Mere information
-
With native SXGA+ resolution and 3000 lumens, the XEED SX80 offers perfect visuals and enhanced connectivity. PC-free operation enables easy presenting - direct from USB flash drives or digital cameras.
Features
- Canon LCOS technology with SXGA+ resolution;
- Bright 3000 lumens with Canon AISYS Optical System;
- 900:1 contrast ratio;
- 1.5 x Zoom Lens with 10:0 Lens offset;
- Full Auto Setup;
- HD ready with DVI port and HDMI™ Connector;
- PC-free operation;
- RJ-45 network port;
- Stylish design.
Native SXGA+ resolution
With native SXGA+ resolution (1400 x 1050 pixels), the XEED SX80 reproduces still and moving images with amazing clarity – and sufficient levels of detail even for specialist applications. Canon LCOS technology also avoids common projection image drawbacks, reproducing detailed images with no unwanted “lattice” or “rainbow” effects.
Exceptional brightness
With a generous 3000 lumens brightness, the XEED SX80 delivers clear, highly defined images. Canon’s AISYS optical system maximises the performance of the highly efficient AC projector lamp, for powerful projection that cuts through high levels of ambient light.
High contrast
A contrast ratio of 900:1 ensures that the XEED SX80 faithfully reproduces every colour in the source image. With deep blacks and vivid colours, every subtle gradation is rendered with pinpoint accuracy.
Easy placement
The XEED SX80 features a Canon 1.5x powered zoom lens, specially designed to combat distortion and deliver perfect image geometry. In addition, the 10:0 lens offset makes installation exceptionally easy.
HD Ready
For perfect images from high definition digital sources, the HD Ready XEED SX80 is equipped with a DVI terminal and an HDMI™ Connector. HDCP encryption is supported, enabling playback of commercial video material.
PC-Free presentations
The XEED SX80 utilises USB and PictBridge technology, for direct projection of image files from USB flash drives and most digital cameras – ideal for occasions when carrying a computer is impractical.
Integrated networking
Equipped with an on-board RJ-45 port, the XEED SX80 can be connected directly to a network for control and monitoring. This makes it ideal for integration with industry-standard AV control systems.
Quiet operation
Running at levels of just 31dBA in Quiet Mode, the XEED SX80 won’t distract your audience with fan noise. Quiet Mode also extends lamp lifetime - up to a maximum of 3000 hours.
Fully automatic set-up
At the touch of a button, the XEED SX80 automatically configures four key settings: Focus, Keystone Correction, Input Selection and Screen Colour Correction. Settings are accurately adjusted in seconds, leaving you free to concentrate on your presentation.
Convenient design
The sleek, lightweight bodyshell of the XEED SX80 complements any office or boardroom. For easy maintenance, an optional Canon ceiling bracket allows the lamp to be changed without removing the projector. -
Projektør Projektor lysstyrke 3000 ANSI lumens Projektionsteknologi LCOS Kontrastforhold (typisk) 900:1 Skærmstørrelse kompatibilitet 1016 - 7620 mm (40 - 300") Projiceringsafstand 1,2 - 9,1 m Horisontal scanningsområde 15 - 75 kHz Vertikalt scanningsområde 50 - 85 Hz Digital gamma rettelse Ja Lyskilde Lyskilde type Lampe Levetid for lyskilde 3000 t Lampe type NSH Lampeeffekt 230 W Linsesystem Fokus Automatisk Brændviddeområde 16.6 - 24.8 mm Digital zoom 12x Forstørrelse 1,5x Video Format til analogt signal NTSC, PAL, SECAM Full HD Ja HD-Ready Ja Porte & Grænseflader Antal VGA-porte (D-sub) 1 Antal HDMI-porte 1 DVI-port Ja Antal af S-video-indgange 1 Antal USB 2.0-porte 1 Udgange til hovedtelefoner 1 Mikrofonindgang Ja Netværk Ethernet LAN-porte (RJ-45) 1 Funktioner Dot clock scanningsfrekvens 170 MHz Multimedie Udgangseffekt (RMS) 1 W Antal indbyggede højttalere 1 Display Skærm diagonal 1,4 cm (0.55") Strømstyring Strømforbrug (standby) 15 W Driftsbetingelser Driftstemperatur (T-T) 5 - 35 °C Opbevaringstemperatur (T-T) -30 - 60 °C Vægt & størrelser Vægt 5,2 kg Andre funktioner Billedformat 4:3 Lydindgang 1 Dimensioner (BxDxH) 121 x 340 x 332 mm Forbindelsesteknologi Ledningsført Strømforsyning 330 W Strømforsyningstype AC Objektiv brændvidde 1,95 - 2,6
