NETGEAR 300 Series Gigabit Ethernet Unmanaged Switches provide easy, reliable, and affordable network connectivity for home and small offices. With these unmanaged plug-and-play switches, you can expand your network connections to multiple devices instantly. The GS305P and GS308P with Power-over-Ethernet (PoE) provides power and data from a single Ethernet (CAT-5) cable to devices such as IP cameras, VoIP/Internet-based phones, wireless access points, etc. With these unmanaged plug-andplay switches, you can expand your network connections to multiple devices instantly. Just step up to GS316, GS324 or GS348 directly to avoid congestion due to stacking up lower port count switches and be ready for future expansion.
| Administrationsfunktioner | |
| Switch-type | Ikke administreret |
| Switch lag | L2 |
| Servicekvalitet support (QoS) | Ja |
| Porte & Grænseflader | |
| Basis omskiftning RJ-45 Ethernet porte, antal | 8 |
| Basis omskiftning RJ-45 Ethernet porttype | Gigabit Ethernet (10/100/1000) |
| Antal installerede SFP moduler | 0 |
| Antal installerede SFP+ moduler | 0 |
| Gigabit Ethernet (kobber) porte, antal | 8 |
| Strømstik | DC-in-stik |
| Netværk | |
| Netværksstandarder | IEEE 802.1p, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u |
| 10G understøttelse | Ingen |
| Kobber ethernet kabelteknologi | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Flowkontrol support | Ja |
| Auto MDI/MDI-X | Ja |
| Auto-sensing | Ja |
| Kabellængde opdagelse | Ja |
| Dataoverførsel | |
| MAC adresselabel | 8000 entries |
| Switch kapacitet | 16 Gbit/sek. |
| Hastighed for videresendelse | 1,448 Mpps |
| Latens (1 Gbps) | 2,6 µs |
| Jumbo Frames support | Ja |
| Jumbo rammer | 9216 |
| Pakke bufferlager | 128 MB |
| Design | |
| Stativ-montering | Ingen |
| Produktfarve | Sort |
| Husmateriale | Metal |
| LED-indikatorer | Aktivitet, Link, Strøm |
| Kan monteres på væggen | Ja |
| Præstation | |
| Gennemsnitstid mellem fejl (MTBF) | 3711898 t |
| Strømstyring | |
| Strømforbrug (maks.) | 3,04 W |
| Power over Ethernet (PoE) | |
| Strøm over Ethernet (PoE) | Ingen |
| Driftsbetingelser | |
| Driftstemperatur (T-T) | 0 - 40 °C |
| Opbevaringstemperatur (T-T) | -20 - 70 °C |
| Relativ luftfugtighed ved drift (H-H) | 0 - 90% |
| Relativ luftfugtighed ved opbevaring (H-H) | 0 - 95% |
| Driftshøjde | 0 - 3000 m |
| Varmeafgivelse | 10,4 BUT/t |
| Vægt & størrelser | |
| Bredde | 158 mm |
| Dybde | 101 mm |
| Højde | 29 mm |
| Vægt | 390 g |
| Godkendelser | |
| Certificering | CE Mark FCC Part 15 Class B IC Class B RCM CCC VCCI KC |
| Logistik data | |
| Harmoniseret systemkode (HS) | 85176990 |
