Intel Inside®. Responsive Digital Services Outside.
The Intel® Xeon® processor E5 v4 family brings an evolutionary leap in performance and capabilities to your next-gen data center running on software defined infrastructure, supporting an agile cloud architecture and a highly-efficient traditional workload management.
The Intel® Xeon® processor E5-1600 v4 product family provides a professional, high-performance workstation platform ideal for efficient multitasking, advanced model generation, and complex applications.
Performance
Built on 14 nm process technology, the Intel® Xeon® processor E5-2600 v4 family offers up to 22 cores/44 threads per socket and 55 MB last-level cache (LLC) per socket for increased performance, as well as Intel® Transactional Synchronization Extensions (Intel® TSX) for increased parallel workload performance.
Optimized for Orchestration
Dynamically manage shared resources efficiently and increase resource utilization with Intel® Resource Director Technology (Intel® RDT) offering cache monitoring and allocation technology, code and data prioritization, and memory bandwidth monitoring.
Enhanced Security
Accelerated cryptographic performance enables encrypted data to move fast over secure connections, plus improved security keys help safeguard network access and deepen platform protection.
Build Your Agile Enterprise with Intel
Intel® Resource Director Technology
Use orchestration and automation features within Intel® RDT to help you better manage shared platform resources dynamically across compute, network, and storage.
Intel® Transactional Synchronization Extensions
Boost performance for online transaction processing (OLTP) and other multi-threaded workloads that are currently slowed by memory locking with Intel® TSX.
Intel® Advanced Vector Extensions 2
Implement Intel® Advanced Vector Extensions 2 (Intel® AVX2) to optimize overall performance for heterogeneous workloads running concurrently, even for applications that don’t use Intel AVX.
Innovative Technology for Diverse Applications and Workloads
Enterprise Cloud
Accelerate your path to a highly efficient, on-premises cloud deployment with innovation based on Intel® architecture.
Software-Defined Infrastructure (SDI)
Use proven, reliable, and innovative Intel technology as the foundation for software-defined infrastructure across your data center.
A Holistic HPC Solution
Fuel your insight with future-ready performance from the Intel® Scalable System Framework (SSF).
High-Performance Computing
Get the performance you need for creating balanced, high-performance computing systems at any scale. -
Processor Processorserie Intel® Xeon® E5 v4, Intel Xeon E5-1600 v4 Processorkerner 6 Processor sokkel LGA 2011-v3 Processor litografi 14 nm Pakketype Kasse Køler inkluderet Ja Processorproducent Intel Processormodel E5-1650V4 Processorens basisfrekvens 3,6 GHz Processor driftstilstande 64-bit Komponent til Server/arbejdsplads Processortråde 12 Systembus-hastighed 0 GT/s Processor boost frekvens 4 GHz Processor-cache 15 MB Processor cache type Smart cache Thermal Design Power (TDP) 140 W Stepping R0 Bus type QPI Antal QPI-lins 0 Hukommelsesbåndbredde understøttet af processor (maks.) 76,8 GB/sek. Processor kodenavn Broadwell Processor kode SR2P7 Processor ARK ID 92994 Hukommelse Hukommelseskanaler Fire-kanals Maksimal intern hukommelse understøttet af processor 1,53 TB Hukommelsestyper understøttet af processor DDR4-SDRAM Hukommelsesurhastigheder understøttet af processor 1600,1866,2133,2400 MHz Fejlkorrigerende kode Ja Grafik On-board grafikkort Ingen Funktioner Udfør deaktivering af bit Ja Idle status Ja Termiske overvågningsteknologier Ja Markedssegment Server Maksimalt antal PCI Express-kanaler 40 PCI Express slots version 3.0 Understøttede instruktionssæt AVX 2.0 Skalerbarhed 1S Fysisk adresseudvidelse (PAE) Ja CPU-konfiguration (maks.) 1 Indlejret tilgængelige muligheder Ingen Fysisk adresse udvidelse (PAE) 46 Bit PCI Express CEM-revision 3.0 Eksportkontrolklassisfikationsnummer (ECCN) 5A992C Automatiseret sporingssystem til vareklassificering (CCATS) G077159 Processor særlige funktioner Intel® Hyper Threading Teknologi (Intel® HT Technology) Ja Intel® Identity Protection Teknologi (Intel® IPT) Ja Intel® Turbo Boost Teknologi 2.0 Intel® Flex Memory Access Ingen Intel® AES Nye Instruktioner (Intel® AES-NI) Ja Enhanced Intel SpeedStep Teknologi Ja Intel® Trusted Execution Teknologi Ja Intel®-udvidelser til transaktionssynkronisering Ja Intel® Enhanced Halt State Ja Intel® VT-x with Extended Page Tables (EPT) Ja Intel® Demand Based Switching Ja Intel® Sikker Nøgle Ja Intel® TSX-NI Ja Intel® OS Guard Ja Intel® 64 Ja Intel® Identity Protection Technology version 1,00 Intel® Secure Key Technology version 1,00 Intel® Virtualization Technology (VT-x) Ja Intel® Virtualization Technology for Directed I/O (VT-d) Ja Intel® TSX-NI-version 1,00 Konfliktfri processor Ja Intel® Turbo Boost Max Teknologi 3.0 Ja Berettigelse til Intel® vPro™ platform Ja Driftsbetingelser Tcase 69 °C Tekniske detaljer Processor cache 15360 KB Produkttype Processor Understøttede hukommelsestyper DDR4-SDRAM Bustype enheder GT/s Lanceringsdato Q2'16 Status Launched Processor brand navn Intel Xeon Sidste ændring 63903513 Produktfamilie Intel Xeon Processor E5 v4 Family Bushastighed 0 GT/s Status for servicering End of Servicing Updates Dato for afslutning af serviceopdateringer Thursday, June 30, 2022 Logistik data Harmoniseret systemkode (HS) 8542310001 Emballeringsdata Pakkebredde 44 mm Pakkedybde 140 mm Pakkehøjde 117 mm Vægt & størrelser Processor-pakke størrelse 45mm x 52.5mm Andre funktioner Maksimal intern hukommelse 1,5 TB, 1572864 MB
