When scalability meets performance
The Synology SA3610 and SA3410 are designed for on-demand scalability and offer up to 1.7 PB of storage when fully expanded.1 They let enterprise data centers, studios, and growing businesses store large data volumes without sacrificing speed and performance.
Flexibly expand storage capacity
Scale up your SA3610 and SA3410 flexibly to meet growing data demands whenever needed. Increase your storage capacity by adding up to seven 12-bay RX1222sas expansion units as your deployment grows.
Networking capabilities
Built-in dual 10GbE RJ-45 ports allow for high-speed network transmission right out of the box. Users can also boost network redundancy and bandwidth by adding optional 10/25/40GbE and Fibre Channel adapter cards into the two available PCIe 3.0 expansion slots.3
Reliable and dependable
Protect your data and leverage hardware and software safeguards to ensure data and service availability in the face of disasters or malicious attacks.
Versatile data storage
Consolidate business data, backup data, and more in a highly scalable server.
- File server
- Backup repository
- Business application platform
File server
Utilize SA3610 and SA3410’s storage capacity and flexible expansion capabilities to host large amounts of data on a central repository.
Share and sync files with an all-in-one private cloud solution
Empower employees across your organization to access, edit, and share corporate files securely and conveniently from desktop, mobile, or web browser platforms. Leverage powerful admin tools to track and set file permissions and control access to documents and files.
Enforce company policies with Windows AD and SMB/NFS
Configure and implement group policies for groups of users using access control lists (ACL) through Windows Active Directory/LDAP integration. Enable user access to files or folders via SMB or NFS protocols.
Sync files across business sites
Synology Drive ShareSync enables one or two-way syncing between multiple Synology servers so that all team members can access the same set of data on their nearest file server.
Reduce storage footprint
Cut bandwidth use, boost sync speeds, and reduce storage footprint by intelligently syncing the bulk of your data to the cloud with Hybrid Share,6 while deploying Synology devices locally to give teams fast access to all their frequently used data at local network speeds.
Backup repository
Back up PCs, servers, Synology systems, SaaS data, and VMs, and back up your backup servers themselves with a scalable central storage solution.
Bare-metal PC, server, and VM backup
Securely back up Windows clients and servers, Linux endpoints, Synology systems, and VMware® and Hyper-V® virtual machines to the SA3610 and SA3410 with Active Backup for Business. Manage all tasks through a centralized management console and choose between bare-metal or file-level restoration. Built-in data deduplication maximizes storage efficiency.
Protect company SaaS accounts
Protect Microsoft 365 and Google Workspace accounts by maintaining complete offline copies of your crucial information and configurations with Active Backup for Microsoft 365 and Active Backup for Google Workspace.
Flexible off-site backup for shares and LUNs
Use Hyper Backup to back up shared folders, LUNs, system settings, and software packages from your Synology system to a secondary server, external device, or Synology C2 Storage. Set up backup schedules, multi-versioning, and flexible backup rotation, protect data with fine-grained permissions and encryption, and reduce backup sizes with built-in deduplication.
Snapshot Replication enables configurable point-in-time snapshots of shared folders and LUNs with an RPO as low as 5 minutes and recovery within seconds.
Bare-metal backup for Synology systems
Perform bare-metal backups and use multi-versioning and data deduplication to store backup copies of Synology systems, while drastically reducing the amount of space needed to store mission-critical data.
Business application platform
Boost team efficiency by utilizing Synology productivity solutions to work and communicate across teams or test out new software in company-hosted containers or virtual machines.
Collaborative tools for team productivity
Create, edit, and share documents, slides, and spreadsheets with teams in real time. Store files in a secure private cloud to take ownership of your data.
Send and receive emails on Synology’s private email server using powerful webmail tools and experience full data ownership, transparent total cost of ownership, and robust security features.
Stay connected with team members by using secure one-on-one chats, public channels, encrypted private channels, and group conversations for efficient workplace communication.
Test out applications in a contained environment
Safely test out new packages, software, and applications in an isolated environment using Docker and Synology Virtual Machine Manager7 (VMM) — a hypervisor for Windows®, Linux®, and Virtual DSM.
Centralized monitoring and management
Monitor and manage your Synology fleet from a central interface, on-prem or in the cloud.
Central Management System (CMS)
Manage Synology servers from a central console using group policies, task delegation, batch updates, and more.
