Varenummer: QGD-1602-C3758-16G
Mere information
-
Upgraded performance for smoother virtualization
The QGD-1602 provides a full upgrade of network speeds, performance and memory, which not only greatly enhances the network transmission speeds of edge devices, but also optimizes the capabilities of running multiple virtual machines and containers for highly-efficient virtualization applications.
Sturdy hardware with Intel QAT for optimized performance
The QGD-1602 uses Intel® Atom® C3000 series multi-core 2.2GHz processors, has two SATA drive bays, and provides and two M.2 NVMe SSD slots for SSD caching to increase IOPS performance. Two PCIe Gen3 x2 slots allows users to install 10GbE network cards, QM2 dual-port M.2 SSD/10GbE cards, USB 3.2 Gen 2 (10Gbps) cards, or Wireless Adapters to boost core functionality. The QGD-1602 also supports Intel® QuickAssist Technology (Intel® QAT) to greatly enhance IPsec VPN performance.
The First Switch Series with VM Support
The Guardian supports QNAP’s QTS operating system and is the world’s first switch series that can host virtual machines, containers, and provide other cloud applications - enabling diverse networking and storage solutions. In addition to QuWAN, QVR Pro, HybridMount, and other applications, the included App Center also supports VMs for running many open-source software applications. The Guardian provides SMBs with not only an all-in-one networking solution for IP surveillance, storage expansion, network security, and wireless LAN management, but also a SD-WAN solution for connecting to other QNAP devices at multiple sites. The dual-processor Guardian enables you to independently run the networking management interfaces (QSS - QNAP Switch System) and QTS. The Guardian provides a user-friendly web interface, QuNetSwitch, to help SMBs deploy a flexible and secure IT infrastructure.
Deploy a multi-site VPN with SD-WAN solution
The QGD-1602 and other QNAP solutions now support QuWAN – QNAP’s SD-WAN solution. QuWAN provides full mesh IPsec VPN topology between QNAP devices based in multiple sites to fulfill enterprise video, VoIP, ERP system data, and filing needs. QuWAN adopts software-defined networking to achieve optimum network connectivity, and supports cloud-centric management for deploying a resilient IT Infrastructure. -
Administrationsfunktioner Switch-type Administreret Switch lag L2 Servicekvalitet support (QoS) Ja Webbaseret administration Ja Trafik klassificering Ja Porte & Grænseflader Basis omskiftning RJ-45 Ethernet porte, antal 16 Basis omskiftning RJ-45 Ethernet porttype 2.5G Ethernet (100/1000/2500) Gigabit Ethernet (kobber) porte, antal 8 Antal 2,5G Ethernet-porte (kobber) 8 Antal SFP + modulslots 2 Netværk Netværksstandarder IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z 10G understøttelse Ja Kobber ethernet kabelteknologi 10BASE-TX, 1000BASE-T Port-spejlning Ja Fuld duplex Ja Flowkontrol support Ja Link aggregering Ja Begrænsning af hastighed Ja Auto-forhandling Ja VLAN understøttelse Ja Vituelle LAN funktioner Port-based VLAN Port trunking Ja Optisk fiber Fiber ethernet kabelteknologi 10GBASE-LR, 10GBASE-SR, 1000Base-X Dataoverførsel MAC adresselabel 32000 entries Switch kapacitet 96 Gbit/sek. Gennemløb 48 Gbit/sek. Jumbo Frames support Ja Jumbo rammer 9000 Sikkerhed DHCP funktioner DHCP client, DHCP server Adgangskontrolliste (ACL) Ja IGMP snooping Ja Sikkerhedsalgoritmer 256-bit AES, FIPS 140-2, HTTPS, SNMPv2, SNMPv3, SSH, SSL/TLS Loop beskyttelse Ja Multicast funktioner MAC-adresse tabel (multicast) 8000 entries Design Stativ-montering Ja Produktfarve Sort, Grå Knap til nulstilling Ja LED-indikatorer Aktivitet, Alarm, Link, PoE, Hastighed Præstation Indbygget processer Ja Processorproducent Intel Processormodel Atom C3758 Processorfrekvens 2200 MHz Intern hukommelse 16000 MB Flashhukommelse 4000 MB Strømstyring Strømkilde Vekselstrøm Strømforsyning inkluderet Ja Vekselstrømsindgangsspænding 100 - 240 V Strømforbrug (maks.) 100 W Power over Ethernet (PoE) Strøm over Ethernet (PoE) Ingen Andre funktioner Garantiperiode 2 År Udvidelsesporte 2x PCIe Gen3 (x4 slot, x2 speed) I/O-porte 2x USB 3.2 Gen 1, 2 x 5GbE, 2 x 1GbE Driftsbetingelser Driftstemperatur (T-T) 0 - 40 °C Relativ luftfugtighed ved drift (H-H) 5 - 95% Vægt & størrelser Bredde 436,2 mm Dybde 326,2 mm Højde 47,2 mm Vægt 4,37 kg Emballage indhold Kabler inkluderet Vekselstrøm, LAN (RJ-45) Hurtig start guide Ja Rack monteringskit Ja Emballeringsdata Pakketype Kasse Pakkebredde 530 mm Pakkedybde 403 mm Pakkehøjde 160 mm Pakkevægt 5,56 kg Godkendelser Certificering FCC, VCCI, BSMI RCM, CCC Logistik data Oprindelsesland Taiwan Produkter pr. hovedkasse (udvendigt) 2 stk
