Varenummer: DGS-1100-26MPV2/E
Mere information
-
Smart Web UI
The DGS-1100's web user interface is an easy way to manage Layer 2 features, such as VLANs, Spanning Tree Protocol (STP), link aggregation (static). With powerful security features like IGMP snooping, Static MAC, and Storm Control, the DGS-1100 Smart family is a versatile solution for environments that require easy to deploy and easy to configure solutions without added complexities.
Easy to Deploy and Manage
D-Link’s free Network Assistant (DNA) displays all connected devices and speeds up the first time configuration. The free D-View 7 Network Management System comes with a license for 25 nodes and 2 probes and full access to the management tools. Optional upgrade licenses allow you to broaden your network and analysis.
PoE and Poe+, with budgets up to 370W
The DGS-1100 Smart Series includes a range of high power budget PoE-enabled switches for businesses looking to power larger deployments of VoIP phones, wireless access points or network cameras.
Easy Troubleshooting
The DGS-1100 Series features Loopback Detection and Cable Diagnostics to help network administrators find and solve network problems quickly and easily.
Loopback Detection is used to detect loops created by a specific port and automatically shut down the affected port. The Cable Diagnostics feature is designed for network administrators to quickly examine the quality of the copper cables, recognise the cable type, and detect cable errors.
Green Technology
D-Link Green technology enables the DGS-1100 Smart series to save power without sacrifices. The majority of the family utilises a fanless design, for silent and energy efficient operation. All are IEEE 802.3az compliant and feature Link Status detection and Time-Based PoE (excluding DGS-1100-05PD and DGS-1100-08P models).
Surveillance Mode
Select Surveillance Mode in the Web UI to take advantage of easy‑to‑use surveillance features which also enable you to manage your surveillance network effortlessly. It automatically detects your security devices and segments them into a dedicated Auto Surveillance VLAN to handle video surveillance traffic securely and efficiently. -
Administrationsfunktioner Switch-type Administreret Switch lag L2 Servicekvalitet support (QoS) Ja Webbaseret administration Ja ARP inspektion Ja MIB support • RFC768 UDP • RFC791 IP • RFC792 ICMP • RFC793 TCP • RFC826 ARP • RFC1213 MIB II • RFC1493 Bridage MIB • RFC1907 SNMPv2 MIB • RFC1215 MIB Traps Convention Porte & Grænseflader Basis omskiftning RJ-45 Ethernet porte, antal 24 Basis omskiftning RJ-45 Ethernet porttype Gigabit Ethernet (10/100/1000) Kombo SFP porte, antal 2 Netværk Netværksstandarder IEEE 802.1D, IEEE 802.1w, IEEE 802.3af, IEEE 802.3at Kobber ethernet kabelteknologi 10GBASE-T, 1000BASE-T Port-spejlning Ja Fuld duplex Ja Halv dupleks Ja Flowkontrol support Ja Link aggregering Ja Broadcast stormkontrol Ja Begrænsning af hastighed Ja Auto MDI/MDI-X Ja Spanning tree protokol Ja Head-of-line (HOL) blokering Ja Auto-forhandling Ja VLAN understøttelse Ja Vituelle LAN funktioner Port-based VLAN, Voice VLAN Dataoverførsel MAC adresselabel 8000 entries Switch kapacitet 52 Gbit/sek. Hastighed for videresendelse 38,69 Mpps Jumbo Frames support Ja Sikkerhed DHCP funktioner DHCP client IGMP snooping Ja Sikkerhedsalgoritmer SSL/TLS Filtrering af MAC-adresser Ja Statisk port, sikkerhed Ja Multicast funktioner Multicast-understøttelse Ja IPv4 multicast indtastninger 1 IPv6 multicast indtastninger 1 Antal filtrerede multicast-grupper 1 Protokoller IPv4 & IPv6 funktioner IPv4 FIB Design Stativ-montering Ja Produktfarve Sort Husmateriale Metal Præstation Flashhukommelse 16 MB Støjniveau 50,5 dB Ventilatorfri Ja MTBF (PoE) 317,777 t Strømstyring Strømforsyning inkluderet Ja Vekselstrømsindgangsspænding 100 - 240 V Strømforbrug (maks.) 454,1 W Power over Ethernet (PoE) Strøm over Ethernet (PoE) Ja Power over Ethernet (PoE) porte, antal 24 Power over Ethernet plus (PoE+) porte, antal 24 Total Power over Ethernet (PoE) 370 W Driftsbetingelser Driftstemperatur (T-T) -10 - 50 °C Opbevaringstemperatur (T-T) -40 - 70 °C Relativ luftfugtighed ved drift (H-H) 0 - 95% Relativ luftfugtighed ved opbevaring (H-H) 0 - 95% Varmeafgivelse 287 BUT/t Vægt & størrelser Bredde 440 mm Dybde 208 mm Højde 44 mm Vægt 2,8 kg Logistik data Harmoniseret systemkode (HS) 85176990
