Unrivaled Speed with 5G, Revolutionary Experience
Take advantage of your advanced 5G network with download speeds up to 4.67 Gbps. Share your 5G network with multiple Wi-Fi devices and enjoy uninterrupted Ultra HD movies, blazingly fast file downloads, and smooth video chats and video conferences. At the same time, NX200 is backward compatible with 4G mode.§
Plug and Play, Enjoy 5G Network Everywhere
Simple, just one SIM card
Traditional broadband or cable installation is expensive and time-consuming for your vacation home, farm, or suburban warehouse. Long contract periods also create headaches for short-rentals, pop-up venues, and temporary shops to access the internet. Archer NX200 ensures a comfortable and no-block network installation. Plug in your SIM card and enjoy high-speed internet!
Powerful Wi-Fi 6
Armed with WiFi 6 technology, NX200 is designed to deliver a huge boost in coverage, speed, and total capacity. Get on the latest mesh WiFi to enjoy the future network that loads faster and connects more.△
EasyMesh-Compatible Networking
Mesh networking creates smooth, fast, stable roaming. Eliminate Wi-Fi dead zones, expand your network, and fill your entire home with high-speed Wi-Fi.*
Available WAN Connection
The gigabit WAN/LAN port enables NX200 to work as a traditional wireless router which is compatible with cable, fiber, and DSL modems. And when it's set as a wireless router, its 5G/LTE connection works as a backup to provide a sustained and reliable internet connection for you.
| WAN-forbindelse | |
| Ethernet WAN | Ja |
| SIM-kort slot | Ja |
| 3G/4G kompatibilitet USB-modem | Ingen |
| WAN forbindelsestype | RJ-45 |
| Trådløse LAN funktioner | |
| Wi-Fi-bånd | Dual-band (2,4 GHz / 5 GHz) |
| Bedste Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| WLAN dataoverførselshastighed (maks) | 1201 Mbit/s |
| Wi-Fi-standarder | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN dataoverførselshastighed (første bånd) | 574 Mbit/s |
| WLAN dataoverførselshastighed (anden bånd) | 1201 Mbit/s |
| Modulation | 1024-QAM |
| Netværk | |
| Ethernet LAN | Ja |
| Ethernet LAN-grænsefladetype | Gigabit Ethernet |
| Ethernet LAN-datahastigheder | 10,100,1000 Mbit/s |
| Port udløsning | Ja |
| Dynamisk DNS (DDNS) | Ja |
| Antal gæstenetværk (2,4 GHz) | 1 |
| Antal gæstenetværk (5 GHz) | 1 |
| VPN-support | PPTP VPN, IPSec VPN , OpenVPN |
| Mobilt netværk | |
| Generering af mobilnetværk | 5G |
| 3G standard | DC-HSDPA, HSPA, HSPA+, UMTS |
| 4G standard | LTE-TDD & LTE-FDD |
| Understøttelse af 5G-bånd | 700,800,850,900,1800,2100,2300,2500,2600,3500,3700 MHz |
| Understøttelse af 4G-bånd | 700,800,850,900,1500,1800,2100,2300,2500,2600,3500,3700 MHz |
| Understøttelse af 3G-bånd | 850,900,2100 MHz |
| SIM-korttype | NanoSIM |
| Porte & Grænseflader | |
| Ethernet LAN-porte (RJ-45) | 3 |
| USB-port | Ingen |
| Administrationsfunktioner | |
| Wi-Fi-multimedie (WMM)/(WME) | Ja |
| Servicekvalitet support (QoS) | Ja |
| Knap til nulstilling | Ja |
| WPS trykknap | Ja |
| MU-MIMO-teknologi | Ja |
| Sikkerhed | |
| Sikkerhedsalgoritmer | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Firewall | Ja |
| Firewall sikkerhed | IPv4 SPI Firewall, IPv6 Firewal |
| Adgangskontrolliste (ACL) | Ja |
| DoS angrebsforebyggelse | Ja |
| Forældrekontrol | Ja |
| Understøttelse af DMZ | Ja |
| Protokoller | |
| DHCP-klient | Ja |
| DHCP-server | Ja |
| Understøttede netværksprotokoller | IPv4, IPv6 |
| Design | |
| Produkttype | Bordplade router |
| Produktfarve | Hvid |
| Tænd-/slukkontakt | Ja |
| Godkendelser | |
| Compliance-certifikater | CE, RoHS |
| Emballage indhold | |
| Kabler inkluderet | LAN (RJ-45) |
| AC-adapter inkluderet | Ja |
| Hurtig installationsvejledning | Ja |
| Antenne | |
| Antennedesign | Intern |
| Antenner, antal | 10 |
| Aftagelig (e) antenne (r) | Ja |
| Strømstyring | |
| Strømkilde type | Vekselstrøm |
| Vekselstrømsindgangsspænding | 100 - 240 V |
| Vekselstrømsindgangsfrekvens | 50/60 Hz |
| Udgangsspænding | 12 V |
| Udgangsstrøm | 2 A |
| Driftsbetingelser | |
| Driftstemperatur (T-T) | 0 - 40 °C |
| Opbevaringstemperatur (T-T) | -40 - 70 °C |
| Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
| Relativ luftfugtighed ved opbevaring (H-H) | 5 - 90% |
| Systemkrav | |
| Understøttet browser | Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser |
| Understøttede Windows-operativsystemer | Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
| Understøttede Linux-operativsystemer | Ja |
| Understøttede Mac-operativsystemer | Ja |
| Vægt & størrelser | |
| Bredde | 99 mm |
| Dybde | 99 mm |
| Højde | 190 mm |
