Intel® Ethernet Power Management
Intel® Ethernet Power Management Technology provides solutions to common power management approaches by reducing idle power, reducing capacity and power as a function of demand, operating at maximum energy efficiency whenever possible, and enabling functionality only when needed.
Flexible Port Partitioning
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.
Virtual Machine Device Queues (VMDq)
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance
PCI-SIG SR-IOV Capable
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices. -
Porte & Grænseflader Forbindelsesteknologi Ledningsført Værtsgrænseflade PCI Express Grænseflade Ethernet Ethernet LAN-porte (RJ-45) 2 PCI version 2.1 PCI-kort formfaktor Fuld højde (lav profil) Netværk Maksimal dataoverførselshastighed 1000 Mbit/s Netværksstandarder IEEE 802.3, IEEE 802.3u Ethernet LAN Ja Ethernet LAN-datahastigheder 10,100,1000 Mbit/s Fibertilstandsstruktur Multitilstand Maksimal driftstilstand 550 m LAN Kontroller Intel® I350 Design Intern Ja Produktfarve Grøn Systemkrav Kompatible operativsystemer Windows Server 2016, Windows Server 2012 R2, Windows Server 2012, Windows 10, Windows 8, Windows Server 2008 R2, Windows 7, Windows Server 2008, Windows Vista, Windows Server 2003 R2, Windows Server 2003, Windows XP Professional, Linux Stable Kernel version 3.x, 2.6,x, Red Hat Enterprise Linux 5, 6, SUSE Linux Enterprise Server 10, 11, FreeBSD 9, VMware ESX/ESXi Logistik data Harmoniseret systemkode (HS) 85176990 Andre funktioner Kabeltype MMF 50um up to 550m; MMF 62.5um up to 275m Markedssegment Server Netværksfunktioner Gigabit Ethernet Intel® Virtualization Teknologi (Intel® VT) VT-c Termisk effekt 5,5 W Intel® Virtual Machine Device Queues (VMDq) Ja PCI-SIG* SR-IOV kompetent Ja On-chip QoS og trafik administration Ja Intel® Fleksibel Port-deling Ja Speed & slot width 5.0 GT/s, x4 Lane Muligheder med lav halogen tilgængelig Ingen Intelligent Offloads Ja iWARP/RDMA Ingen Fiberkanal over ethernet Ingen Intel® Ethernet Power Administration Ja Intel® Virtualization Technology for Connectivity (VT-c) Ja Grænsefladetype PCIe v2.1 (5.0 GT/s) Produkttype Network Interface Card Thermal Design Power (TDP) 5,5 W Processorserie Gigabit Ethernet Adapters (up to 2.5GbE)-Gigabit Ethernet Adapters (up to 2.5GbE) Ethernet adapter ARK ID 59064 Eksportkontrolklassisfikationsnummer (ECCN) 5A991 Automatiseret sporingssystem til vareklassificering (CCATS) NA Controller type Intel I350 Beslagshøjde Low-Profile (LP) / Full-Height (FH) Opbevaring over ethernet iSCSI, NFS Lanceringsdato Q4'11 Netværkskort kabel medium Fiber Netværkskorttype Server Produktbeskrivelse URL http://www.intel.com/content/www/us/en/ethernet-controllers/ethernet-i350-server-adapter-brief.html Status Launched Sidste ændring 63903513 Produktfamilie Intel Gigabit server adapter Produktserie Intel® I350
