Varenummer: TL-WR840N
Mere information
-
Highlights:
- 300Mbps wireless transmission rate ideal for both bandwidth sensitive tasks and basic work;
- Easy wireless security encryption at a push of WPS button;
- IP based bandwidth control allows administrators to determine how much bandwidth is allotted to each PC;
- WDS wireless bridge provides seamless bridging to expand your wireless network.
What This Product Does
The 300Mbps Wireless N Router TL-WR840N is a combined wired/wireless network connection device designed specifically for small business and home office networking requirements. The TL-WR840N creates an exceptional and advanced wireless performance, making it ideal for streaming HD video, VoIP and online gaming. Also, Wi-Fi Protected Setup (WPS) button on the sleek and fashionable exterior ensures WPA2 encryptions, preventing the network from outside intrusions.
300Mbps Wireless N Speed - Fast Download Speed
TP-LINK’s TL-WR840N is a high speed solution that is compatible with IEEE 802.11b/g/n. Based on 802.11n technology, TL-WR840N gives users wireless performance at up to 300Mbps, which can meet your most demanding home networking needs, such as HD streaming, online gaming and large files downloading.
CCA Technology - Stable Wireless Signals
Clear Channel Assessment (CCA) automatically avoids channel conflicts using its clear channel selection feature and fully realizes the advantages of channel binding, greatly enhancing wireless performance.
IP QoS -- Manage your Bandwidth
Within the wireless network, indiscriminate Internet surfing and bandwidth-guzzling downloads by internal users often leave homes or small offices with insufficient bandwidth. TL-WR840N supports an IP QoS function, allowing optimum utilization of bandwidth and offering bandwidth control over congestion, preventing bandwidth abuse. In this way, users of a small network receive committed and specific bandwidth, preventing non-critical applications from degrading network performance.
Easy To Use
With the TL-WR840N even novice users can setup their networks. The device comes with a CD featuring an Easy Setup Assistant that leads users through the setup process step-by-step, and even helps with wireless network settings and security configurations.
Features:
- Wireless N speed of up to 300Mbps makes it ideal for bandwidth consuming or interruption sensitive applications like video streaming, online gaming and VoIP;
- 2T2R MIMO™ delivers greater throughput at range versus conventional 1T1R;
- Easily setup a WPA encrypted secure connection at a push of the QSS button;
- WDS wireless bridge provides seamless bridging to expand your wireless network;
- QoS function assures the quality of VoIP and multimedia streaming;
- Wi-Fi On/Off Button allows users to simply turn their wireless radio on or off;
- Features parental control function managing the internet access of children or employee's computer;
- Supports virtual server, special application and DMZ host ideal for creating a website within your LAN;
- Offers Auto-mail function for system log, convenient for managing the router;
- Backward compatible with 802.11b/g products;
- Easy Setup Assistant provides quick & hassle free installation;
- Sleek exterior, can be mounted on a wall or placed horizontally on a table or desk. -
WAN-forbindelse Ethernet WAN Ja DSL WAN Ingen SIM-kort slot Ingen 3G/4G kompatibilitet USB-modem Ingen WAN forbindelsestype RJ-45 Trådløse LAN funktioner Wi-Fi-bånd Enkelt band (2,4 GHz) Bedste Wi-Fi standard Wi-Fi 4 (802.11n) WLAN dataoverførselshastighed (maks) 300 Mbit/s Wi-Fi-standarder 802.11b, 802.11g, Wi-Fi 4 (802.11n) Netværk Ethernet LAN Ja Ethernet LAN-grænsefladetype Hurtigt ethernet Ethernet LAN-datahastigheder 10,100 Mbit/s Kabelteknologi 10/100Base-T(X) Netværksstandarder IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u Portvideresendelse Ja Port udløsning Ja Antal gæstenetværk (2,4 GHz) 1 VPN-support PPTP, L2TP, IPSec Modtager, følsomhed 270M: -68dBm@10% PER 130M: -68dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER Porte & Grænseflader Ethernet LAN-porte (RJ-45) 4 USB-port Ingen DC-in-stik Ja Administrationsfunktioner Webbaseret administration Ja Servicekvalitet support (QoS) Ja Knap til nulstilling Ja WPS trykknap Ja Sikkerhed Sikkerhedsalgoritmer WEP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise Firewall Ja Firewall sikkerhed SPI Gæsteadgang Ja Filtrering Ja Filtrering af MAC-adresser Ja URL-filtrering Ja Understøttelse af DMZ Ja Protokoller DHCP-klient Ja DHCP-server Ja Universal Plug and Play (UPnP) Ja Understøttede netværksprotokoller IPv4, IPv6 Design Produkttype Bordplade router Produktfarve Grå, Hvid LED-indikatorer Ja Tænd-/slukkontakt Ja Godkendelser Compliance-certifikater RoHS, Federal Communications Commission (FCC), CE Emballage indhold Kabler inkluderet LAN (RJ-45) AC-adapter inkluderet Ja Hurtig installationsvejledning Ja Antenne Antennedesign Ekstern Niveau for antennestyrke (maks.) 5 dBi Antenner, antal 2 Funktioner Indbygget processer Ja Processorkerner 1 Strømstyring Strømkilde type DC Udgangsspænding 9 V Udgangsstrøm 0,6 A Driftsbetingelser Driftstemperatur (T-T) 0 - 40 °C Opbevaringstemperatur (T-T) -40 - 70 °C Relativ luftfugtighed ved drift (H-H) 10 - 90% Relativ luftfugtighed ved opbevaring (H-H) 5 - 90% Systemkrav Understøttede Windows-operativsystemer Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 Understøttede Linux-operativsystemer Ja Understøttede Mac-operativsystemer Ja Vægt & størrelser Bredde 182 mm Dybde 128 mm Højde 35 mm Emballeringsdata Pakkebredde 265 mm Pakkedybde 180 mm Pakkehøjde 86 mm Pakkevægt 430 g Andre funktioner Understøttede WLAN-dataoverførselshastigheder 11,54,300 Mbit/s Bæredygtighed Overholdelse af bæredygtighed Ja
