Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.
Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.
Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.
Intel® Thermal Velocity Boost
Intel® Thermal Velocity Boost (Intel® TVB) is a feature that opportunistically and automatically increases clock frequency above single-core and multi-core Intel® Turbo Boost Technology frequencies based on how much the processor is operating below its maximum temperature and whether turbo power budget is available. The frequency gain and duration is dependent on the workload, capabilities of the processor and the processor cooling solution.
Intel® Turbo Boost Max Technology 3.0
Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.
Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.
Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
Idle States
Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.
Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Thermal Monitoring Technologies
Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits.
Intel® Volume Management Device (VMD)
Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives. -
Processor Processorserie Intel® Core™ i9 Processorkerner 24 Processor sokkel LGA 1700 Pakketype Bakke Processorproducent Intel Processormodel i9-13900KS Processor driftstilstande 64-bit Processorgeneration 13th gen Intel® Core™ i9 Processortråde 32 Performance-kerner 8 Effektive kerner 16 Processor boost frekvens 6 GHz Boostfrekvens af performancekerne 5,4 GHz Basisfrekvens af performancekerne 3,2 GHz Boostfrekvens af effektiv kerne 4,3 GHz Basisfrekvens af effektiv kerne 2,4 GHz Processor-cache 36 MB Processor cache type Smart cache Processor base power 150 W Maksimal turbokraft 253 W Stepping B0 Bus type DMI4 Maksimalt antal DMI-baner 8 Hukommelsesbåndbredde understøttet af processor (maks.) 89,6 GB/sek. Processor kodenavn Raptor Lake Processor ARK ID 232167 Hukommelse Hukommelseskanaler To-kanals Maksimal intern hukommelse understøttet af processor 192 GB Hukommelsestyper understøttet af processor DDR4-SDRAM, DDR5-SDRAM Fejlkorrigerende kode Ja Hukommelsesbåndbredde (maks.) 89,6 GB/sek. Grafik On-board grafikkort Ja Diskret grafikadapter Ingen On-board grafikkort, model Intel UHD Graphics 770 Diskret grafikadaptermodel Ikke tilgængelig Understøttelse af indbyggede grafikadapterudgange Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1 Indbygget grafikadapter basefrekvens 300 MHz Indbygget grafikadapter dynamisk frekvens (maks.) 1650 MHz Antal understøttede skærme (indbygget grafik) 4 Indbygget grafikadapter DirectX-version 12.0 Indbygget grafikadapter OpenGL-version 4.5 Indbygget grafikadapter maksimal opløsning (DisplayPort) 7680 x 4320 pixel Indbygget grafikadapter maksimal opløsning (eDP- integreret fladskærm) 5120 x 3200 pixel Indbygget grafikadapter maksimal opløsning (HDMI) 4096 x 2160 pixel Opdateringshastighed for indbygget grafikadapter ved maksimal opløsning (DisplayPort) 60 Hz Opdateringshastighed for indbygget grafikadapter ved maksimal opløsning (eDP-integreret fladskærm) 120 Hz Opdateringshastighed for indbygget grafikadapter ved maksimal opløsning (HDMI) 60 Hz Indbygget grafikadapter-ID 0xA780 Antal udførelsesenheder 32 Multi-format codec-motorer 2 Funktioner Udfør deaktivering af bit Ja Idle status Ja Termiske overvågningsteknologier Ja Markedssegment Desktop Brugsbetingelser PC/Client/Tablet Maksimalt antal PCI Express-kanaler 20 PCI Express slots version 5.0, 4.0 PCI Express-konfigurationer 1x16+1x4, 2x8+1x4 Understøttede instruktionssæt SSE4.1, SSE4.2, AVX 2.0 Skalerbarhed 1S CPU-konfiguration (maks.) 1 Indlejret tilgængelige muligheder Ingen Direct Media Interface (DMI) revision 4.0 Eksportkontrolklassisfikationsnummer (ECCN) 5A992C Automatiseret sporingssystem til vareklassificering (CCATS) 740.17B1 Processor særlige funktioner Intel® Hyper Threading Teknologi (Intel® HT Technology) Ja Intel® Turbo Boost Teknologi 2.0 Intel® Quick Sync Video Teknologi Ja Intel® Clear Video HD Teknologi (Intel® CVT HD) Ja Intel® AES Nye Instruktioner (Intel® AES-NI) Ja Enhanced Intel SpeedStep Teknologi Ja Intel® Trusted Execution Teknologi Ja Intel® Speed Shift Technology Ja Intel® Thermal Velocity Boost Ja Intel® Adaptive Boost-teknologi Ja Intel® Turbo Boost Max Technology 3.0-frekvens 5,8 GHz Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 Ja Intel® termisk hastighedsforøgelsesfrekvens 6 GHz Intel® CET (Control-flow Enforcement Technology) Ja Intel® Thread Director Ja Intel® VT-x with Extended Page Tables (EPT) Ja Intel® Sikker Nøgle Ja Intel® Active Management Teknologi (Intel® AMT) Ja Intel® Stabil Billede Platformsprogram (SIPP) Ja Intel® OS Guard Ja Intel® 64 Ja Intel® Virtualization Technology (VT-x) Ja Intel® Virtualization Technology for Directed I/O (VT-d) Ja Intel® Turbo Boost Max Teknologi 3.0 Ja Intel® Boot Guard Ja Intel® Deep Learning Boost (Intel® DL Boost) on CPU Ja Intel® Volume Management Device (VMD) Ja Mønsterbaseret eksekveringskontrol (MBE) Ja Berettigelse til Intel® vPro™ platform Ja Intel® Standard Manageability (ISM) Ja Intel® One-Click Recovery Ja Intel® Stable IT Platform Program (SIPP) Ja Intel® Remote Platform Deletese (RPE) Ja Intel® virtualiseringsteknologi med omdirigeringsbeskyttelse (VT-rp) Ja Intel vPro® Enterprise Platform kvalificering Ja Intel® Threat Detection Technology (TDT) Ja Kvalificering til Intel® Hardware Shield Ja Intel® Total Memory Encryption - Multi Key Ja Intel vPro® Essentials Platform Kvalificering Ja Driftsbetingelser Tjunction 100 °C Tekniske detaljer OpenCL version 3.0 Målgruppe Gaming, Content Creation Lanceringsdato Q1'23 Status Launched Logistik data Harmoniseret systemkode (HS) 8542310001 Andre funktioner L2 cache 32768 KB Maksimal intern hukommelse 192 GB Grafikudgang eDP 1.4b, DP 1.4a, HDMI 2.1
