iWARP/RDMA
iWARP delivers converged, low-latency fabric services to data centers through Remote Direct Memory Access (RDMA) over Ethernet. The key iWARP components that deliver low-latency are Kernel Bypass, Direct Data Placement, and Transport Acceleration.
Intel® Data Direct I/O Technology
Intel® Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel® Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.
PCI-SIG* SR-IOV Capable
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.
Flexible Port Partitioning
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.
Virtual Machine Device Queues (VMDq)
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance -
Porte & Grænseflader Forbindelsesteknologi Ledningsført Værtsgrænseflade PCI Express Grænseflade Ethernet Ethernet LAN-porte (RJ-45) 2 PCI version 3.0 PCI-kort formfaktor Halvhøjde (lavprofil) Netværk Maksimal dataoverførselshastighed 10000 Mbit/s Netværksstandarder IEEE 802.1Q, IEEE 802.1as, IEEE 802.1p, IEEE 802.3, IEEE 802.3ad Ethernet LAN Ja Ethernet-grænsefladetype 5 Gigabit Ethernet, 10 Gigabit Ethernet, Hurtigt ethernet, Gigabit Ethernet Ethernet LAN-datahastigheder 100,1000,2500,5000,10000 Mbit/s Kabelteknologi 10GBase-T VLAN mærkning Ja iSCSI-understøttelse Ja Maksimal driftstilstand 100 m LAN Kontroller Intel® X550 Design Intern Ja Produktfarve Grøn, Sølv Systemkrav Kompatible operativsystemer https://www.intel.com/content/www/us/en/support/articles/000025890/network-and-i-o/ethernet-products.html Understøttede Windows-operativsystemer Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64 Understøttede Linux-operativsystemer Red Hat Enterprise Linux WS 5.0, Red Hat Enterprise Linux WS 6.0, SUSE Linux Enterprise Desktop 10, SUSE Linux Enterprise Desktop 11 Understøttede operativsystemer til servere Windows Server 2003, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012 R2, Windows Server 2012 R2 x64 Driftsbetingelser Driftstemperatur (T-T) 0 - 55 °C Opbevaringstemperatur (T-T) -40 - 70 °C Relativ luftfugtighed ved opbevaring (H-H) 0 - 90% Logistik data Harmoniseret systemkode (HS) 85176990 Andre funktioner Dataoverførselshastighed 8 GT/s Kabeltype RJ45 Category 6 up to 55m; Category 6A up to 100m Markedssegment Server Antal VLAN'er 4096 Intel® Virtual Machine Device Queues (VMDq) Ja PCI-SIG* SR-IOV kompetent Ja On-chip QoS og trafik administration Ja Intel® Fleksibel Port-deling Ja Speed & slot width 8.0 GT/s, x4 Lane Muligheder med lav halogen tilgængelig Ingen Intelligent Offloads Ja iWARP/RDMA Ingen Fiberkanal over ethernet Ja Intel® Data Direct I/O Teknologi Ja Intel® Virtualization Technology for Connectivity (VT-c) Ja Grænsefladetype PCIe v3.0 (8.0 GT/s) Konfliktfri Ja Produkttype Network Interface Card Desktop Management Interface (DMI) version 2.0 Processorserie 500 Network Adapters (up to 10GbE)-500 Network Adapters (up to 10GbE) Ethernet adapter ARK ID 88209 Eksportkontrolklassisfikationsnummer (ECCN) 5A992C Automatiseret sporingssystem til vareklassificering (CCATS) G135872 Controller type Intel® Ethernet Controller X550 Beslagshøjde Low-Profile (LP) / Full-Height (FH) Opbevaring over ethernet iSCSI, FCoE, NFS Lanceringsdato Q1'16 Netværkskort kabel medium Copper Netværkskorttype Server Produktbeskrivelse URL http://www.intel.com/content/www/us/en/ethernet-products/converged-network-adapters/ethernet-x550-brief.html Status Launched Sidste ændring 64826838 Produktfamilie Intel 10 Gigabit server adapter Produktserie 500 Series Network Adapters (up to 10GbE)
