1G SFP OR 10G SFP+ UPLINK PORTS
Enable fast, dedicated connections back to your core network. Our 8-Port Ethernet switches come with 2x 1G SFP uplinks while our 24/48-port switches come with 4x 10G SFP+ uplinks.
NETWORK EXPANSION FEATURES
Build a mesh of Ethernet switches easily with features like Spanning Tree Protocol (STP) and storm control. They help control planned or inadvertent cable loops so you can expand your network with confidence.
ADVANCED NETWORK SECURITY
Ensure data passes to authorized clients only with port authentication. Advanced DHCP snooping and IP-MAC binding functions assure network integrity and help prevent attacks.
QUALITY OF SERVICE (QOS) TRAFFIC PRIORITIZATION
Prioritize traffic with numerous QoS features. Ideal for real-time voice and video applications as well as high bandwidth graphic or video uploads and downloads.
Dedicated Connections Back to the Core
Use dedicated SFP uplink ports to connect to other switches or back to your core network instead of taking away from one of your existing PoE+ ports. Plus, with our 24 and 48 port switches, you get high speed 10G SFP+ ports to ensure maximum bandwidth capacity for your edge devices.
Advanced Security, QoS, and Static Routing
Secure and optimize your smart managed network with advanced security and QoS features. On top of that, we've added static routing for free, typically only found in higher end switches.
How Does It Work?
Linksys Managed Gigabit switches can connect to devices such as desktops, surveillance cameras, access points, door access control systems, VoIP phones and ProAV systems. They can help expand the edge of your network as you add more client devices.
Administrationsfunktioner | |
Switch-type | Administreret |
Servicekvalitet support (QoS) | Ja |
Porte & Grænseflader | |
Basis omskiftning RJ-45 Ethernet porte, antal | 48 |
Basis omskiftning RJ-45 Ethernet porttype | Gigabit Ethernet (10/100/1000) |
Netværk | |
Netværksstandarder | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad |
10G understøttelse | Ja |
Port-spejlning | Ja |
IP-routing | Ja |
Link aggregering | Ja |
Broadcast stormkontrol | Ja |
Begrænsning af hastighed | Ja |
Spanning tree protokol | Ja |
Head-of-line (HOL) blokering | Ja |
VLAN understøttelse | Ja |
Vituelle LAN funktioner | Port-based VLAN |
Antal VLAN'er | 256 |
Dataoverførsel | |
MAC adresselabel | 32000 entries |
Switch kapacitet | 176 Gbit/sek. |
Hastighed for videresendelse | 130,95 Mpps |
Jumbo Frames support | Ja |
Jumbo rammer | 12000 |
Sikkerhed | |
DHCP funktioner | DHCP snooping |
Adgangskontrolliste (ACL) | Ja |
IGMP snooping | Ja |
IP-MAC-portbinding | Ja |
Godkendelse | Gæste VLAN |
Godkendelsestype | RADIUS |
Protokoller | |
Administrationsprotokoller | HTTP, HTTPS |
IPv4 FIB indtastninger | 63 |
IPv6 FIB indtastninger | 21 |
Design | |
Stativ-montering | Ja |
Stabelbar | Ja |
Produktfarve | Sort |
LED-indikatorer | Fejl, Strøm |
Oprindelsesland | Taiwan |
Præstation | |
Intern hukommelse | 512 MB |
Firmware kan opgraderes | Ja |
Strømstyring | |
Strømforsyning inkluderet | Ja |
Vekselstrømsindgangsspænding | 100 - 240 V |
Vekselstrømsindgangsfrekvens | 50/60 Hz |
Indgangsstrøm | 1.5 A |
Strømforbrug (typisk) | 43,87 W |
Power over Ethernet (PoE) | |
Strøm over Ethernet (PoE) | Ja |
Power over Ethernet plus (PoE+) porte, antal | 4 |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 45 °C |
Opbevaringstemperatur (T-T) | -20 - 70 °C |
Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
Relativ luftfugtighed ved opbevaring (H-H) | 5 - 95% |
Vægt & størrelser | |
Bredde | 440 mm |
Dybde | 260 mm |
Højde | 44 mm |
Vægt | 3,47 kg |
Emballeringsdata | |
Pakketype | Kasse |
Logistik data | |
Harmoniseret systemkode (HS) | 85176990 |
