Intel® Trusted Execution Technology
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.
Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel® 64
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.
Intel® Clear Video HD Technology
Intel® Clear Video HD Technology, like its predecessor, Intel® Clear Video Technology, is a suite of image decode and processing technologies built into the integrated processor graphics that improve video playback, delivering cleaner, sharper images, more natural, accurate, and vivid colors, and a clear and stable video picture. Intel® Clear Video HD Technology adds video quality enhancements for richer color and more realistic skin tones.
Cache
CPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.
Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Intel® InTru™ 3D Technology
Intel® InTru™ 3D Technology provides stereoscopic 3-D Blu-ray* playback in full 1080p resolution over HDMI* 1.4 and premium audio.
Idle States
Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.
Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.
Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.
Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
Instruction Set
An instruction set refers to the basic set of commands and instructions that a microprocessor understands and can carry out. The value shown represents which Intel’s instruction set this processor is compatible with.
Intel® Quick Sync Video
Intel® Quick Sync Video delivers fast conversion of video for portable media players, online sharing, and video editing and authoring.
Intel® VT-x with Extended Page Tables (EPT)
Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.
Intel® Optane™ Memory Supported
Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.
Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Intel® Clear Video Technology
Intel® Clear Video Technology is a suite of image decode and processing technologies built into the integrated processor graphics that improve video playback, delivering cleaner, sharper images, more natural, accurate, and vivid colors, and a clear and stable video picture.
Intel® Secure Key
Intel® Secure Key includes instructions RDRAND and RDSEED and the underlying the hardware implementation used to generate high-quality keys for cryptographic protocols.
Intel® Software Guard Extensions (Intel® SGX)
Intel® Software Guard Extensions (Intel® SGX) provide applications the ability to create hardware enforced trusted execution protection for their applications’ sensitive routines and data. Intel® SGX provides developers a way to partition their code and data into CPU hardened trusted execution environments (TEE’s).
Instruction Set Extensions
Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).
Thermal Monitoring Technologies
Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits.
Intel® Identity Protection Technology
Intel® Identity Protection Technology is a built-in security token technology that helps provide a simple, tamper-resistant method for protecting access to your online customer and business data from threats and fraud. Intel® IPT provides a hardware-based proof of a unique user’s PC to websites, financial institutions, and network services; providing verification that it is not malware attempting to login. Intel® IPT can be a key component in two-factor authentication solutions to protect your information at websites and business log-ins.
Intel® Memory Protection Extensions (Intel® MPX)
Intel® Memory Protection Extensions (Intel® MPX) provides a set of hardware features that can be used by software in conjunction with compiler changes to check that memory references intended at compile time do not become unsafe at runtime due to buffer overflow or underflow.
Intel® Stable IT Platform Program (SIPP)
The Intel® Stable IT Platform Program (Intel® SIPP) aims for zero changes to key platform components and drivers for at least 15 months or until the next generational release, reducing complexity for IT to effectively manage their computing endpoints.
Intel® Boot Guard
Intel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks.
Intel® Transactional Synchronization Extensions
Intel® Transactional Synchronization Extensions (Intel® TSX) are a set of instructions that add hardware transactional memory support to improve performance of multi-threaded software. -
