardware/software solutions bring new levels of freedom and flexibility to your data center.
- Support for Open Network Install Environment (ONIE) enables zero-touch installation of alternate network operating systems.
- Your choice of network operating system helps simplify data-center fabric orchestration and automation.
- A broad ecosystem of applications and tools, open-source and Linux-based, provides more options to optimize and manage your network. Built for cost-effective deployment
Select S-Series Managed 1/10GbE switches are supported by the Dell Open Automation Framework, a suite of interrelated network management tools that can be used together or independently to provide a flexible, available and manageable network while helping reduce operational expenses. The Open Automation Framework takes full advantage of Dell Networking Operating System OS9 software capabilities to bring network automation into virtual data center environments. This helps the S-Series switches efficiently respond and adapt to changes in application requirements. Navigate network complexity with Dell Services
Our global team of network experts understands the complexities of IT ecosystems, including multi-vendor environments. We have the skillset and experience to not only quickly resolve performance issues but also transform your network to meet the demands of your business. -
Administrationsfunktioner Switch-type Administreret Switch lag L2/L3 Servicekvalitet support (QoS) Ja Konfigurerer lokationsindstillinger (CLI) Ja Porte & Grænseflader Basis omskiftning RJ-45 Ethernet porte, antal 0 Basis omskiftning RJ-45 Ethernet porttype Ingen Antal SFP modulslots 24 Antal SFP + modulslots 2 Netværk Netværksstandarder IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z 10G understøttelse Ja VLAN understøttelse Ja Vituelle LAN funktioner Tagged VLAN Sikkerhed Understøtter adskillelse PoE+ Multicast funktioner Multicast-understøttelse Ja Design Stativ-montering Ja Formfaktor 1U Produktfarve Sort LED-indikatorer Fejl Strømstyring Vekselstrømsindgangsspænding 100 - 240 V Vekselstrømsindgangsfrekvens 50 - 60 Hz Power over Ethernet (PoE) Strøm over Ethernet (PoE) Ingen Andre funktioner Dell E-Værdi kode DNS3124F Driftsbetingelser Driftstemperatur (T-T) 0 - 45 °C Relativ luftfugtighed ved drift (H-H) 10 - 85% Vægt & størrelser Vægt 6 kg CO2-aftryk Samlet CO2-fodaftryk (kg of CO2e) 3880 Samlet kulstofudledning, standardafvigelse (kg CO2e) 1220 Kulstofudledning, produktion (kg CO2e) 2388 Kulstofudledning, logistik (kg CO2e) 119 Kulstofudledning, energiforbrug (kg CO2e) 1360 Udledning af kulstof i slutningen af levetiden (kg CO2e) 7 Samlet kulstofudledning, uden brugsfase (kg CO2e) 2514 PAIA-version 1.2.8, 2020 Logistik data Harmoniseret systemkode (HS) 85176990
