Varenummer: GSM4328-100NES
Mere information
-
Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.
Multicast in an Instant
NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.
Sleek, Quiet Design
Less fan noise, and mounting ears included for rack mounting.
Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.
FAST, EASY
CONFIGURATION
FOR AV PROS
A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.
FOCUS ON THE EVENT
NOT FAN NOISE
Most models have quiet mode which greatly reduces fan noise.
DESIGNED FOR
AV OVER IP
RIGHT OUT OF
THE BOX
With built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box. -
Administrationsfunktioner Switch-type Administreret Switch lag L3 Servicekvalitet support (QoS) Ja Webbaseret administration Ja Trafik formning Ja Porte & Grænseflader Basis omskiftning RJ-45 Ethernet porte, antal 24 Basis omskiftning RJ-45 Ethernet porttype Gigabit Ethernet (10/100/1000) Antal installerede SFP moduler 0 Antal installerede SFP+ moduler 4 Netværk Netværksstandarder IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x 10G understøttelse Ja VLAN understøttelse Ja Antal VLAN'er 4093 Dataoverførsel MAC adresselabel 16000 entries Switch kapacitet 128 Gbit/sek. Gennnemløb 95,23 Mpps Pakke bufferlager 16 MB Sikkerhed DHCP funktioner DHCP server, DHCP snooping, DHCPv6 snooping Design Stativ-montering Ja Stabelbar Ja Formfaktor 1U Produktfarve Sort Præstation Støjniveau 52 dB Strømstyring Strømkilde Vekselstrøm Strømforsyning inkluderet Ja Power over Ethernet (PoE) Strøm over Ethernet (PoE) Ja Power over Ethernet plus (PoE+) porte, antal 24 Power over Ethernet (PoE) effekt pr. port 30 W Total Power over Ethernet (PoE) 648 W Driftsbetingelser Driftstemperatur (T-T) 0 - 45 °C Opbevaringstemperatur (T-T) -20 - 70 °C Vægt & størrelser Bredde 440 mm Dybde 400 mm Højde 43,2 mm Vægt 6,41 kg
