Outperforming the competition
The DGS-3630-28TC was benchmarked against a market leading competitor's device. It matched or exceeded the competitor's performance across all tests despite being significantly lower in price with a much lower power consumption.
Versatile Management
The DGS-3630 Series provides:
- Network Assistant Utility
- Industry-standard CLI
- Intuitive web-based management interface
Support for SNMP allows centralized management of a large number of devices and out-of-band management is available via a dedicated console port.
A mini-USB console port allows the DGS-3630 Series to be managed without any extra connectors, and a USB Type A port can be used to store logs, configuration, and firmware images.
High Availability and Flexibility
Includes stacking technology, which allows multiple switches to be combined to form a single physical or virtual stack.
Scale your network using just a stacking cable and without the need for stacking modules.
Increased redundancy over multiple physical units, simplifies management and provides a single IP address to manage all members in the stack.
Security, Performance & Availability
Robust set of QoS features helps ensure that critical network services such as Voice over IP and video conferencing are given high priority through the network.
The D-Link Safeguard Engine increases the switch’s reliability, serviceability, and availability by preventing malicious flooding traffic caused by worms or virus attacks.
| Administrationsfunktioner | |
| Switch-type | Administreret |
| Switch lag | L3 |
| Servicekvalitet support (QoS) | Ja |
| Webbaseret administration | Ja |
| Porte & Grænseflader | |
| Basis omskiftning RJ-45 Ethernet porte, antal | 20 |
| Basis omskiftning RJ-45 Ethernet porttype | Gigabit Ethernet (10/100/1000) |
| Antal installerede SFP moduler | 0 |
| Antal installerede SFP+ moduler | 0 |
| Kombo SFP porte, antal | 4 |
| Antal SFP + modulslots | 4 |
| Fiber optisk strømstik | SFP+ |
| Port til konsol | RJ-45/Mini-USB |
| Antal USB 2.0-porte | 1 |
| Netværk | |
| Netværksstandarder | IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Qbb, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at |
| 10G understøttelse | Ja |
| Kobber ethernet kabelteknologi | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Port-spejlning | Ja |
| Fuld duplex | Ja |
| IP-routing | Ja |
| Routing indtastninger | 16000 |
| Flowkontrol support | Ja |
| Link aggregering | Ja |
| Head-of-line (HOL) blokering | Ja |
| Auto-forhandling | Ja |
| Ethernet ringbeskyttelsesskift (ERPS) | Ja |
| VLAN understøttelse | Ja |
| Vituelle LAN funktioner | Private VLAN, Voice VLAN, Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN |
| Antal VLAN'er | 4000 |
| Dataoverførsel | |
| MAC adresselabel | 68000 entries |
| Switch kapacitet | 128 Gbit/sek. |
| Hastighed for videresendelse | 95,24 Mpps |
| Opbevar-og-frem | Ja |
| Statisk rute | Ja |
| Stastiske routere | 512 |
| Jumbo Frames support | Ja |
| Jumbo rammer | 12000 |
| Pakke bufferlager | 4 MB |
| Sikkerhed | |
| DHCP funktioner | DHCP server, DHCP client |
| Adgangskontrolliste (ACL) | Ja |
| IGMP snooping | Ja |
| Sikkerhedsalgoritmer | 802.1x RADIUS, SNMP, SNMPv3, SSH, SSL/TLS |
| SSH/SSL support | Ja |
| Loop beskyttelse | Ja |
| BPDU filtrering/beskyttelse | Ja |
| IP-MAC-portbinding | Ja |
| Multicast funktioner | |
| Multicast-understøttelse | Ja |
| Multicast Listener Discovery (MLD) snooping | MLD v1, MLD v2 |
| Design | |
| Stativ-montering | Ja |
| Stabelbar | Ja |
| Produktfarve | Sort, Grå |
| Antal blæsere | 4 blæser(e) |
| Sikkerhed | cUL, CB, CE, CCC, BSMI |
| Elektromagnetisk kompatibilitet | CE, FCC A, C-Tick, VCCI, BSMI, CCC |
| Præstation | |
| Fysisk stabling | 9 |
| Virtuelle stabling | 32 |
| Indbygget processer | Ja |
| Strømstyring | |
| Redundant strømforsyning | Ja |
| Vekselstrømsindgangsspænding | 100 - 240 V |
| Vekselstrømsindgangsfrekvens | 50 - 60 Hz |
| Power over Ethernet (PoE) | |
| Strøm over Ethernet (PoE) | Ja |
| Power over Ethernet plus (PoE+) porte, antal | 24 |
| Power over Ethernet (PoE) effekt pr. port | 30 W |
| Total Power over Ethernet (PoE) | 370 W |
| Driftsbetingelser | |
| Driftstemperatur (T-T) | -5 - 50 °C |
| Opbevaringstemperatur (T-T) | -40 - 70 °C |
| Relativ luftfugtighed ved drift (H-H) | 10 - 95% |
| Relativ luftfugtighed ved opbevaring (H-H) | 5 - 95% |
| Vægt & størrelser | |
| Bredde | 441 mm |
| Dybde | 380 mm |
| Højde | 44 mm |
| Vægt | 5,88 kg |
| Emballeringsdata | |
| Pakkebredde | 538 mm |
| Pakkedybde | 560 mm |
| Pakkehøjde | 170 mm |
| Pakkevægt | 8,24 kg |
| Tekniske detaljer | |
| Forsendelseskassens højde (indvendig) | 57,2 cm |
| Forsendelseskasses kassens bredde (indvendig) | 36,2 cm |
| Forsendelseskassens længde (indvendig) | 57,9 cm |
| Forsendelsesemballage nettovægt | 12,9 kg |
| Produkter pr. forsendelseskasse (indvendig) | 2 stk |
| Palle bruttovægt (luft) | 342,4 kg |
| Antal papkasser pr. palle (luft) | 18 stk |
| Antal pr. palle (luft) | 36 stk |
| Pallens bruttolængde | 110 cm |
| Pallens bruttobredde | 120 cm |
| Pallehøjde (luft) | 185,1 cm |
| Palle bruttovægt (hav) | 342,4 kg |
| Antal papkasser pr. palle (hav) | 18 stk |
| Antal pr. palle (hav) | 36 stk |
| Pallehøjde (hav) | 185,1 cm |
| Forsendelseskassens bruttovægt (indvendig) | 18 kg |
| Logistik data | |
| Harmoniseret systemkode (HS) | 85176990 |
