Varenummer: DGS-1530-52P/E
Mere information
-
Uninterrupted Service
Redundant power supply ensures uninterrupted operation while boosting PoE output for high-demand devices
Simplified Management
The SIM feature lets you manage multiple switches as a virtual stack under one IP, streamlining operations and integration
Enhanced Security
Features includes VLANs, ACLs, Port Security, 802.1X, and RADIUS to protect data and manage access
Resilience Connectivity
G.8032 ERPS delivers sub-millisecond ring recovery for uninterrupted connectivity across critical operations
Seamless Power Delivery
PD-Alive, Fast PoE, and Perpetual PoE ensure rapid startup, automatic device recovery, and uninterrupted power supply
Shielded for Stability
All copper ports include 6kV surge protection for reliability and protection against electrical spikes
Zero-Touch Setup, Infinite Scalability
Zero-Touch Provisioning (ZTP) streamlines setup by enabling devices to auto-configure without manual input. Simply hold the reset button for 5–10 seconds to trigger reboot and provisioning. ZTP speeds up deployment, minimizes errors, and ensures consistent configuration and ideal for large-scale networks.
Power on the switch and connect the cable to service LAN, then start ZTP
- Hold the reset button (5~10 sec)
- Get IP and settings from DHCP server
- Download firmware or configuration from TFTP server
Flexible Power for Business Growth
The DGS-1530-52P delivers up to 30 W per port with support for Perpetual and Fast PoE, offering a 370 W PoE budget, expandable to 740 W with the DPS-700 RPS. It powers APs, IP cameras, and VoIP phones over standard Ethernet—simplifying deployment and allowing easy planning of power resources across your network.
Recover Instantly with Intelligent Stacking
Physical stacking lets multiple switches act as one, boosting scalability and resilience. It reroutes traffic automatically during failures, supports hot-swapping, and ensures seamless master switch failover. Shortest-path forwarding and trunked ports enhance bandwidth and reliability. -
Administrationsfunktioner Switch-type Administreret Switch lag L2 Servicekvalitet support (QoS) Ja Webbaseret administration Ja Trafik klassificering Ja ARP inspektion Ja Konfigurerer lokationsindstillinger (CLI) Ja Porte & Grænseflader Basis omskiftning RJ-45 Ethernet porte, antal 48 Basis omskiftning RJ-45 Ethernet porttype Gigabit Ethernet (10/100/1000) Antal SFP + modulslots 4 Antal USB Type-A-porte 1 Port til konsol RJ-45 Antal USB 2.0-porte 1 Netværk Netværksstandarder IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x 10G understøttelse Ja Port-spejlning Ja Fuld duplex Ja Politikbaseret routing Ja Flowkontrol support Ja Link aggregering Ja Broadcast stormkontrol Ja Auto MDI/MDI-X Ja Spanning tree protokol Ja Ethernet LAN-datahastigheder 10,1000,100 Mbit/s Auto-forhandling Ja VLAN understøttelse Ja Antal VLAN'er 4096 Dataoverførsel MAC adresselabel 16000 entries Switch kapacitet 176 Gbit/sek. Hastighed for videresendelse 130,95 Mpps Opbevar-og-frem Ja Jumbo Frames support Ja Pakke bufferlager 1,5 MB Sikkerhed Adgangskontrolliste (ACL) Ja Adgangskontrolliste (ACL) egress 1000 Adgangskontrolliste (ACL) ingress 2000 IGMP snooping Ja Sikkerhedsalgoritmer SNMP, SNMPv2, SNMPv3 Filtrering af MAC-adresser Ja SSH/SSL support Ja Loop beskyttelse Ja Beskyttelse af adgangskode Ja Godkendelsestype RADIUS, TACACS+ Multicast funktioner Multicast-understøttelse Ja Design Stativ-montering Ja Stabelbar Ja Produktfarve Sort LED-indikatorer Ja Antal blæsere 3 blæser(e) Præstation Støjniveau 52,7 dB Gennemsnitstid mellem fejl (MTBF) 230300 t Strømstyring Strømkilde Vekselstrøm Strømforsyning inkluderet Ja Vekselstrømsindgangsspænding 100 - 240 V Vekselstrømsindgangsfrekvens 50/60 Hz Strømforbrug (maks.) 482 W Power over Ethernet (PoE) Strøm over Ethernet (PoE) Ja Power over Ethernet plus (PoE+) porte, antal 48 Total Power over Ethernet (PoE) 370 W Driftsbetingelser Driftstemperatur (T-T) -5 - 50 °C Opbevaringstemperatur (T-T) -20 - 70 °C Relativ luftfugtighed ved drift (H-H) 0 - 95% Relativ luftfugtighed ved opbevaring (H-H) 0 - 95% Varmeafgivelse 1643,62 BUT/t Vægt & størrelser Bredde 440 mm Dybde 250 mm Højde 44 mm Vægt 4,35 kg
