Varenummer: DIS-200G-12S
Mere information
-
Smart Management
Featuring management interfaces, including an industry-standard CLI, and Web-based UI, the DIS-200G Serie is easy to manage and provides the controls to help protect and shape your network.
Gigabit Connectivity with SFP ports
Designed with 10 x 10/100/1000BaseT ports and 2 x SFP ports to suit a range of devices and network layouts.
Officially Certified
Certifications for vibration, shock, free-fall, electromagnetic, and high-capacity 6 kV surge protection on all copper ports to maximise network uptime in harsh deployment environments.
Withstands Extreme Temperatures
Operates effortlessly in a range of industrial and harsh environments in temperatures from -40°C to +65°C.
High Redundancy and Reliability
ERPS quick failover recovery for ring topologies that ensures minimal downtime and avoids any loss of data in mission-critical deployment settings.
Strong Build
The tough housing has been created to keep your network protected and reliably rugged.
Enhanced IP Surveillance
Supports Auto-Surveillance VLAN (ASV), automatically detecting surveillance devices and putting them into a dedicated surveillance VLAN, increasing security of surveillance data, and giving the traffic a higher priority.
Fanless Design
With no moving parts inside to reduce downtime and maintenance call outs, the rugged housing has been optimised for the transfer of heat.
Fast Deployment
For instant installation it features a snap-to-DIN-rail clip, and also supports wall mounting.
Discrete Size
Small but mighty. To make the most of cabinet space, it measures: 48 x 210 x 171.2 mm. -
Administrationsfunktioner Switch-type Administreret Switch lag L2 Servicekvalitet support (QoS) Ja Webbaseret administration Ja Konfigurerer lokationsindstillinger (CLI) Ja System hændelseslog Ja Porte & Grænseflader Basis omskiftning RJ-45 Ethernet porte, antal 10 Basis omskiftning RJ-45 Ethernet porttype Gigabit Ethernet (10/100/1000) Antal installerede SFP moduler 0 Antal installerede SFP+ moduler 0 Gigabit Ethernet (kobber) porte, antal 10 Antal SFP modulslots 2 Port til konsol RJ-45 Netværk Netværksstandarder IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z 10G understøttelse Ingen Kobber ethernet kabelteknologi 10BASE-T, 100BASE-TX, 1000BASE-T Port-spejlning Ja Fuld duplex Ja Flowkontrol support Ja Link aggregering Ja Broadcast stormkontrol Ja Auto MDI/MDI-X Ja Spanning tree protokol Ja Auto-forhandling Ja Aktiv link opdagelse Ja VLAN understøttelse Ja Vituelle LAN funktioner Voice VLAN, Tagged VLAN, Port-based VLAN Antal VLAN'er 4094 Optisk fiber Fiber ethernet kabelteknologi 1000BASE-X Dataoverførsel MAC adresselabel 8000 entries Switch kapacitet 24 Gbit/sek. Hastighed for videresendelse 17,85 Mpps Opbevar-og-frem Ja Jumbo Frames support Ja Jumbo rammer 9216 Sikkerhed DHCP funktioner DHCP client IGMP snooping Ja Sikkerhedsalgoritmer 802.1x RADIUS, SSL/TLS Godkendelse Portbaseret godkendelse Godkendelsestype RADIUS Algoritmer for køplanlægning SPQ, Weighted Round Robin (WRR) Multicast funktioner Multicast-understøttelse Ja Protokoller Administrationsprotokoller SNMP v1/v2c/v3, SNTP, Telnet Design Stativ-montering Ja Produktfarve Sort Husmateriale Metal LED-indikatorer Ja Kode for international beskyttelse (IP) IP30 Kan monteres på væggen Ja DIN-skinne montering Ja Antal blæsere 0 blæser(e) Elektromagnetisk kompatibilitet CISPR 22, FCC Part 15B Class A Præstation Gennemsnitstid mellem fejl (MTBF) 276773 t Strømstyring DC indgangsspænding 12 - 48 V Strømforbrug (maks.) 10,26 W Power over Ethernet (PoE) Strøm over Ethernet (PoE) Ingen Driftsbetingelser Driftstemperatur (T-T) -40 - 65 °C Opbevaringstemperatur (T-T) -40 - 85 °C Relativ luftfugtighed ved drift (H-H) 0 - 95% Relativ luftfugtighed ved opbevaring (H-H) 0 - 95% Varmeafgivelse 35,01 BUT/t Vægt & størrelser Bredde 171,2 mm Dybde 53 mm Højde 210 mm Vægt 1,63 kg Godkendelser Certificering CE, FCC, BSMI EN 61000-4-2 ESD EN 61000-4-3 RS EN 61000-4-4 EFT EN 61000-4-5 EN 61000-4-6 CS EN 61000-4-8 IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6 Logistik data Harmoniseret systemkode (HS) 85176990
