Varenummer: USW-FLEX-3
Mere information
-
PoE Flexibility
The USW-Flex supports a maximum PoE output budget of 46W when powered by 60W 802.3bt PoE++. Four ports offer auto-sensing 802.3af PoE output to power multiple devices on the network.
Versatile Mounting
The USW-Flex can be installed horizontally or vertically making it ideal for desktop, magnetic wall-mount, and pole-mount installations.
Indoor/Outdoor Design
The USW-Flex is designed for indoor or outdoor use. With its weatherproof housing and versatile mounting options, the USW-Flex provides both flexibility and durability for environments with extreme temperature variations
Compatible Products
The USW-Flex powers a variety of products, including the UniFi Video Camera G3 Flex, UniFi Video Camera G4 Pro, and UniFi AC Mesh AP, which use 802.3af PoE. To enable its maximum power budget of 46W, the USW-Flex can be powered by the USW-Industrial switch, which provides 60W of 802.3bt PoE++.
Seamless Integration
A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts. -
Administrationsfunktioner Switch-type Administreret Switch lag L2 Porte & Grænseflader Basis omskiftning RJ-45 Ethernet porte, antal 5 Basis omskiftning RJ-45 Ethernet porttype Gigabit Ethernet (10/100/1000) Antal installerede SFP moduler 0 Antal installerede SFP+ moduler 0 Netværk Netværksstandarder IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt 10G understøttelse Ingen Fuld duplex Ja Auto MDI/MDI-X Ja VLAN understøttelse Ja Dataoverførsel Jumbo Frames support Ja Design Stativ-montering Ingen Produktfarve Hvid LED-indikatorer Aktivitet, Link, PoE, Status Kode for international beskyttelse (IP) IP55 Kan monteres på væggen Ja Præstation Firmware kan opgraderes Ja Strømstyring Strømforbrug (maks.) 5 W Power over Ethernet (PoE) Strøm over Ethernet (PoE) Ja Power over Ethernet (PoE) porte, antal 4 Power over Ethernet (PoE) spænding 57 V Power over Ethernet (PoE) effekt pr. port 15,4 W Total Power over Ethernet (PoE) 46 W Driftsbetingelser Driftstemperatur (T-T) -40 - 55 °C Relativ luftfugtighed ved drift (H-H) 5 - 95% Vægt & størrelser Bredde 122,5 mm Dybde 107,1 mm Højde 28 mm Vægt 230 g Godkendelser Certificering CE, FCC, IC Logistik data Harmoniseret systemkode (HS) 85176990
