Varenummer: DIS-100G-10S
Mere information
-
Unmanaged Plug and Play
Plug in and go. The DIS-100G-5SW reliably forwards Ethernet frames.
Gigabit Connectivity with SFP slot
Designed with 4 x 100/1000Base-T ports and 1 x 100/1000BaseSFP slot to suit a range of devices and network layouts.
Officially Certified
Certifications for vibration, shock, free-fall, NEMA‑TS2 Section 2, and electromagnetic compatibility to maximise network uptime in a variety of deployment environments, including smart city surveillance, factory automation, and outdoor wireless networks.
Withstands Extreme Temperatures
Operates effortlessly in a range of industrial and harsh environments in temperatures from -40°C to +75°C, and can cold start from -40°C.
Strong Build
The tough housing has been created to keep your network protected and reliably rugged. That’s why every DIS-switch comes with a 5-year D-Link warranty.
Fast Deployment
For instant installation it features a snap-to-DIN-rail clip, and also supports wall mounting.
Fanless Design
With no moving parts inside to reduce downtime and maintenance call outs, the rugged housing has been optimised for the transfer of heat.
Discrete Size
Small but mighty. To make the most of cabinet space, it measures: 190 x 100 x 28 mm. -
Administrationsfunktioner Switch-type Ikke administreret Servicekvalitet support (QoS) Ja Porte & Grænseflader Basis omskiftning RJ-45 Ethernet porte, antal 8 Basis omskiftning RJ-45 Ethernet porttype Gigabit Ethernet (10/100/1000) Antal SFP modulslots 2 Netværk Netværksstandarder IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3z Kobber ethernet kabelteknologi 1000BASE-T Auto MDI/MDI-X Ja Dataoverførsel MAC adresselabel 4000 entries Switch kapacitet 20 Gbit/sek. Hastighed for videresendelse 14,88 Mpps Opbevar-og-frem Ja Jumbo Frames support Ja Jumbo rammer 9000 Overførselsmetode Store-and-forward Design Stabelbar Ja Formfaktor DIN rail Produktfarve Sort LED-indikatorer Ja Kode for international beskyttelse (IP) IP40 Præstation Ventilatorfri Ja Gennemsnitstid mellem fejl (MTBF) 392267 t Strømstyring Strømkilde DC DC indgangsspænding 12 - 48 V Indgangsstrøm 1 A Strømforbrug (maks.) 7,44 W Power over Ethernet (PoE) Strøm over Ethernet (PoE) Ingen Driftsbetingelser Driftstemperatur (T-T) -20 - 65 °C Opbevaringstemperatur (T-T) -20 - 85 °C Relativ luftfugtighed ved drift (H-H) 5 - 95% Relativ luftfugtighed ved opbevaring (H-H) 5 - 95% Vægt & størrelser Bredde 190 mm Dybde 28 mm Højde 100 mm Vægt 498 g Godkendelser Certificering 47 CFR FCC Part 15 Subpart B (Class A), ICES-003 Issue 6 (Class A) EN 61000-4-2 ESD, EN 61000-4-3 RS, EN 61000-4-4 EFT, EN 61000-4-5 Surge, EN 61000-4-6 CS, EN 61000-4-8 IEC 60068-2-27 Shock, • IEC 60068-2-32 Freefall, IEC 60068-2-6 Vibration CE, FCC Logistik data Harmoniseret systemkode (HS) 85176990
