No-Stud TV Wall Mount | Slim Design with Tilt | For 37" to 80" Displays
This No-Stud TV Wall Mount enables you to easily and securely mount your display from 37" up to 80" to walls without the need to align the bracket with wall studs. Its steel frame supports displays up to 110lb / 50kg in weight and provides the ability to tilt your display to ensure your application and the ideal viewing angle are aligned.
Easy and Flexible Installation
The studless design of this Universal TV Wall Mount makes it easy for you to mount your TV to a drywall or plaster wall in any boardroom, office, or classroom setup. Simply choose the best mounting location and secure the mounting bracket into the wall (with included nails); no need to drill or look for wall studs. The included Automatic Spring Lock lets you conveniently mount and secure your TV in place.
Low Profile Slim Design
This Low Profile TV Wall Mount is perfect for applications like digital signage, where space and aesthetics are important. With a 1.2" profile from the wall, this Wall Mount TV Hanger provides a professional and clean look.
Tilt your Display
The Hanging TV Wall Mount lets you angle your TV towards your audience. The included wall-mounted spacers give you a choice to change the tilting angle (0°/ -5°) for a comfortable viewing experience.
The FPWHANGER is backed by a StarTech.com 5-year warranty and free lifetime technical support.
The StarTech.com Advantage
- LARGE 80" NO-STUD TV WALL MOUNT: Low profile TV wall mount supports VESA compatible displays incl. curved TVs up to 80 inch (110 lb/50 kg) w/ support for many VESA patterns; Ideal for unusual stud placement or anywhere on a wall in between studs
- EASY INSTALLATION: Mount your TV without studs on drywall; The steel frame guides 20 nails into the wall on an angle to increase the load bearing strength; The picture hanger style simplifies the final step of mounting the TV
- SLIM DESIGN: Studless TV wall mount with a minimal profile of only 1.2" (3cm) is provided with large wall-mounted spacers to give you a choice for the tilting angle (0°/-5°)
Montering | |
Maksimal vægtkapacitet | 50 kg |
Maksimal skærmstørrelse kompatibilitet | 2,03 m (80") |
Monteringstype | Væg |
Montering interface kompatibilitet (min.) | 100 x 200 mm |
Montering interface kompatibilitet (maks.) | 600 x 400 mm |
Minimal skærmstørrelse kompatibilitet | 94 cm (37") |
Panel montering grænseflade | 100 x 200,200 x 200,200 x 300,300 x 200,300 x 300,400 x 200,400 x 400,400 x 300,600 x 400 |
Antal understøttede skærme | 1 |
Ergonomisk | |
Hældningsindstilling | Ja |
Hældningsvinkelområde | -5 - 0° |
Afstand til væggen (min.) | 3,1 cm |
Design | |
Produktfarve | Sort |
Husmateriale | Stål |
Tyverisikring | Ingen |
Tekniske detaljer | |
Overholdelse af bæredygtighed | Ja |
Bæredygtighedscertifikater | RoHS |
Emballage indhold | |
Ankre inkluderet | Ja |
Antal ankre inkluderet | 4 |
Spændeskiver inkluderet | Ja |
Antal spændeskiver inkluderet | 12 |
Afstandsstykke medfølger | Ja |
Antal afstandsstykker inkluderet | 18 |
Skruer inkluderet | Ja |
Antal skruer | 24 |
Monteringsbeslag inkluderet | Ja |
Antal monteringsbeslag | 1 |
Vægt & størrelser | |
Bredde | 700 mm |
Dybde (maks.) | 13,3 cm |
Højde | 31 mm |
Vægt | 2,4 kg |
Emballeringsdata | |
Pakkebredde | 769 mm |
Pakkedybde | 200 mm |
Pakkehøjde | 45 mm |
Pakkevægt | 2,6 kg |
Logistik data | |
Hovedkassens bredde (udvendigt) | 785 mm |
Hovedkassens længde (udvendigt) | 415 mm |
Hovedkassen højde (udvendigt) | 210 mm |
Produkter pr. hovedkasse (udvendigt) | 8 stk |
Harmoniseret systemkode (HS) | 85299097 |