Active Insight
Monitor your global Synology fleet’s performance, backup status, login activity and more with the power of the cloud. -
Lagring Datalagringsdriver installeret Ja Total installeret opbevaringskapacitet 144 TB Antal understøttede lagerdiske 12 Installeret lagerdisktype HDD Understøttet datalagringsdrev typer HDD & SSD Understøtter RAID Ja Understøttede lagerdrev brugerflader SATA, Serial Attached SCSI (SAS) Understøttede lagerdisk størrelser 2.5,3.5" RAID-niveauer 0, 1, 5, 6, 10, F1, JBOD Online RAID-migrering Ja Online RAID-udvidelse Ja Hot-swap drevbåse Ja Understøttede filsystemer BTRFS, Fedt, HFS+, NTFS, exFAT, ext3, ext4 Processor Processorserie Intel® Xeon® Processorproducent Intel Processormodel D-1567 Processorfrekvens 2,1 GHz Processor boost frekvens 2,7 GHz Processorkerner 12 Processortråde 24 Processor-cache 18 MB CPU-konfiguration (maks.) 1 Antal understøttede processorer 1 Konfliktfri processor Ja Hukommelse Intern hukommelse 16 GB Intern hukommelsestype DDR4 Maksimal understøttede RAM 128 GB Hukommelsesstik 4 Hukommelse form faktor RDIMM Fejlkorrigerende kode Ja Netværk Ethernet LAN Ja Ethernet LAN-datahastigheder 10,100,1000,10000 Mbit/s Ethernet LAN datahastighed understøttet (maks.) 10000 Mbit/s Kobber ethernet kabelteknologi 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T iSCSI-understøttelse Ja Wake-on-LAN klar Ja Understøttede netværksprotokoller SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV Link aggregering Ja Porte & Grænseflader Ethernet LAN-porte (RJ-45) 7 USB-port Ja Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte 2 Antal serielle porte 1 PCI Ekspres x8 (Gen 3.x) slots 2 Design Kabinettype Stativ (2U) Kølingstype Aktiv Produktfarve Sort, Grå Antal blæsere 4 blæser(e) Ventilator diameter 8 cm LED-indikatorer Alarm, Strøm, Status Indbygget skærm Ingen Indbyggede højttaler(e) Ingen Præstation Type NAS Enhedsklasse Små & mellemstore virksomheder Backup funktion Ja Backup detaljer Cloud, iSCSI LUN Lydalarm Ja Flersproget support Ja Antal brugere 16000 bruger(e) Støjniveau 49,8 dB Indbygget kortlæser Ingen Snapshot Ja Administrationsprotokoller SNMP Sikkerhedsalgoritmer AES, SSH, SSL/TLS Adgangskontrolliste (ACL) Ja Knap til nulstilling Ja Tænd-/slukkontakt Ja Indbygget UPnP™ AV -medieserver Ja Indbygget FTP-server Ja Understøttet browser Google Chrome, Firefox, Microsoft Edge, Safari System logfil Ja Varm reservedel Ja Filmappe SMB/AFP/FTP Software Operativsystem installeret DiskStation Manager Strømstyring Placering af strømforsyning Indbygget Strømforsyningens kapacitet (PCU) 550 W Antal strømforsyninger 1 Redundant strømforsyning Ja Strømforbrug (typisk) 137,54 W Strømforbrug (HDD standby) 58,23 W Vekselstrømsindgangsspænding 100 - 240 V Vekselstrømsindgangsfrekvens 50/60 Hz Vægt & størrelser Bredde 482 mm Dybde 724 mm Højde 88 mm Emballage indhold Kabler inkluderet Vekselstrøm Antal strømkabler 2 Processor særlige funktioner Indlejret tilgængelige muligheder Ja Enhanced Intel SpeedStep Teknologi Ja Udfør deaktivering af bit Ja Idle status Ja Intel® 64 Ja Intel® Enhanced Halt State Ja Intel® Secure Key Technology version 1,00 Intel® Trusted Execution Teknologi Ja Intel® TSX-NI Ja Intel® TSX-NI-version 1,00 Intel® Virtualization Technology (VT-x) Ja Intel® Virtualization Technology for Directed I/O (VT-d) Ja Intel® VT-x with Extended Page Tables (EPT) Ja Bæredygtighed Bæredygtighedscertifikater UL ECOLOGO Overholdelse af bæredygtighed Ja Driftsbetingelser Driftstemperatur (T-T) 0 - 35 °C Relativ luftfugtighed ved drift (H-H) 5 - 95% Opbevaringstemperatur (T-T) -20 - 60 °C Relativ luftfugtighed ved opbevaring (H-H) 5 - 95% Andre funktioner Compliance-certifikater BSMI, CCC, CE, EAC, Federal Communications Commission (FCC), KC, RoHS, UKCA, VCCI
