Unlock your Network Potential with 10-Gigabit/Multi-Gigabit 5-Speed Networking Switches
Revolutionary 5-speed 10-Gigabit/Multi-Gigabit technology built in the NETGEAR multi-speed switches allows your devices to speed past the Gigabit barrier.
With the growth of virtualization, flash Storage, 4K videos , video streaming and IP surveillance, SMB networks need to extend beyond 1 Gigabit barrier. The 10-Gigabit/Multi-Gigabit Smart Managed Plus series from NETGEAR presents the right solution for this requirement; delivering unprecedented 10-Gigabit/Multi-Gigabit bandwith at an affordable cost.
Each port automatically detects which speed is needed by the connected device and provides the adequate speed. As opposed to regular 10-Gigabit switches that will only provide 1-Gigabit connectivity to any device that require less than 10-Gigabit, the XS512EM and XS724EM gives the exact speed required, no downgrade. Also, the new NETGEAR Multi-speed switch ports can be connected with regular Cat5E Ethernet cables, without the need to upgrade to Cat6/Cat6A wiring, therefore reducing wiring costs and hassle
| Administrationsfunktioner | |
| Switch-type | Administreret |
| Switch lag | L2 |
| Servicekvalitet support (QoS) | Ja |
| Porte & Grænseflader | |
| Basis omskiftning RJ-45 Ethernet porte, antal | 24 |
| Basis omskiftning RJ-45 Ethernet porttype | 10G Ethernet (100/1000/10000) |
| Antal installerede SFP moduler | 0 |
| Antal SFP + modulslots | 2 |
| Strømstik | DC-in-stik |
| Netværk | |
| Netværksstandarder | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G understøttelse | Ja |
| Broadcast stormkontrol | Ja |
| VLAN understøttelse | Ja |
| Vituelle LAN funktioner | Port-based VLAN |
| Dataoverførsel | |
| MAC adresselabel | 32000 entries |
| Switch kapacitet | 480 Gbit/sek. |
| Opbevar-og-frem | Ja |
| Jumbo Frames support | Ja |
| Jumbo rammer | 9000 |
| Pakke bufferlager | 3 MB |
| Sikkerhed | |
| DHCP funktioner | DHCP client |
| IGMP snooping | Ja |
| Filtrering af MAC-adresser | Ja |
| Design | |
| Stativ-montering | Ja |
| Formfaktor | 1U |
| Produktfarve | Blå, Grå |
| LED-indikatorer | Ja |
| Antal blæsere | 3 blæser(e) |
| Præstation | |
| Gennemsnitstid mellem fejl (MTBF) | 830493 t |
| Strømstyring | |
| Strømkilde | Vekselstrøm |
| Vekselstrømsindgangsspænding | 100 - 240 V |
| Indgangsstrøm | 2 A |
| Power over Ethernet (PoE) | |
| Strøm over Ethernet (PoE) | Ingen |
| Driftsbetingelser | |
| Driftstemperatur (T-T) | 0 - 50 °C |
| Opbevaringstemperatur (T-T) | -20 - 70 °C |
| Relativ luftfugtighed ved drift (H-H) | 0 - 90% |
| Relativ luftfugtighed ved opbevaring (H-H) | 0 - 95% |
| Varmeafgivelse | 513,88 BUT/t |
| Vægt & størrelser | |
| Bredde | 440 mm |
| Dybde | 204 mm |
| Højde | 43 mm |
| Vægt | 3,72 kg |
| Bæredygtighed | |
| Bæredygtighedscertifikater | ENERGY STAR |
| Godkendelser | |
| Certificering | 47 CFR FCC, ICES-003:2016, ANSI C63.4:2014, EN55032:2012+AC:2013, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS/NZS CISPR 32:2013, VCCI-CISPR32:2016, CNS 13438, IEC 60950-1:2005(ed.2) + A1:2009 + A2:2013, UL 60950-1, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, AS/NZS 60950.1:2015 CNS14336-1 |
| Logistik data | |
| Harmoniseret systemkode (HS) | 85176990 |
