iWARP/RDMA
iWARP delivers converged, low-latency fabric services to data centers through Remote Direct Memory Access (RDMA) over Ethernet. The key iWARP components that deliver low-latency are Kernel Bypass, Direct Data Placement, and Transport Acceleration.
Intel® Data Direct I/O Technology
Intel® Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel® Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.
PCI-SIG* SR-IOV Capable
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.
Flexible Port Partitioning
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.
Virtual Machine Device Queues (VMDq)
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance
Porte & Grænseflader | |
Forbindelsesteknologi | Ledningsført |
Værtsgrænseflade | PCI Express |
Grænseflade | Fiber |
Fiberkanal porte | 2 |
Fiber optisk strømstik | SFP28 |
PCI version | 4.0 |
Netværk | |
Netværksstandarder | IEEE 1588, IEEE 1588v2, IEEE 802.1p |
Ethernet-grænsefladetype | 10 Gigabit Ethernet, 25 Gigabit Ethernet, Gigabit Ethernet |
Ethernet LAN-datahastigheder | 1000,10000,25000 Mbit/s |
Servicekvalitet support (QoS) | Ja |
Design | |
Intern | Ja |
Komponent til | Server |
Produktfarve | Sort, Grøn, Sølv |
LED-indikatorer | Aktivitet, Link |
Certificering | FCC B, UL, CE, VCCI, BSMI, RCM, KCC |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 55 °C |
Opbevaringstemperatur (T-T) | -40 - 70 °C |
Vægt & størrelser | |
Bredde | 167 mm |
Dybde | 68 mm |
Andre funktioner | |
Intel® Virtual Machine Device Queues (VMDq) | Ja |
PCI-SIG* SR-IOV kompetent | Ja |
On-chip QoS og trafik administration | Ja |
Intel® Fleksibel Port-deling | Ja |
Intelligent Offloads | Ja |
iWARP/RDMA | Ja |
Intel® Data Direct I/O Teknologi | Ja |
Ethernet adapter ARK ID | 189760 |
Opbevaring over ethernet | iSCSI, NFS |
Lanceringsdato | Q3'20 |
Status | Launched |
