Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.
Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.
Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.
Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
Intel® Standard Manageability (ISM)
Intel® Standard Manageability is the manageability solution for Intel vPro® Essentials platforms and is a subset of Intel® AMT with out-of-band management over Ethernet and Wi-Fi, but no KVM or new life cycle management features.
Intel® Control-Flow Enforcement Technology
CET - Intel Control-flow Enforcement Technology (CET) helps protect against the misuse of legitimate code snippets through return-oriented programming (ROP) control-flow hijacking attacks.
| Processor | |
| Processorserie | Intel® Core™ i3 |
| Processorkerner | 4 |
| Processor sokkel | LGA 1700 |
| Pakketype | Kasse |
| Processorproducent | Intel |
| Processormodel | i3-13100 |
| Processor driftstilstande | 64-bit |
| Processorgeneration | Intel Core i3-13xxx |
| Processortråde | 8 |
| Performance-kerner | 4 |
| Effektive kerner | 0 |
| Processor boost frekvens | 4,5 GHz |
| Boostfrekvens af performancekerne | 4,5 GHz |
| Basisfrekvens af performancekerne | 3,4 GHz |
| Processor-cache | 12 MB |
| Processor cache type | Smart cache |
| Processor base power | 60 W |
| Maksimal turbokraft | 89 W |
| Bus type | DMI4 |
| Maksimalt antal DMI-baner | 8 |
| Hukommelsesbåndbredde understøttet af processor (maks.) | 76,8 GB/sek. |
| Processor kodenavn | Raptor Lake |
| Processor ARK ID | 230575 |
| Hukommelse | |
| Hukommelseskanaler | To-kanals |
| Maksimal intern hukommelse understøttet af processor | 192 GB |
| Hukommelsestyper understøttet af processor | DDR4-SDRAM, DDR5-SDRAM |
| Hukommelsesbåndbredde (maks.) | 76,8 GB/sek. |
| Grafik | |
| On-board grafikkort | Ja |
| Diskret grafikadapter | Ingen |
| On-board grafikkort, model | Intel UHD Graphics 730 |
| Diskret grafikadaptermodel | Ikke tilgængelig |
| Understøttelse af indbyggede grafikadapterudgange | Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1 |
| Indbygget grafikadapter basefrekvens | 300 MHz |
| Indbygget grafikadapter dynamisk frekvens (maks.) | 1500 MHz |
| Antal understøttede skærme (indbygget grafik) | 4 |
| Indbygget grafikadapter DirectX-version | 12.0 |
| Indbygget grafikadapter OpenGL-version | 4.5 |
| Indbygget grafikadapter maksimal opløsning (DisplayPort) | 7680 x 4320 pixel |
| Indbygget grafikadapter maksimal opløsning (eDP- integreret fladskærm) | 5120 x 3200 pixel |
| Indbygget grafikadapter maksimal opløsning (HDMI) | 4096 x 2160 pixel |
| Opdateringshastighed for indbygget grafikadapter ved maksimal opløsning (DisplayPort) | 60 Hz |
| Opdateringshastighed for indbygget grafikadapter ved maksimal opløsning (eDP-integreret fladskærm) | 120 Hz |
| Opdateringshastighed for indbygget grafikadapter ved maksimal opløsning (HDMI) | 60 Hz |
| Indbygget grafikadapter-ID | 0x4692 |
| Antal udførelsesenheder | 24 |
| Multi-format codec-motorer | 1 |
| Funktioner | |
| Udfør deaktivering af bit | Ja |
| Idle status | Ja |
| Termiske overvågningsteknologier | Ja |
| Markedssegment | Desktop |
| Brugsbetingelser | PC/Client/Tablet |
| Maksimalt antal PCI Express-kanaler | 20 |
| PCI Express slots version | 5.0, 4.0 |
| PCI Express-konfigurationer | 1x16+1x4, 2x8+1x4 |
| Understøttede instruktionssæt | SSE4.1, SSE4.2, AVX 2.0 |
| Skalerbarhed | 1S |
| CPU-konfiguration (maks.) | 1 |
| Indlejret tilgængelige muligheder | Ja |
| Direct Media Interface (DMI) revision | 4.0 |
| Eksportkontrolklassisfikationsnummer (ECCN) | 5A992C |
| Automatiseret sporingssystem til vareklassificering (CCATS) | 740.17B1 |
| Processor særlige funktioner | |
| Intel® Hyper Threading Teknologi (Intel® HT Technology) | Ja |
| Intel® Turbo Boost Teknologi | 2.0 |
| Intel® Quick Sync Video Teknologi | Ja |
| Intel® Clear Video HD Teknologi (Intel® CVT HD) | Ja |
| Intel® AES Nye Instruktioner (Intel® AES-NI) | Ja |
| Enhanced Intel SpeedStep Teknologi | Ja |
| Intel® Speed Shift Technology | Ja |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Ja |
| Intel® CET (Control-flow Enforcement Technology) | Ja |
| Intel® Thread Director | Ingen |
| Intel® VT-x with Extended Page Tables (EPT) | Ja |
| Intel® Sikker Nøgle | Ja |
| Intel® OS Guard | Ja |
| Intel® 64 | Ja |
| Intel® Virtualization Technology (VT-x) | Ja |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Ja |
| Intel® Turbo Boost Max Teknologi 3.0 | Ingen |
| Intel® Boot Guard | Ja |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Ja |
| Intel® Volume Management Device (VMD) | Ja |
| Mønsterbaseret eksekveringskontrol (MBE) | Ja |
| Intel® Standard Manageability (ISM) | Ja |
| Intel® Threat Detection Technology (TDT) | Ja |
| Driftsbetingelser | |
| Tjunction | 100 °C |
| Logistik data | |
| Harmoniseret systemkode (HS) | 8542310001 |
| Vægt & størrelser | |
| Processor-pakke størrelse | 45 x 37.5 mm |
| Andre funktioner | |
| Maksimal intern hukommelse | 192 GB |
