Varenummer: 7X10A0CWEA
Mere information
-
Workload-optimized support
New second-generation Intel® Xeon® Scalable family CPUs offer increased performance of 36% over the previous generation, support for faster 2933MHz TruDDR4 memory and Intel’s Vector Neural Network Instruction (VNNI) which accelerates processor performance for the needs of growing higher data transmitting speed and advanced computing performance. Up to 6% increases in per-core performance and hardware security mitigations round out the enhanced capabilities featured in this next-generation processor technology from Intel.
Accelerate data insights
ThinkSystem ST550 supports up to two NVIDIA graphic processing unit (GPUs) cards up to 250W. Processing is offloaded to the GPU to maximize computing power and application performance, and the server is optimized to process large blocks of data in parallel. This high-performance parallel computing makes the ST550 ideal for virtualization, VDI, and private cloud.
Flexible storage
Lenovo AnyBay design features a choice of drive interface type in the same drive bay: SAS drives, SATA drives, or U.2 NVMe PCIe drives. Freedom to configure some of the bays with PCIe SSDs and still use the remaining bays for capacity SAS drives provides the ability to upgrade to more PCIe SSDs in the future as needed. -
Processor Processorserie Intel® Xeon Silver Processorproducent Intel Processormodel 4208 Processorfrekvens 2,1 GHz Processorgeneration Intel Xeon skalerbar 2. generation Processor boost frekvens 3,2 GHz Processorkerner 8 Processor-cache 11 MB Antal installerede processorer 1 Thermal Design Power (TDP) 85 W Processor sokkel LGA 3647 (Socket P) Processor litografi 14 nm Processortråde 16 Processor driftstilstande 64-bit Processor kodenavn Cascade Lake Tcase 78 °C Maksimal intern hukommelse understøttet af processor 1 TB Hukommelsestyper understøttet af processor DDR4-SDRAM Hukommelsesurhastigheder understøttet af processor 2400 MHz Udfør deaktivering af bit Ja Maksimalt antal PCI Express-kanaler 48 Processor-pakke størrelse 76.0 x 56.5 mm Understøttede instruktionssæt AVX-512 Skalerbarhed 2S Indlejret tilgængelige muligheder Ingen Hukommelse Intern hukommelse 16 GB Intern hukommelsestype DDR4-SDRAM Hukommelsesur hastighed 2933 MHz Hukommelseslayout (slots x størrelse) 1 x 16 GB Lagring Understøtter RAID Ja Optisk drevtype Ingen HDD-grænseflade SATA, Serial Attached SCSI (SAS) HDD-størrelse 2.5" RAID-niveauer 0, 1, 5, 6, 10, 50, 60 Understøttede RAID-kontroller 930-8i Understøtter hot-plug Ja Hot-swap Ja Grafik On-board grafikkort Ja On-board grafikkort, model Ikke tilgængelig Netværk Ethernet LAN Ja Kabelteknologi 10/100/1000Base-T(X) Ethernet-grænsefladetype Gigabit Ethernet Porte & Grænseflader Ethernet LAN-porte (RJ-45) 2 Antal USB 2.0-porte 5 Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte 3 Antal VGA-porte (D-sub) 1 Udvidelsessokler PCI Ekspres x4 slots 1 PCI Ekspres x8 slots 1 PCI Express x16 slots 2 PCI Express slots version 3.0 Design Kabinettype Stativ (4U) Produktfarve Sort Stativ-montering Ja Præstation Målstyring XClarity Advanced Trusted Platform Module (TPM) Ja Software Operativsystem installeret Ingen Kompatible operativsystemer Microsoft Windows Server 2016/2012 R2 Red Hat Enterprise Linux 6/7 x64 Linux Enterprise Server 12 SP2/11 SP4 VMware vSphere (ESXi) 6.5/6.0 U3 Processor særlige funktioner Enhanced Intel SpeedStep Teknologi Ja Intel® Virtualization Technology for Directed I/O (VT-d) Ja Intel® Hyper Threading Teknologi (Intel® HT Technology) Ja Intel® Turbo Boost Teknologi 2.0 Intel® AES Nye Instruktioner (Intel® AES-NI) Ja Intel® Trusted Execution Teknologi Ja Intel® VT-x with Extended Page Tables (EPT) Ja Intel® TSX-NI Ja Intel® 64 Ja Intel® Virtualization Technology (VT-x) Ja Processor ARK ID 193390 Strømstyring Redundant strømforsyning Ja Strømforsyning 750 W Antal installerede strømforsyninger 1 Logistik data Harmoniseret systemkode (HS) 84714100 Bæredygtighed Bæredygtighedscertifikater ENERGY STAR Vægt & størrelser Bredde 176 mm Dybde 670 mm Højde 438 mm Vægt 36 kg
