Varenummer: CP-9020300-EU
Mere information
-
SIDE-MOUNTED CONNECTIONS
A patented PSU panel features modular, compact Type-5 connectors located on the side of the power supply, making it easier to plug in and manage your cables.
NATIVE 12V-2x6 GPU POWER CABLE
Power modern graphics cards, such as the NVIDIA® GeForce RTX™ 50 Series, using the included 12V-2x6 cable with a dual-color connector for visual confirmation of a secure GPU-side connection for easy, worry-free power delivery.
CYBENETICS GOLD CERTIFIED
Steady power output at up to 89% overall efficiency and Cybenetics™ Gold certified for lower power consumption, less noise, and cooler temperatures.
ATX 3.1 COMPLIANT and PCIe 5.1 READY
The RMx SHIFT Series features the latest standards for power delivery and connectivity to provide efficient, reliable power. RMx SHIFT Series are built with a robust resonant LLC topology with DC-DC conversion and 105°C-rated Japanese industrial-grade capacitors.
FULLY MODULAR TYPE-5 CONNECTORS
CORSAIR Type-5 PSU cables take up less space, which combines with the modular design to allow for easier cable management.
DEBOSSED-PVC CABLE KIT INCLUDED
The ultra-flexible cable kits make cable management easy and the included low-profile cable combs keep cables tidy for a sophisticated look and an easier build.
MANUAL FAN SPEED CONTROL KNOB
Want to get more air through the PSU or to exhaust heat from your case? Override the Zero RPM Mode and low-noise profile with the manual fan override knob, increasing fan speed and airflow.
140mm FLUID DYNAMIC BEARING FAN
A Fluid Dynamic Bearing fan with a magnetic dome structure minimizes noise, while Zero RPM Mode eliminates fan noise entirely at low to medium loads. -
Strømstyring Total effekt 1000 W Vekselstrømsindgangsspænding 100 - 240 V Vekselstrømsindgangsfrekvens 47 - 63 Hz Kombineret effekt (+3,3 V) 120 W Kombineret effekt (+12 V) 1000 W Kombineret effekt (+5 V) 120 W Kombineret effekt (+5 VSB) 15 W Maks. udgangsstrøm (+3,3 V) 20 A Maks. udgangsstrøm (+12 V) 83,2 A Maks. udgangsstrøm (+5 V) 20 A Maks. udgangsstrøm (+5 VSB) 3 A Porte & Grænseflader Motherboard, strømstik 24-pin ATX Længde på strømkabel på bundkort 61 cm Antal SATA strømstik 12 Antal PATA strømstik 4 Strømkabellængde SATA 100,500,700 mm EPS strømstik (8-pin) Ja PCI ekspres strømforbindelser (6+2 pin) 2 PCI Express strømstik (12+4-bens) 1 PCI Express strømstik (12+4 pin) ledningslængde 650 mm ATX strømstrik (24 stikben) Ja PCI Express stik Ja Kabeltype Fuldt modulær Præstation Formål PC Strømforsyningenhed (PSU) formfaktor ATX 80 PLUS certificering 80 PLUS Gold ATX-version 3.1 Lejeteknologi FDB Gennemsnitstid mellem fejl (MTBF) 100000 t Design Produktfarve Sort Kølingstype Aktiv Ventilator diameter 14 cm Antal blæsere 1 blæser(e) Tænd-/slukkontakt Ja Vægt & størrelser Bredde 160 mm Dybde 150 mm Højde 86 mm Vægt 3,1 kg
