Varenummer: DMS-108P/E
Mere information
-
Plug & Play
No complex configurations required for fast and easy network connectivity
Multi-Gigabit
Multi-Gigabit ports for high data rate transmission
High Power Budget
230W PoE total budget to power more devices
IEEE802.3bt
Up to 90W per port enables high-power devices (PD)
Multicast Optimization
IGMP snooping feature prevents network flooding
Silent Operation
Fanless design for a noise-free working environment
Unleash Wi-Fi 6 via 2.5G Ports
As Wi-Fi 6 (802.11ax) delivers ultra-fast speeds and low latency, standard Gigabit Ethernet can become a bottleneck. 2.5G Ethernet offers 2.5x the bandwidth without new cabling, unlocking the full potential of Wi-Fi 6 for smoother 4K/8K streaming, HD surveillance, AR/VR gaming, data transfer, and data-intensive environments. Future-proof your network and experience Wi-Fi 6 at its best—fast, reliable, and unrestricted.
Small Size, Big Power
The DMS-108P with IEEE 802.3bt (PoE++) delivers up to 90W per port with a 230W total power budget, enabling high-performance devices without additional power supplies. Ideal for Wi-Fi 6 access points, PTZ cameras, kiosks, smart LED lighting systems, and much more. PoE++ simplifies installation, reduces cabling costs, and enhances energy efficiency.
Smarter Multicast, Smoother Performance
The DMS-108P enables IGMP Snooping to enhance network efficiency by intelligently managing multicast traffic, ensuring data reaches only the devices that need it. This reduces bandwidth congestion, improves video streaming and VoIP performance, and optimizes IPTV, surveillance, and enterprise networks.
Prioritize Traffic for Optimized Performance
With the DMS-108P, you can effortlessly manage your network traffic with the 802.1p Quality of Service (QoS) feature. The switch automatically organizes and prioritizes time-sensitive and critical data for efficient delivery, enabling buffer-free video streaming as well as jitter-free video and voice calls. -
Administrationsfunktioner Switch-type Ikke administreret Servicekvalitet support (QoS) Ja Trafik klassificering Ja Porte & Grænseflader Basis omskiftning RJ-45 Ethernet porte, antal 8 Basis omskiftning RJ-45 Ethernet porttype 2.5G Ethernet (100/1000/2500) Strømstik DC-in-stik Netværk Netværksstandarder IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x 10G understøttelse Ingen Auto MDI/MDI-X Ja Ethernet LAN-datahastigheder 10,100,1000,2500 Mbit/s Dataoverførsel MAC adresselabel 4000 entries Switch kapacitet 40 Gbit/sek. Hastighed for videresendelse 29,76 Mpps Opbevar-og-frem Ja Design Stabelbar Ja Produktfarve Sort LED-indikatorer Ja Præstation Gennemsnitstid mellem fejl (MTBF) 140688261 t Strømstyring Strømkilde DC Strømforsyning inkluderet Ja DC indgangsspænding 54 V Indgangsstrøm 4.62 A Strømforbrug (maks.) 261,02 W Power over Ethernet (PoE) Strøm over Ethernet (PoE) Ja Power over Ethernet (PoE) porte, antal 8 Power over Ethernet (PoE) effekt pr. port 90 W Total Power over Ethernet (PoE) 290 W Driftsbetingelser Driftstemperatur (T-T) 0 - 40 °C Opbevaringstemperatur (T-T) -10 - 70 °C Relativ luftfugtighed ved drift (H-H) 10 - 90% Relativ luftfugtighed ved opbevaring (H-H) 5 - 90% Varmeafgivelse 890,6 BUT/t Vægt & størrelser Bredde 190 mm Dybde 120 mm Højde 38 mm Vægt 753 g Godkendelser Certificering CB; UL; LVD; FCC; VCCI; IC; BSMI
