Varenummer: FDS1904T
Mere information
-
Durable and Reliable
The monitor offers durability for use in harsh maritime environments, complying with the conditions for temperature, humidity, and vibration as defined in the IEC 60945 international standard for maritime navigation and radio communication equipment and systems. IP65 rating ensures they can withstand dust ingress and is protected against low-pressure water jets. A coating is applied to make the electronic substrates moisture-proof and the cooling fan is easily accessible for exchanging purposes.
Approval from Classification Societies
The monitor meets the requirements for the following maritime classification societies: GL (Germany), BV (France), LR (UK), DNV (Norway), ABS (USA), ClassNK (Japan), KR (Korea), and CCS (China).
Long-Lasting LED Backlight
The monitor is equipped with an LED backlight. Compared to conventional CCFL backlights, LED backlights last longer and consume less power. They are also mercury-free for minimal impact on the environment.
Calibrated for ECDIS
Backlight brightness, gamma, and RGB color settings are calibrated at the factory so each monitor achieves accurate color reproduction for meeting the highly specialized requirements of ECDIS systems. The monitor meets IEC 61174, IEC 62288, and IEC 62388 international standards for ECDIS and RADAR applications.
Wide Dimming Range
The wide dimming range of less than 1 cd/m2 up to 590 cd/m2 allows you to adjust to the appropriate brightness level for viewing during the day or at night
Clear View
The VA panel features wide viewing angles that minimize changes in contrast and gradation to maintain excellent visibility when the screen is viewed from the side. An AR coating is applied to reduce the amount of reflections on the screen for a clear display.
Optical Bonding for High Visibility
EIZO optical bondingOptional optical bonding is available for the monitor. Optical bonding significantly reduces reflective light for high visibility even when the screen is viewed in direct sunlight. A screen with optical bonding is also more resistant to applied pressure, giving it increased physical durability.
24-Hour Use, 3-Year Warranty
The monitor is built for 24-hour use and are backed by a three-year manufacturer's warranty for long-term reliability. -
Display Skærm diagonal 48,3 cm (19") Skærmopløsning 1280 x 1024 pixel Berøringsskærm Ja Responstid 20 ms Skærm form Flad Kontrastforhold (typisk) 2000:1 Vis antal farver 16,78 millioner farver Type af baggrundslys LED Berøringsskærmstype Bordplade Berøringsskærm teknologi Projekteret kapacitivt systemet Berøringsteknologi Multi-touch Antal simultane touchpunkter 5 Skærmens lysstyrke 540 cd/m² Billedformat 5:4 Synsvinkel, horisontal 178° Synsvinkel, vertikal 178° Pixel pitch 0,294 x 0,294 mm Sync-on-green (SOG) Ja Separat H/V-synkronisering Ja Sammensat synkronisering Ja Præstation NVIDIA G-SYNC Ingen AMD FreeSync Ingen Understøttede Windows-operativsystemer Ja Multimedie Indbygget kamera Ingen Indbygget mikrofon Ingen Design Produktfarve Sort Porte & Grænseflader USB upstream port type USB Type-B Antal upstream-porte 1 Antal VGA-porte (D-sub) 3 DVI-port Ja Antal DVI-D-porte 1 Ergonomisk Kan monteres på væggen Ja OSD-sprog Engelsk Strømstyring Strømforbrug (standby) 7 W Strømforbrug (maks.) 64 W Strømforbrug (strømbesparelse) 9 W Vekselstrømsindgangsspænding 85-264 V Vekselstrømsindgangsfrekvens 50 - 60 Hz Strømforsyningstype Vekselstrøm/jævnstrøm Driftsbetingelser Relativ luftfugtighed ved drift (H-H) 10 - 90% Vægt & størrelser Bredde (uden stativ) 429 mm Dybde (uden stativ) 75 mm Højde (uden stativ) 406 mm Vægt (uden stativ) 6,4 kg Andre funktioner Vis synligt område (HxL) 376,3 x 301 mm Compliance-certifikater RoHS Certificering CB, CE, WEEE, IEC60945, IEC62288/IEC61174/IEC62388, KC
