The ThinkEdge SE450 is a single-socket server with a 2U height and short depth case, making it suitable for deployment in shallow cabinets. It can be mounted on a wall, stacked on a shelf or mounted in a rack. The SE450 puts increased processing power, storage and network closer to where data is generated, allowing actions resulting from the analysis of that data to take place more quickly.
This product guide provides essential pre-sales information to understand the ThinkEdge SE450 edge server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SE450 and consider its use in IT solutions.
| Processor | |
| Processorserie | Intel® Xeon Silver |
| Processorproducent | Intel |
| Processormodel | 4310T |
| Processorfrekvens | 2,3 GHz |
| Processorgeneration | Intel Xeon skalerbar 3. generation |
| Processor boost frekvens | 3,4 GHz |
| Processorkerner | 10 |
| Processor-cache | 15 MB |
| Hukommelse | |
| Intern hukommelse | 32 GB |
| Intern hukommelsestype | DDR4-SDRAM |
| Fejlkorrigerende kode | Ja |
| Hukommelsesur hastighed | 3200 MHz |
| Hukommelseslayout (slots x størrelse) | 1 x 32 GB |
| Lagring | |
| Optisk drevtype | Ingen |
| SSD-størrelse | 2.5" |
| Hot-swap | Ja |
| Interne drevbåse | 2 |
| Grafik | |
| On-board grafikkort | Ja |
| Maksimal grafikadapterhukommelse | 16 MB |
| Netværk | |
| Wake-on-LAN klar | Ja |
| Ethernet LAN | Ja |
| Ethernet-grænsefladetype | 25 Gigabit Ethernet |
| Porte & Grænseflader | |
| Ethernet LAN-porte (RJ-45) | 1 |
| Antal USB 2.0-porte | 1 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 2 |
| Antal VGA-porte (D-sub) | 1 |
| Design | |
| Kabinettype | Stativ (2U) |
| Produktfarve | Sort |
| Stativ-montering | Ja |
| Præstation | |
| Målstyring | XClarity Enterprise |
| Trusted Platform Module (TPM) | Ja |
| Trusted Platform Module (TPM) version | 2.0 |
| Software | |
| Kompatible operativsystemer | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi |
| Strømstyring | |
| Redundant strømforsyning | Ja |
| Strømforsyning | 1100 W |
| Vægt & størrelser | |
| Bredde | 445 mm |
| Dybde | 323 mm |
| Højde | 87 mm |
| Vægt | 14,8 kg |
