Varenummer: TL-SG1008P
Mere information
-
What This Product Does
8-Port Gigabit Desktop Switch with 4-Port PoE provides the seamless network connection. It integrates 1000Mbps Gigabit Ethernet and 10/100Mbps Fast Ethernet network capabilities.
How This Product Works
4 of the 8 Auto-Negotiation RJ45 ports (port-1 to port-4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.
Overload Arrangement
TL-SG1008P has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 53W, a priority will be arranged among the PoE ports, then the system will cut off the power of the lowest-priority port.
Port Priority Function
Priority (port-1>port-2>port-3>port-4): This function will help protect the system if the system power becomes overloaded. For example, Port 1, 2 and 4 are using 15.4w (maximum power per port is 15.4W), the system power is 46.2w in total (PoE max LED is red ). If there is an additional PD inserted to Port 3 with 10w then the system will cut off Port 4 to protect the system, this means Port 1, 2 will use 15.4w, and Port3 will use 10w, and no power will be supplied to Port 4.
Easy To Use
TL-SG1008P is easy to install and use. It requires no configuration and installation. With desktop design, outstanding performance and quality, the TP-LINK TL-SG1008P 8-Port Gigabit Desktop Switch with 4-Port PoE is a great selection for expanding your home or office network. -
Administrationsfunktioner Switch-type Ikke administreret Porte & Grænseflader Basis omskiftning RJ-45 Ethernet porte, antal 8 Basis omskiftning RJ-45 Ethernet porttype Gigabit Ethernet (10/100/1000) Gigabit Ethernet (kobber) porte, antal 8 Fiber optisk strømstik LuxCis Kompatible hukommelseskort MMC Mobile Strømstik DC-in-stik Netværk Netværksstandarder IEEE 802.11j 10G understøttelse Ingen Kobber ethernet kabelteknologi 100BASE-T Understøttede kabeltyper Cat6a Fuld duplex Ja Flowkontrol support Ja Auto MDI/MDI-X Ja Ethernet LAN-datahastigheder 1000 Mbit/s Vituelle LAN funktioner IP subnet–based VLAN VLAN kortlægningstype 2:2 VLAN Mapping Optisk fiber Fiber ethernet kabelteknologi 40GBASE-LR4 Dataoverførsel MAC adresselabel 4800 entries Switch kapacitet 16 Gbit/sek. Opbevar-og-frem Ja Sikkerhed DHCP funktioner DHCPv6 client Sikkerhedsalgoritmer HTTPS Godkendelse Automatisk VLAN Godkendelsestype HWTACACS Algoritmer for køplanlægning SP MAC adresse indtastninger Blackhole MAC adresse indtastninger Protokoller Routing-protokoller IP IPv4 & IPv6 funktioner IPv6 Telnet Design Stativ-montering Ingen Produktfarve Hasselnød Husmateriale Polymer LED-indikatorer Fejl Luftflow retning Luftstrømning bagfra-fremad Strømstyring Strømforsyning inkluderet Ja Antal strømforsyninger 1 DC indgangsspænding 48 V Indgangsstrøm 1.25 A Strømforbrug (typisk) 53 W Power over Ethernet (PoE) Strøm over Ethernet (PoE) Ja Power over Ethernet (PoE) -type understøttet Active PoE Power over Ethernet (PoE) porte, antal 4 Driftsbetingelser Driftstemperatur (T-T) 0 - 40 °C Opbevaringstemperatur (T-T) -40 - 70 °C Relativ luftfugtighed ved drift (H-H) 10 - 90% Relativ luftfugtighed ved opbevaring (H-H) 5 - 90% Vægt & størrelser Bredde 171 mm Dybde 98 mm Højde 27 mm Emballage indhold Kabler inkluderet Vekselstrøm Brugervejledning Ja Emballeringsdata Pakketype Kasse Bæredygtighed Bæredygtighedscertifikater ENERGY STAR Godkendelser Certificering CE, FCC, RoHS Logistik data Harmoniseret systemkode (HS) 85176990