Processor Processorserie Intel® Pentium® Gold, Intel Pentium Gold Series Processorkerner 2 Processor sokkel LGA 1151 (stik H4) Processor litografi 14 nm Pakketype Bakke Køler inkluderet Ingen Processorproducent Intel Processormodel G5400 Processorens basisfrekvens 3,7 GHz Processor driftstilstande 64-bit Komponent til PC Processortråde 4 Systembus-hastighed 8 GT/s Processor-cache 4 MB Processor cache type Smart cache Thermal Design Power (TDP) 58 W Bus type DMI3 Hukommelsesbåndbredde understøttet af processor (maks.) 37,5 GB/sek. Processor kodenavn Coffee Lake Processor ARK ID 129951 Hukommelse Hukommelseskanaler To-kanals Maksimal intern hukommelse understøttet af processor 64 GB Hukommelsestyper understøttet af processor DDR4-SDRAM Hukommelsesurhastigheder understøttet af processor 2400 MHz Fejlkorrigerende kode Ja Grafik On-board grafikkort Ja Diskret grafikadapter Ingen On-board grafikkort, model Intel® UHD Graphics 610 Diskret grafikadaptermodel Ikke tilgængelig Maksimalt indbygget grafikadapterhukommelse 64 GB Indbygget grafikadapter basefrekvens 350 MHz Indbygget grafikadapter dynamisk frekvens (maks.) 1050 MHz Antal understøttede skærme (indbygget grafik) 3 Understøttelse af indbygget 4K grafikadapter Ja Indbygget grafikadapter DirectX-version 12.0 Indbygget grafikadapter OpenGL-version 4.5 Indbygget grafikadapter maksimal opløsning (DisplayPort) 4096 x 2304 pixel Indbygget grafikadapter maksimal opløsning (eDP- integreret fladskærm) 4096 x 2304 pixel Indbygget grafikadapter maksimal opløsning (HDMI) 4096 x 2304 pixel Opdateringshastighed for indbygget grafikadapter ved maksimal opløsning (DisplayPort) 60 Hz Opdateringshastighed for indbygget grafikadapter ved maksimal opløsning (eDP-integreret fladskærm) 60 Hz Opdateringshastighed for indbygget grafikadapter ved maksimal opløsning (HDMI) 24 Hz Indbygget grafikadapter-ID 0x3E90/x93 Funktioner Udfør deaktivering af bit Ja Idle status Ja Termiske overvågningsteknologier Ja Markedssegment Desktop Maksimalt antal PCI Express-kanaler 16 PCI Express slots version 3.0 PCI Express-konfigurationer 1x16, 2x8, 1x8+2x4 Understøttede instruktionssæt SSE4.1, SSE4.2 Skalerbarhed 1S CPU-konfiguration (maks.) 1 Indlejret tilgængelige muligheder Ja Specifikation for termisk opløsning PCG 2015C PCI Express CEM-revision 3.0 Eksportkontrolklassisfikationsnummer (ECCN) 5A992C Automatiseret sporingssystem til vareklassificering (CCATS) G077159 Processor særlige funktioner Intel® Hyper Threading Teknologi (Intel® HT Technology) Ja Intel® Identity Protection Teknologi (Intel® IPT) Ja Intel® Turbo Boost Teknologi Ingen Intel® Quick Sync Video Teknologi Ja Intel® InTru™ 3D Teknologi Ja Intel® Clear Video HD Teknologi (Intel® CVT HD) Ja Intel® AES Nye Instruktioner (Intel® AES-NI) Ja Enhanced Intel SpeedStep Teknologi Ja Intel® Trusted Execution Teknologi Ingen Intel® hukommelse beskyttelsesudvidelser (Intel® MPX) Ja Intel®-udvidelser til transaktionssynkronisering Ingen Intel® Enhanced Halt State Ja Intel® Clear Video Teknologi til MID (Intel® CVT for MID) Ja Intel® VT-x with Extended Page Tables (EPT) Ja Intel® Sikker Nøgle Ja Intel® TSX-NI Ingen Intel® Stabil Billede Platformsprogram (SIPP) Ingen Intel® OS Guard Ja Intel® klar video teknologi Ja Intel® Software Guard Extensions (Intel® SGX) Ja Intel® 64 Ja Intel® Identity Protection Technology version 1,00 Intel® Secure Key Technology version 1,00 Intel® Stable Billede Platform Program (SIPP) version 0,00 Intel® Virtualization Technology (VT-x) Ja Intel® Virtualization Technology for Directed I/O (VT-d) Ja Intel® TSX-NI-version 0,00 Intel® Optane™ Memory Ready Ja Intel® Boot Guard Ja Berettigelse til Intel® vPro™ platform Ingen Driftsbetingelser Tjunction 100 °C Tekniske detaljer Processor cache 4096 KB Produkttype Processor Understøttede hukommelsestyper DDR4-SDRAM Maksimal grafikadapterhukommelse 64 GB Bus båndbredde 8 Bustype enheder GT/s Lanceringsdato Q2'18 Maksimal opløsning og opdateringshastighed (DisplayPort) 4096x2304@60Hz Maksimal opløsning og opdateringshastighed (HDMI) 4096x2304@24Hz Maksimal opløsning og opdateringshastighed (VGA) 4096x2304@60Hz Status Launched Maksimal hukommelse 64 GB Processor brand navn Intel Pentium Gold (2017) Intel Pentium Gold Processor (2017) Sidste ændring 63903513 Produktfamilie Intel Pentium Processor Bushastighed 8 GT/s Processor ID 0x3E90/x93 Logistik data Harmoniseret systemkode (HS) 8542310001 Vægt & størrelser Processor-pakke størrelse 37.5 x 37.5 mm Andre funktioner Maksimal intern hukommelse 64 GB, 65536 MB
