Extend a Gigabit Network via
Your Existing Electrical Wiring
AV1000 2-Port Gigabit Passthrough Powerline Starter Kit
Extend an AV1000 Speed Network to Any Outlet
- No need for new wires or drilling
- Network passes through walls and floors
Integrating advanced HomePlug AV2 technology, this kit provides users with high-speed data transfer rates up to 1000 Mbps, which is ideal for bandwidth-intensive applications such as simultaneous HD/3D/4K video streaming, online gaming, and large file transfers. Just plug in and enjoy!
2× Gigabit Ports for High-Speed Connections
Provide reliable high-speed wired connections for game consoles, smart TVs, STBs, and more.
Plug and Play, No Configuration Required
1. Connect a powerline adapter to your router.
2. Plug another powerline adapter into a wall socket in another room.
3. Connect it to your internet-enabled device via Ethernet—and you’re done!
Don’t Worry about Occupying an Outlet
Simply plug into your TL-PA7027P KIT as though it were a normal wall socket. Feel free to plug in PCs, smart TVs, or other wired appliances without any performance differences.
Up to 85% Power Saved
The future’s looking green for powerline adapters. TL-PA7027P KIT’s practical design and sophisticated Power-Saving Mode, which automatically switches from its regular "Working" mode to "Power-Saving" mode, reduces its energy consumption by up to 85%.
| Præstation | |
| Maksimal dataoverførselshastighed | 1000 Mbit/s |
| Ethernet LAN | Ja |
| Wi-Fi | Ingen |
| Netværksstandarder | IEEE 1901, IEEE 802.3, IEEE 802.3u |
| Strømstik | Type G |
| Indbygget stikkontakt | Ja |
| Ethernet LAN-grænsefladetype | Gigabit Ethernet |
| Ethernet LAN-datahastigheder | 10,100,1000 Mbit/s |
| Ethernet LAN-porte (RJ-45) | 1 |
| PowerLine standard | HomePlug AV2 |
| Modulation | COFDM |
| Sikkerhedsalgoritmer | 128-bit AES |
| Maksimal driftstilstand | 300 m |
| Krypteringsknap | Ja |
| Plug and play | Ja |
| Strømstyring | |
| Strømforbrug (typisk) | 4 W |
| Strømforbrug (standby) | 0,84 W |
| Design | |
| Produktfarve | Hvid |
| Antenne type | Intern |
| LED-indikatorer | LAN, Strøm |
| Certificering | CE, RoHS |
| Systemkrav | |
| Understøttede Windows-operativsystemer | Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP |
| Understøttede Linux-operativsystemer | Ja |
| Mac kompabilitet | Ja |
| Understøttede Mac-operativsystemer | Ja |
| Driftsbetingelser | |
| Driftstemperatur (T-T) | 0 - 40 °C |
| Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
| Vægt & størrelser | |
| Bredde | 58 mm |
| Dybde | 42 mm |
| Højde | 95 mm |
| Godkendelser | |
| Compliance-certifikater | RoHS |
| Emballeringsdata | |
| Pakketype | Kasse |
| Emballage indhold | |
| Antal pr. pakke | 2 stk |
| Hurtig installationsvejledning | Ja |
| Brugervejledning | Ja |
| Kabler inkluderet | LAN (RJ-45) |
| Logistik data | |
| Harmoniseret systemkode (HS) | 85171800 |
