Exclusive RCM functionalities
Supports exclusively integrated RCM APIs with various functions, such as OCR, for system integrators
Supports RCMMS for customizable Panel Array for operators to monitor all machines simultaneously
Supports ATEN Access Control Box for on-site enabling / disabling of remote control privilege*
OSD title bar notification – instantly notifies users upon urgent events*
Local console priority – gives the local console the priority over remote consoles to access the connected server*
Supports RS-232 and USB touch panel for easy and intuitive control*Note: These exclusive RCM functions are supported when working with KVM Adapter Module – KA7174.
Hardware
Laptop USB Console (LUC) – a dedicated USB port directly connects to a laptop for easy console operation
4 separate buses for remote KVM over IP access
Two 10 / 100 / 1000 Mbps NICs for redundant LAN or two IP operation
Blade server support
Supports PS/2, USB, Sun Legacy and serial (RS-232) connectivity
Multiplatform server environments: Windows, Mac, Sun, Linux and VT100 based serial devices
Audio enabled
Dual power supply
Video resolution up to 1920 x 1200 @ 60 Hz; 24-bit color depth
Management
Integration with ATEN CCVSR Video Session Recording Software
Supports 64 user accounts and up to 32 users can be logged in at the same time for control and management
Green IT Fan – auto-fan-speed adjustment responding to temperature
Event logging and Windows-based log server
Event notification – supports notification of SMTP email, SNMP Trap, and SMS (with additional mobile devices)
Event destination – event logs will be saved to Log server, Syslog server, and USB drive
Firmware upgradeable
Out-of-Band access – modem dial-in / dial-out / dial-back support
Adapter ID – stores port information allowing administrators to relocate the servers to different ports, without having to re-configure the adapters and switches
Port share mode – allows multiple users to gain access to a server simultaneously
Supports ATEN KVM over IP console station (KA82xx series)
Power association enables the switch’s KVM ports to be associated with ATEN PDUs power outlets for remote power management
Supports IPv4, IPv6
Easy-to-Use Interface
Panel Array Mode™ – monitors all ports in a grid display (both local and remote screens)
Local console, browser-based, and AP GUIs offer a unified multi-language interface to minimize the user training time and increase productivities
Multiplatform client support (Windows, Mac OS X, Linux, and Sun)
Multi-browser support – Internet Explorer, Chrome, Firefox, Safari, Opera, and Netscape
Browser-based GUI in pure Web technology –allows administrators to perform administrative tasks without preinstalled software. (e.g. Java)
Supports web-friendly KVM-over-IP access with HTML5 WebClient viewer – users can remotely access all the connected servers and PCs without Java or browser plug-in installation
Users can launch multiple virtual remote desktop sessions to control multiple servers during the same login
Full-screen or sizable and scalable virtual remote desktop
Keyboard / mouse broadcast – keyboard and mouse signals can be duplicated across all servers simultaneously
Video syncing with the local console – local console monitor’s EDID information stored on the KVM adapter for display resolution optimization
Security
High-grade security – supports FIPS 140-2 level 1 security standards that use an embedded FIPS 140-2 certified OpenSSL cryptographic module (Certificate #1747, #2398, #2473)
Remote authentication support: RADIUS, LDAP, LDAPS, and MS Active Directory
Supports TLS 1.2 data encryption and RSA 2048-bit certificates to secure users log in from browser
Flexible encryption design allows users to choose any combination of 56-bit DES, 168-bit 3DES, 256-bit AES, 128-bit RC4, or random for independent keyboard / mouse, video, and virtual media data encryption
Support for IP / MAC filter
Configurable user and group permissions for server access and control
Automated CSR creation utility and third party CA certificate authentication
Virtual Media
Virtual media enhances data transmission performance, ideally for file transfers, OS patching, software installations and diagnostic testing
Works with USB enabled servers in operating system and BIOS level
Support USB2.0 DVD / CD drives, USB mass storage devices, PC hard drives and ISO images
Virtual Remote Desktop
Video quality such as monochrome color depth, threshold and noise settings, bandwidth increment / reduction can be adjusted for optimizing data transfer speed
Mouse DynaSync™ – automatically synchronizes the local and remote mouse movements
On-screen keyboard with multi-language support
BIOS-level access for Troubleshooting
