iWARP/RDMA
iWARP delivers converged, low-latency fabric services to data centers through Remote Direct Memory Access (RDMA) over Ethernet. The key iWARP components that deliver low-latency are Kernel Bypass, Direct Data Placement, and Transport Acceleration.
PCI-SIG* SR-IOV Capable
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.
Intel® Ethernet Power Management
Intel® Ethernet Power Management Technology provides solutions to common power management approaches by reducing idle power, reducing capacity and power as a function of demand, operating at maximum energy efficiency whenever possible, and enabling functionality only when needed.
Flexible Port Partitioning
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.
Virtual Machine Device Queues (VMDq)
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance -
Porte & Grænseflader Forbindelsesteknologi Ledningsført Værtsgrænseflade PCI Express Grænseflade Ethernet Ethernet LAN-porte (RJ-45) 4 PCI version 2.1 PCI-kort formfaktor Fuld højde (lav profil) Netværk Maksimal dataoverførselshastighed 1000 Mbit/s Netværksstandarder IEEE 802.1Q, IEEE 802.1as, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z Ethernet-grænsefladetype Hurtigt ethernet, Gigabit Ethernet Ethernet LAN-datahastigheder 10,100,1000 Mbit/s Kabelteknologi 10/100/1000BaseT(X) VLAN mærkning Ja iSCSI-understøttelse Ja Maksimal driftstilstand 100 m LAN Kontroller Intel® I350 Design Intern Ja Produktfarve Grøn Systemkrav Kompatible operativsystemer https://www.intel.com/content/www/us/en/support/articles/000025890/network-and-i-o/ethernet-products.html Understøttede Linux-operativsystemer Ja Understøttede operativsystemer til servere Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2012 R2, Windows Server 2012 R2 x64 Logistik data Harmoniseret systemkode (HS) 85176990 Andre funktioner Dataoverførselshastighed 5 GT/s Kabeltype Cat 5 up to 100m Markedssegment Server Antal VLAN'er 4096 Intel® Virtual Machine Device Queues (VMDq) Ja PCI-SIG* SR-IOV kompetent Ja On-chip QoS og trafik administration Ja Intel® Fleksibel Port-deling Ja Speed & slot width 5.0 GT/s, x4 Lane Muligheder med lav halogen tilgængelig Ingen Intelligent Offloads Ja iWARP/RDMA Ingen Intel® Ethernet Power Administration Ja Intel® Virtualization Technology for Connectivity (VT-c) Ja Grænsefladetype PCIe v2.1 (5.0 GT/s) Produkttype Network Interface Card Thermal Design Power (TDP) 5 W Processorserie Gigabit Ethernet Adapters (up to 2.5GbE)-Gigabit Ethernet Adapters (up to 2.5GbE) Ethernet adapter ARK ID 84805 Eksportkontrolklassisfikationsnummer (ECCN) 5A991 Automatiseret sporingssystem til vareklassificering (CCATS) NA Controller type Intel I350 Beslagshøjde Low-Profile (LP) / Full-Height (FH) Opbevaring over ethernet iSCSI, NFS Lanceringsdato Q3'14 Netværkskort kabel medium Copper Netværkskorttype Server Produktbeskrivelse URL http://www.intel.com/content/www/us/en/ethernet-controllers/ethernet-i350-server-adapter-brief.html?wapkw=i350 Status Launched Sidste ændring 63903513 Produktfamilie Intel Gigabit server adapter Produktserie Intel® I350 Produktkode navn Powerville
