Cloud Networking, Refreshed
The DBS-2000 series of switches is part of the Nuclias Cloud solution – D-Link’s complete Cloud-Managed Networking solution for Small-to-Medium Businesses (SMBs), designed to make the ownership and administration of your IT infrastructure as simple and hassle-free as possible.
Management Over the Cloud
DBS-2000 is a series of Smart Managed Switches, manageable via the Nuclias Cloud Web Portal through any compatible online PC or Tablet. Connectivity with the Nuclias Cloud platform is guaranteed, with a 99.9% Service-Level-Agreement (SLA), and operation will continue even if the Cloud connection fails.
Easy Troubleshooting
The DBS-2000 Series features Cable Diagnostics and Per Port Traffic Packet Counters to help network admins find & solve network problems. Cable Diagnostics enables quick examination of cable quality, recognition of cable type, and detection of cable errors, with the Per-Port Traffic Packet Counter helping to further isolate problems.
Advanced Security Features
The DBS-2000 series utilizes the Nuclias Cloud Web Portal interface, giving administrators an easy way to manage Layer-2 features, such as VLANs, Spanning Tree Protocol (STP), and 802.3ad Link Aggregation (static). With powerful security features, including IGMP snooping, Static MAC, and end-to-end encryption (WPA/WPA2/WPA3), these Cloud switches are a versatile solution for deployments that require easy configuration, without added complexities.
| Administrationsfunktioner | |
| Switch-type | Administreret |
| Switch lag | L2 |
| Webbaseret administration | Ja |
| Porte & Grænseflader | |
| Basis omskiftning RJ-45 Ethernet porte, antal | 48 |
| Basis omskiftning RJ-45 Ethernet porttype | Gigabit Ethernet (10/100/1000) |
| Antal installerede SFP moduler | 0 |
| Antal installerede SFP+ moduler | 0 |
| Kombo SFP porte, antal | 4 |
| Port til konsol | RJ-45 |
| Netværk | |
| Netværksstandarder | IEEE 802.3ad, IEEE 802.3at |
| 10G understøttelse | Ingen |
| Kobber ethernet kabelteknologi | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Link aggregering | Ja |
| Auto MDI/MDI-X | Ja |
| Spanning tree protokol | Ja |
| Dataoverførsel | |
| Switch kapacitet | 104 Gbit/sek. |
| Hastighed for videresendelse | 77,4 Mpps |
| Pakke bufferlager | 12 MB |
| Sikkerhed | |
| IGMP snooping | Ja |
| Sikkerhedsalgoritmer | WPA, WPA2 |
| Design | |
| Stativ-montering | Ja |
| Produktfarve | Grå |
| LED-indikatorer | Ja |
| Præstation | |
| Indbygget processer | Ja |
| Processorfrekvens | 700 MHz |
| Hukommelsestype | DDR3-SDRAM |
| Intern hukommelse | 256 MB |
| Flashhukommelse | 32 MB |
| Gennemsnitstid mellem fejl (MTBF) | 236406 t |
| Strømstyring | |
| Vekselstrømsindgangsspænding | 100 - 240 V |
| Strømforbrug (maks.) | 478,9 W |
| Power over Ethernet (PoE) | |
| Strøm over Ethernet (PoE) | Ja |
| Power over Ethernet (PoE) porte, antal | 48 |
| Power over Ethernet (PoE) effekt pr. port | 30 W |
| Total Power over Ethernet (PoE) | 370 W |
| Driftsbetingelser | |
| Driftstemperatur (T-T) | -5 - 50 °C |
| Opbevaringstemperatur (T-T) | -20 - 70 °C |
| Relativ luftfugtighed ved drift (H-H) | 0 - 95% |
| Relativ luftfugtighed ved opbevaring (H-H) | 0 - 95% |
| Varmeafgivelse | 1634,01 BUT/t |
| Vægt & størrelser | |
| Bredde | 440 mm |
| Dybde | 430 mm |
| Højde | 44 mm |
| Vægt | 6,26 kg |
| Emballeringsdata | |
| Pakkebredde | 558 mm |
| Pakkedybde | 568 mm |
| Pakkehøjde | 149 mm |
| Pakkevægt | 8,66 kg |
| Tekniske detaljer | |
| Forsendelseskassens højde (indvendig) | 59,8 cm |
| Forsendelseskasses kassens bredde (indvendig) | 31,5 cm |
| Forsendelseskassens længde (indvendig) | 57,4 cm |
| Forsendelsesemballage nettovægt | 17,3 kg |
| Produkter pr. forsendelseskasse (indvendig) | 2 stk |
| Palle bruttovægt (luft) | 242,7 kg |
| Antal papkasser pr. palle (luft) | 12 stk |
| Antal pr. palle (luft) | 24 stk |
| Pallens bruttolængde | 110 cm |
| Pallens bruttobredde | 120 cm |
| Pallehøjde (luft) | 133,1 cm |
| Palle bruttovægt (hav) | 354,8 kg |
| Antal papkasser pr. palle (hav) | 18 stk |
| Antal pr. palle (hav) | 36 stk |
| Pallehøjde (hav) | 192,9 cm |
| Forsendelseskassens bruttovægt (indvendig) | 18,6 kg |
| Logistik data | |
| Harmoniseret systemkode (HS) | 85176990 |
