Varenummer: 5462E1G
Mere information
-
- Tackle enterprise workloads with power, efficiency, and reliability.
- Choose from flexible storage configurations for workload-optimized performance.
- Reduce unplanned downtime and minimize costs.
- Gain superior performance with Intel® Xeon® E5-2600 v3 processors (up to 36 cores per server), end-to-end 12 Gbps RAID support—devices and infrastructure—up to four RAID adapters, and up to two 300 W GPUs.
- Run up to 131 percent greater java workload performance, up to 61 percent greater virtualization performance, and up to 59 percent greater database performance per system than the previous generation.
- Reduce data-center costs with smart energy-efficient features, including unique 40° C operating temperature, 80 PLUS® Titanium power supplies (up to 96 percent efficiency), active/standby power supply modes, dual fan zone design, and TruDDR4™ Memory (up to 45 percent lower energy use over DDR3).
- Run more virtual machines and workloads with up to 50 percent more cores and cache and 2x more memory capacity per system than previous generation.
- Simplify server management and administration with Lenovo XClarity.
With the powerful, versatile 2U dual-socket System x3650 M5 rack server, you can run even more workloads, 24/7, and gain faster business insights. Integrated with up to two Intel® Xeon® processors E5-2600 v3 series and faster TruDDR4 Memory, the x3650 M5 fast forwards your business. You can select from an impressive array of storage configurations (up to 26 drive bays) that optimize diverse workloads from cloud to big data. -
Processor Processorserie Intel® Xeon E5 v3, Intel Xeon E5-2600 v3 Processorproducent Intel Processormodel E5-2603V3 Processorfrekvens 1,6 GHz Processorkerner 6 Processor-cache 15 MB Bundkort chipsæt Intel® C612 Hukommelseskanaler understøttet af processor Quad Antal installerede processorer 1 Thermal Design Power (TDP) 85 W Processor cache type Smart cache Systembus-hastighed 6,4 GT/s Maksimalt antal SMP-processorer 2 Kompatibel processor serie Intel® Xeon® Processor sokkel LGA 2011-v3 Processor litografi 22 nm Processortråde 6 Processor driftstilstande 64-bit Stepping R2 FSB Paritet Ingen Bus type QPI Antal QPI-lins 2 Processor kodenavn Haswell Tcase 72,8 °C Maksimal intern hukommelse understøttet af processor 768 GB Hukommelsestyper understøttet af processor DDR4-SDRAM Hukommelsesurhastigheder understøttet af processor 1600 MHz Hukommelsesbåndbredde understøttet af processor (maks.) 51 GB/sek. Fejlkorrigerende kode understøttet af processor Ja Udfør deaktivering af bit Ja Idle status Ja Termiske overvågningsteknologier Ja Maksimalt antal PCI Express-kanaler 40 PCI Express-konfigurationer x4, x8, x16 Processor-pakke størrelse 52.5 x 45 mm Understøttede instruktionssæt AVX 2.0 Skalerbarhed 2S Fysisk adresse udvidelse (PAE) 46 Bit Indlejret tilgængelige muligheder Ingen Konfliktfri processor Ingen Understøttelse af Intelligent Platform Management Interface (IPMI) Ja Hukommelse Intern hukommelse 8 GB Intern hukommelsestype DDR4-SDRAM Maksimal intern hukommelse 1,53 TB Hukommelsesstik 24 Fejlkorrigerende kode Ja Hukommelsesur hastighed 2133 MHz Hukommelseslayout (slots x størrelse) 1 x 8 GB Lagring Samlet lagringskapacitet 0 GB Understøtter RAID Ja Optisk drevtype DVD Super Multi Antal installerede HDD'er 0 Antal understøttede HHD'er 8 Understøttede HDD-størrelser 2.5" RAID-niveauer 0, 1, 5, 6, 10, 50, 60, JBOD Hot-swap Ja Understøttede lagerdrev brugerflader SAS, Serial ATA III Grafik On-board grafikkort Ja Netværk LAN Kontroller Broadcom BCM5719 Ethernet LAN Ja Kabelteknologi 10/100/1000Base-T(X) Ethernet-grænsefladetype Hurtigt ethernet, Gigabit Ethernet Porte & Grænseflader Ethernet LAN-porte (RJ-45) 5 Antal USB 2.0-porte 4 Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte 3 Antal VGA-porte (D-sub) 2 Udvidelsessokler PCI Express slots version 3.0 Design Kabinettype Stativ (2U) Stativ-montering Ja Understøttelse af redundante blæsere Ja Præstation BIOS-type UEFI Trusted Platform Module (TPM) Ja Trusted Platform Module (TPM) version 1.2 Software Operativsystem installeret Ingen Kompatible operativsystemer Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere Processor særlige funktioner CPU-konfiguration (maks.) 2 Intel® Rapid Storage Teknologi Ingen Enhanced Intel SpeedStep Teknologi Ja Intel® Identity Protection Teknologi (Intel® IPT) Ingen Intel® Wireless Display (Intel® WiDi) Ingen Intel® Virtualization Technology for Directed I/O (VT-d) Ja Intel® Anti-Theft Teknologi (Intel® AT) Ingen Intel® Hyper Threading Teknologi (Intel® HT Technology) Ingen Intel® My WiFi Teknologi (Intel® MWT) Ingen Intel® Turbo Boost Teknologi Ingen Intel® Quick Sync Video Teknologi Ingen Intel® InTru™ 3D Teknologi Ingen Intel® Clear Video HD Teknologi (Intel® CVT HD) Ingen Intel® Insider™ Ingen Intel® Flex Memory Access Ingen Intel® AES Nye Instruktioner (Intel® AES-NI) Ja Intel® Trusted Execution Teknologi Ja Intel® Enhanced Halt State Ja Intel® VT-x with Extended Page Tables (EPT) Ja Intel® Demand Based Switching Ja Intel® Sikker Nøgle Ja Intel® TSX-NI Ingen Intel® OS Guard Ja Intel® klar video teknologi Ingen Intel® Clear Video Teknologi til MID (Intel® CVT for MID) Ingen Intel® 64 Ja Intel® Identity Protection Technology version 0,00 Intel® Secure Key Technology version 1,00 Intel® Virtualization Technology (VT-x) Ja Intel® TSX-NI-version 0,00 Intel® Dual Display Capable Teknologi Ingen Intel® HD Graphics Ingen Intel® FDI Teknologi Ingen Intel® Fast Memory Access Ingen Processor ARK ID 83349 Strømstyring Redundant strømforsyning Ja Strømforsyning 550 W Antal understøttede overflødige strømforsyninger 2 Antal installerede strømforsyninger 1 Antal af hovedstrømforsyninger 1 Driftsbetingelser Driftstemperatur (T-T) 5 - 40 °C Opbevaringstemperatur (T-T) -40 - 60 °C Relativ luftfugtighed ved drift (H-H) 8 - 85% Relativ luftfugtighed ved opbevaring (H-H) 8 - 85% Vægt & størrelser Bredde 445,6 mm Dybde 800 mm Højde 86,5 mm Andre funktioner Indbygget skærm Ja Skærm LCD Grafikadapter G200eR2 Grafikadapter familie Matrox Integreret LAN Ja
