AV1300 Powerline Kit
Bring Your Network Into New Era
AV1300 3-Port
Gigabit Passthrough
Powerline Starter Kit
Upgraded 1300Mbps!
Perfect for Bandwidth Demanding Activities
Advanced HomePlug AV2 technology means the TL-PA8033P KIT supports 2x2 MIMO* with
beamforming, so users benefit from ultra-fast data transfer speeds of up to 1300Mbps. Perfect for bandwidth demanding activities like streaming Ultra HD video to multiple devices simultaneously, online gaming and large file transfers.
*The MIMO functionality within HomePlug AV2 significantly improves
data transfer rates especially during peak periods.
Line-Neutral/Line-Ground
with Beamforming
- Larger Range
MIMO Technology with Beamforming maximizes the performance on the independent streams, which improves coverage throughout the home, particularly for previously hard to reach outlets.
- Higher Transmission Capacity & More Stable Connections
MIMO Technology means the TL-PA8033P KIT can use the 3 wires, including the live, neutral and earth to create multiple data paths, meaning that you benefit from faster data throughput and more stable connections.
3 Gigabit Ports
for Maximum Connectivity
With 3 gigabit Ethernet ports, TL-PA8033P KIT can simultaneously connect up to 3 wired-only devices. This makes the TL-PA8033P KIT the perfect home entertainment companion. Connect any 3 devices from smart TVs and game consoles to NAS boxes and computers to the Internet at the same time. Just plug the Ethernet cable into the powerline and away you go!
Plug and Play,
No Configuration Required
Connect a powerline adapter to the router; plug another powerline adapter into a wall socket in another room, and connect it to your Internet enabled device via Ethernet - and you’re done!
Pair for more security
Get more security for your network with the simple paring process
Extra Power Socket for Additional Devices
The integrated power socket, with power output of up to 13A*, means the powerline can be used like a traditional electrical socket. Simply plug in your device or extension lead as though it were a normal wall socket. The built-in noise filter also helps to prevent electrical signal noise from affecting Powerline performance.
Power Save by
Up to 85%
TL-PA8033P KIT is a new-generation of Powerline adapter. Its sophisticated Power-Saving mode automatically switches from its regular “Working” mode to “Power-Saving” mode reducing energy consumption by up to 85%.
Præstation | |
Maksimal dataoverførselshastighed | 1300 Mbit/s |
Ethernet LAN | Ja |
Wi-Fi | Ingen |
Netværksstandarder | IEEE 1901, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
Indbygget stikkontakt | Ja |
Ethernet LAN-grænsefladetype | Gigabit Ethernet |
Modulation | OFDM |
Maksimal driftstilstand | 300 m |
Krypteringsknap | Ja |
MIMO | Ja |
MIMO type | Multi User MIMO |
Plug and play | Ja |
Strømstyring | |
Strømforbrug (typisk) | 5,32 W |
Strømforbrug (standby) | 1,36 W |
Strøm | 16 A |
Design | |
Produktfarve | Hvid |
LED-indikatorer | LAN, PLC, Strøm |
Systemkrav | |
Understøttede Windows-operativsystemer | Windows 2000, Windows XP |
Understøttede Linux-operativsystemer | Ja |
Mac kompabilitet | Ja |
Understøttede Mac-operativsystemer | Ja |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 40 °C |
Opbevaringstemperatur (T-T) | -40 - 70 °C |
Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
Relativ luftfugtighed ved opbevaring (H-H) | 5 - 90% |
Vægt & størrelser | |
Bredde | 131 mm |
Dybde | 72 mm |
Højde | 42 mm |
Tekniske detaljer | |
Bæredygtighedscertifikater | RoHS |
Logistik data | |
Harmoniseret systemkode (HS) | 85171800 |
