POWER AND
THROUGHPUT
Edge to core flexible platform, from 1 Gigabit to 100 Gigabit, good for projects of all sizes.
Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.
Multicast in an Instant
NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.
Sleek, Quiet Design
Less fan noise, and mounting ears included for rack mounting.
Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350
FOCUS ON THE EVENT
NOT FAN NOISE
Most models have quiet mode which greatly reduces fan noise.
DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOX
With built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless audio and video delivery. Enable multicasting right out of the box.
MAXIMIZE PERFORMANCE WITH PRO WIFI ACCESS POINTS
Enable powerful, reliable WiFi at your location with Pro WiFi access points, powered by PoE or an external power adapter.
| Administrationsfunktioner | |
| Switch-type | Administreret |
| Switch lag | L3 |
| Porte & Grænseflader | |
| Antal installerede SFP+ moduler | 40 |
| Fiberkanal porte | 44 |
| Fiber optisk strømstik | QSFP28, SFP+ |
| Port til konsol | USB |
| QSFP28-portmængde | 4 |
| Netværk | |
| 10G understøttelse | Ja |
| Dataoverførsel | |
| Switch kapacitet | 1600 Gbit/sek. |
| Jumbo Frames support | Ja |
| Sikkerhed | |
| IGMP snooping | Ja |
| IGMP proxy | Ja |
| Design | |
| Stativ-montering | Ja |
| Stabelbar | Ja |
| Formfaktor | 1U |
| Produktfarve | Sort |
| Præstation | |
| Hukommelsestype | DDR4-SDRAM |
| Intern hukommelse | 4000 MB |
| Støjniveau | 69,5 dB |
| Strømstyring | |
| Strømkilde | Vekselstrøm |
| Strømforsyning inkluderet | Ja |
| Strømforbrug (maks.) | 213,6 W |
| Power over Ethernet (PoE) | |
| Strøm over Ethernet (PoE) | Ingen |
| Driftsbetingelser | |
| Varmeafgivelse | 728,21 BUT/t |
| Vægt & størrelser | |
| Bredde | 440 mm |
| Dybde | 400 mm |
| Højde | 43,2 mm |
| Vægt | 7,38 kg |
| Emballage indhold | |
| Kabler inkluderet | Vekselstrøm, USB |
| Brugervejledning | Ja |
| Rack monteringskit | Ja |
