Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Intel® Demand Based Switching
Intel® Demand Based Switching is a power-management technology in which the applied voltage and clock speed of a microprocessor are kept at the minimum necessary levels until more processing power is required. This technology was introduced as Intel SpeedStep® Technology in the server marketplace.
Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network. -
Processor Processorserie Intel® Xeon® 7000 Sequence, Intel Xeon 7200 Series Processorkerner 2 Processor sokkel Sokkel 604(mPGA604) Processor litografi 65 nm Pakketype Bakke Køler inkluderet Ingen Processorproducent Intel Processormodel E7210 Processorens basisfrekvens 2,4 GHz Processor driftstilstande 64-bit Processortråde 2 Processor-cache 8 MB Processor cache type L2 Processor front side bus 1066 MHz Thermal Design Power (TDP) 80 W VID spændingsområde 1 - 1,5 V Stepping G0 FSB Paritet Ja Bus type FSB CPU-multiplikator (bus/kerneforhold) 9 Processor kodenavn Tigerton Processor kode SLA6D Processor ARK ID 30779 Funktioner Udfør deaktivering af bit Ja Idle status Ja Termiske overvågningsteknologier Ja Markedssegment Server Antal behandling Die transistorer 582 M Behandling Die størrelse 286 mm² Antal grafik og IMC Die transistorer 582 M Indlejret tilgængelige muligheder Ingen Eksportkontrolklassisfikationsnummer (ECCN) 3A991.A.1 Automatiseret sporingssystem til vareklassificering (CCATS) NA Processor særlige funktioner Intel® Hyper Threading Teknologi (Intel® HT Technology) Ingen Intel® Turbo Boost Teknologi Ingen Enhanced Intel SpeedStep Teknologi Ja Intel® Trusted Execution Teknologi Ingen Intel® Enhanced Halt State Ja Intel® Demand Based Switching Ja Intel® 64 Ja Intel® Virtualization Technology (VT-x) Ja Driftsbetingelser Maksimal driftstemperatur 64 °C Tcase 64 °C Tekniske detaljer Processor cache 8192 KB Produkttype Processor Fødselsdato Q3'07 Bus båndbredde 1066 Bustype enheder MHz Lanceringsdato Q3'07 Processor kernespænding 1.0-1.5 V Produktnavn Intel Xeon E7210 (8M Cache, 2.40 GHz, 1066 MHz FSB) Status Discontinued Processor brand navn Intel Xeon Sidste ændring 63903513 Produktfamilie Intel Xeon Processor 7000 Sequence Bushastighed 1066 MHz Logistik data Harmoniseret systemkode (HS) 8542310001 Vægt & størrelser Processor-pakke størrelse 53.3mm x 53.3mm Andre funktioner Cache hukommelse 8 MB
