LevelOne FSW-0808TX netværksswitch Ikke administreret Fast Ethernet (10/100) Grå
Varenummer: FSW-0808TX
.
DKK 203,13 / Stk
DKK 162,50 ekskl. moms
  •
FSW-0808TX 8-Port Fast Ethernet Switch


Mere information

  • - Kompatibel med IEEE802.3 Ethernet, IEEE802.3u Fast Ethernet standarder
    - Indeholder store-and-forward arkitektur og udfører filtering og forwarding med non-blocking fuld wire speed
    - Fuld/ Halv-duplex kapacitet på hver port
    - Understøtter 1K MAC adresser
    - 8-Port 10/100 Mbps Switch indbygget høj effektiv SRAM for pakke buffer
    - IEEE802.3x kompatibel fuld-duplex flow kontrol, halv-duplex flow kontrol
    - Alle porte understøtter Auto-MDI/ MDIX funktion

    The LevelOne FSW-0808 is a wire-speed, non-blocking networking device that provides 8 ports 10/100Mbps Ethernet connections. All ports support auto-negotiation and auto-MDI/MDIX sensing, eliminating the need for crossover cables or Uplink Ports. Each port can be used as general network port or as connecting port into a router, server, hub or another network switch.

    Easy Configuration and Maintenance
    The LevelOne FSW-0808TX does not require software configuration. Users can immediately use any features of this product simply by attaching the cables and turning on the power. For instant error detection, the switch is equipped with a full range of LEDs to help you monitor and troubleshoot problems on your network.

    Compact Size Design
    This switch is compact specially designed to fit on the desktop or in other space-limited locations. The FSW-0808TX provides an ideal solution for businesses that crave a reliable network to exchange large data files and multimedia information with bandwidth-starving workgroup, departments, and offices.

  • Administrationsfunktioner
    Switch-type Ikke administreret
    Porte & Grænseflader
    Basis omskiftning RJ-45 Ethernet porte, antal 8
    Basis omskiftning RJ-45 Ethernet porttype Fast Ethernet (10/100)
    Antal installerede SFP moduler 0
    Antal installerede SFP+ moduler 0
    Strømstik DC-in-stik
    Netværk
    Netværksstandarder IEEE 802.3, IEEE 802.3u, IEEE 802.3x
    10G understøttelse Ingen
    Kobber ethernet kabelteknologi 10BASE-T, 100BASE-TX
    Fuld duplex Ja
    Flowkontrol support Ja
    Auto MDI/MDI-X Ja
    Auto-forhandling Ja
    Dataoverførsel
    MAC adresselabel 1024 entries
    Switch kapacitet 1,6 Gbit/sek.
    Opbevar-og-frem Ja
    Pakke videresendelsesrate (100 Mbps) 148000 pps
    Pakke videresendelsesrate (10 Mbps) 14880 pps
    Design
    Stativ-montering Ingen
    Stabelbar Ingen
    Produktfarve Grå
    LED-indikatorer Aktivitet, Link, Strøm
    Præstation
    Bufferstørrelse 96 KB
    Strømstyring
    Vekselstrømsindgangsspænding 100 - 240 V
    Vekselstrømsindgangsfrekvens 50 - 60 Hz
    Udgangsspænding 5 V
    Udgangsstrøm 1 A
    Strømforbrug (typisk) 2,8 W
    Power over Ethernet (PoE)
    Strøm over Ethernet (PoE) Ingen
    Driftsbetingelser
    Driftstemperatur (T-T) 0 - 40 °C
    Opbevaringstemperatur (T-T) -40 - 70 °C
    Relativ luftfugtighed ved drift (H-H) 5 - 90%
    Relativ luftfugtighed ved opbevaring (H-H) 10 - 90%
    Vægt & størrelser
    Bredde 125 mm
    Dybde 69 mm
    Højde 30 mm
    Emballage indhold
    Hurtig start guide Ja
    Emballeringsdata
    AC-adapter inkluderet Ja
    Pakkebredde 75 mm
    Pakkedybde 130 mm
    Pakkehøjde 90 mm
    Pakkevægt 300 g
    Godkendelser
    Certificering FCC, CE, RoHS
    Logistik data
    Oprindelsesland Kina
    Harmoniseret systemkode (HS) 85176990
