QVP-41C
4-bay high-performance NVR for SMBs and SOHO
The QVP-41C QVR Pro appliance is a tower-based network surveillance server with an Intel® Celeron® quad-core processor that supports eight free IP camera channels and up to twenty-four IP camera channels. Offering an economic and high-performance software and hardware integrated video surveillance solution, the QVP-41C fulfills requirements for secure, reliable, and centrally-managed video surveillance storage for small businesses and offices.
QVP-41C vs. other NAS-based surveillance systems. What’s the difference?
In a conventional NAS-based surveillance system, surveillance is just one of many applications available to users. As all these applications need to share NAS system resources and storage space, surveillance performance could be impacted. The QVP-41C QVR Pro Appliance overcomes this by providing dedicated storage space and reserving full system resources for surveillance, delivering the utmost performance to fulfill professional surveillance system requirements. The QVP-41C also comes with built-in camera channel licenses and essential applications to enable local installation without requiring an internet connection. Simply install the hard drives and power up the QVP-41C to start the installation process.
| Lagring | |
| Datalagringsdriver installeret | Ingen |
| Total installeret opbevaringskapacitet | 0 TB |
| Antal installerede lagerdiske | 0 |
| Antal understøttede lagerdiske | 4 |
| Installeret lagerdisktype | Ingen |
| Understøttet datalagringsdrev typer | HDD & SSD |
| Understøtter RAID | Ja |
| Understøttede lagerdrev brugerflader | M.2, Serial ATA II, Serial ATA III |
| Understøttede lagerdisk størrelser | 2.5,3.5" |
| Antal M.2 (M & B) porte | 2 |
| RAID-niveauer | 1, 5, 6, 10, JBOD |
| Online RAID-migrering | Ja |
| Online RAID-udvidelse | Ja |
| Hot-swap drevbåse | Ja |
| Understøttede filsystemer | ext4 |
| Processor | |
| Processorserie | Intel® Celeron® |
| Processorproducent | Intel |
| Processormodel | J6412 |
| Processorfrekvens | 2,6 GHz |
| Processorkerner | 4 |
| Processortråde | 4 |
| Hukommelse | |
| Intern hukommelse | 8 GB |
| Intern hukommelsestype | DDR4 |
| Maksimal understøttede RAM | 16 GB |
| Hukommelsesstik | 2 |
| Hukommelse form faktor | SO-DIMM |
| Netværk | |
| Ethernet LAN | Ja |
| Ethernet LAN-datahastigheder | 1000 Mbit/s |
| DHCP-server | Ja |
| Wake-on-LAN klar | Ja |
| Understøttede netværksprotokoller | HTTP, HTTPS, TCP/IP, UDP, DHCP, Static IP, DNS, DDNS, UPnP, FTP, NTP, and SMTP |
| Porte & Grænseflader | |
| Ethernet LAN-porte (RJ-45) | 2 |
| USB-port | Ja |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 1 |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte | 2 |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) type-C-porte | 2 |
| Antal HDMI-porte | 1 |
| HDMI-version | 2.0 |
| Lyd in/out | Ja |
| PCU Ekspres x4 (Gen 3.x) slots | 1 |
| Design | |
| Kabinettype | Tower |
| Kølingstype | Aktiv |
| Produktfarve | Sort |
| Antal blæsere | 3 blæser(e) |
| Ventilator diameter | 12 cm |
| Blæser 2, diameter | 6 cm |
| LED-indikatorer | HDD, LAN, Status, USB |
| Indbygget skærm | Ja |
| Skærmtype | LCD |
| Indbyggede højttaler(e) | Ja |
| Antal indbyggede højttalere | 1 |
| Præstation | |
| Type | NAS |
| Enhedsklasse | Små & mellemstore virksomheder |
| Backup funktion | Ja |
| Backup detaljer | Cloud |
| Lydalarm | Ja |
| Støjniveau | 16,9 dB |
| Webbaseret administration | Ja |
| Sikkerhedsalgoritmer | HTTPS, SSH |
| Knap til nulstilling | Ja |
| Tænd-/slukkontakt | Ja |
| System logfil | Ja |
| Varm reservedel | Ja |
| Understøtter S.M.A.R.T. | Ja |
| USB kopifunktion | Ja |
| Strømstyring | |
| Placering af strømforsyning | Indbygget |
| Strømforsyningens kapacitet (PCU) | 90 W |
| Antal strømforsyninger | 1 |
| Strømforbrug (typisk) | 35,79 W |
| Strømforbrug (dvale) | 28,974 W |
| Vekselstrømsindgangsspænding | 100-240 V |
| Vægt & størrelser | |
| Bredde | 160,2 mm |
| Dybde | 220,5 mm |
| Højde | 168,5 mm |
| Vægt | 2,21 kg |
| Pakkevægt | 3,61 kg |
| Emballage indhold | |
| Kabler inkluderet | Vekselstrøm, LAN (RJ-45) |
| Antal strømkabler | 1 |
| Antal skruer | 28 |
| Driftsbetingelser | |
| Driftstemperatur (T-T) | 0 - 40 °C |
| Relativ luftfugtighed ved drift (H-H) | 5 - 95% |
