Lenovo ThinkSystem SE350 server 1610 GB Stativ (1U) Intel® Xeon® D D-2143IT 2,2 GHz 64 GB DDR4-SDRAM
Varenummer: 7D1XA01CEA
.
DKK 74.412,50 / Stk
DKK 59.530,00 ekskl. moms
  •
Lenovo ThinkSystem SE350. Processorserie: Intel® Xeon® D, Processorfrekvens: 2,2 GHz, Processormodel: D-2143IT. Intern hukommelse: 64 GB, Intern hukommelsestype: DDR4-SDRAM, Hukommelseslayout (slots x størrelse): 2 x 32 GB. Samlet lagringskapacitet: 1610 GB. Ethernet LAN, Kabelteknologi: 10/100/1000Base-T(X), Wi-Fi. Redundant strømforsyning. Kabinettype: Stativ (1U)


Mere information

  • The ThinkSystem SE350 is a purpose-built server that is half the width and significantly shorter than a traditional server, making it ideal for deployment in tight spaces. It can be mounted on a wall, stacked on a shelf or mounted in a rack. The ThinkSystem SE350 puts increased processing power, storage and network closer to where data is generated, allowing actions resulting from the analysis of that data to take place more quickly.

    This product guide provides essential pre-sales information to understand the ThinkSystem SE350 edge server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SE350 and consider its use in IT solutions.

    Introduction
    The ThinkSystem SE350 is a purpose-built server that is half the width and significantly shorter than a traditional server, making it ideal for deployment in tight spaces. It can be mounted on a wall, stacked on a shelf or mounted in a rack. The ThinkSystem SE350 puts increased processing power, storage and network closer to where data is generated, allowing actions resulting from the analysis of that data to take place more quickly.

    Suggested uses: edge computing (IoT, AI, machine learning), retail, video security, inventory management, building control, telecommunications, manufacturing, distribution

    Did you know?

    Customers looking for computing solutions at the edge of their networks often have to compromise -- to use either datacenter-class equipment which is too large and power hungry, or PC based equipment which can't run their enterprise level applications. The ThinkSystem SE350 fits the space between those two extremes. Its compact design, low power usage, and high performance are just the right combination for edge locations. The SE350 can be wall mounted, stacked on a shelf or installed in a rack. It is also designed to operate in rugged environments, up to 55°C.

  • Processor
    Processorserie Intel® Xeon® D
    Processorproducent Intel
    Processormodel D-2143IT
    Processorfrekvens 2,2 GHz
    Processor boost frekvens 3 GHz
    Processorkerner 8
    Processor-cache 11 MB
    Antal installerede processorer 1
    Thermal Design Power (TDP) 65 W
    Processor sokkel FCBGA2518
    Processor litografi 14 nm
    Processortråde 16
    Processor driftstilstande 64-bit
    Stepping M1
    Bus type UPI
    Processor kodenavn Skylake
    Maksimal intern hukommelse understøttet af processor 512 GB
    Hukommelsestyper understøttet af processor DDR4-SDRAM
    Hukommelsesurhastigheder understøttet af processor 2133 Mhz
    Udfør deaktivering af bit Ja
    Idle status Ja
    Termiske overvågningsteknologier Ja
    Maksimalt antal PCI Express-kanaler 32
    Understøttede instruktionssæt AVX 2.0
    Processor kode SR3ZU
    Skalerbarhed 1S
    Indlejret tilgængelige muligheder Ja
    Konfliktfri processor Ja
    Hukommelse
    Intern hukommelse 64 GB
    Intern hukommelsestype DDR4-SDRAM
    Maksimal intern hukommelse 256 GB
    Hukommelsesstik 4
    Fejlkorrigerende kode Ja
    Hukommelsesur hastighed 2666 Mhz
    Hukommelseslayout (slots x størrelse) 2 x 32 GB
    Lagring
    Maksimal lagerkapacitet 15,68 TB
    Samlet lagringskapacitet 1610 GB
    Understøtter RAID Ja
    Optisk drevtype Ingen
    Antal installerede SSD'er 3
    SSD-grænsefladetype M.2
    Antal understøttede SSD'er 8
    RAID-niveauer 0, 1, 5, 10
    Grafik
    On-board grafikkort Ja
    On-board grafikkort, model Matrox G200
    Netværk
    Wi-Fi Ja
    Wi-Fi-standarder Wi-Fi 5 (802.11ac)
    Wake-on-LAN klar Ja
    Ethernet LAN Ja
    Kabelteknologi 10/100/1000Base-T(X)
    Ethernet-grænsefladetype 10 Gigabit Ethernet, Gigabit Ethernet
    Porte & Grænseflader
    Antal USB 2.0-porte 2
    Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte 2
    Antal VGA-porte (D-sub) 1
    Antal serielle porte 1
    Udvidelsessokler
    PCI Express slots version 3.0
    Design
    Kabinettype Stativ (1U)
    Produktfarve Sort
    Præstation
    Trusted Platform Module (TPM) Ja
    Trusted Platform Module (TPM) version 2.0
    Software
    Kompatible operativsystemer Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi. Ubuntu Server certification.
    Processor særlige funktioner
    CPU-konfiguration (maks.) 1
    Enhanced Intel SpeedStep Teknologi Ja
    Intel® Virtualization Technology for Directed I/O (VT-d) Ja
    Intel® Hyper Threading Teknologi (Intel® HT Technology) Ja
    Intel® Turbo Boost Teknologi 2.0
    Intel® AES Nye Instruktioner (Intel® AES-NI) Ja
    Intel® Trusted Execution Teknologi Ja
    Intel® Enhanced Halt State Ja
    Intel® VT-x with Extended Page Tables (EPT) Ja
    Intel® Sikker Nøgle Ja
    Intel® TSX-NI Ja
    Intel® OS Guard Ja
    Intel® Software Guard Extensions (Intel® SGX) Ingen
    Intel® 64 Ja
    Intel® Secure Key Technology version 1,00
    Intel® Virtualization Technology (VT-x) Ja
    Intel® TSX-NI-version 1,00
    Intel® QuickAssist Teknologi Ingen
    Processor ARK ID 136431
    Strømstyring
    Redundant strømforsyning Ja
    Antal installerede strømforsyninger 2
    Logistik data
    Harmoniseret systemkode (HS) 84714100
    Vægt & størrelser
    Bredde 209 mm
    Dybde 376 mm
    Højde 43 mm
    Vægt 3,75 kg
