A true multi-talent
The IB-HUB801-TB4 supports up to two 4K displays at 60 Hz in extended or mirrored mode, a single 8K display at 30 Hz or a 5K Thunderbolt™ display at 60 Hz. When external high-speed storage is connected, you get read speeds of up to 3000 MB/s.
Powerful when it matters
When you connect the hub to your notebook, your notebook can draw up to 85 watts of charging power via the Power Delivery feature when needed. With 85 watts notebook charging power, the IB-HUB801-TB4 outperforms most comparable Thunderbolt™ 4 hubs, which usually deliver up to 60 watts in comparison.
Daisy chain is back
Thunderbolt™ 4 supports high-resolution displays and high-performance data within one port, as well as connecting your computer to multiple devices via a daisy chain of cables. This also allows the hub to be daisy-chained with a larger DockingStation such as the IB-DK8801-TB4 for even more connections.
| Porte & Grænseflader | |
| Porte, antal | 4 |
| Værtsgrænseflade | Thunderbolt 4 |
| Hub-grænseflader | Thunderbolt 4, USB 3.2 Gen 2 (3.1 Gen 2) Type-A |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte | 1 |
| Thunderbolt 4 porte antal | 3 |
| DC-in-stik | Ja |
| Funktioner | |
| Dataoverførselshastighed | 40000 Mbit/s |
| Maksimal opdateringshastighed | 60 Hz |
| Understøttede grafikopløsninger | 3840 x 2160, 7680 x 4320 |
| Produktfarve | Anthracit, Sort |
| Husmateriale | Aluminium, Plast |
| USB strømforsyning | Ja |
| USB strømforsyning op til | 85 W |
| HD-type | 8K Ultra HD |
| Kabeltype | Rundt kabel |
| Plug and play | Ja |
| Oprindelsesland | Kina |
| Strømstyring | |
| Strømforsyningstype | USB/AC |
| Strømforsyning | 100 W |
| Indgangsspænding | 100-240 V |
| Indgangsstrøm | 2 A |
| Vekselstrømsindgangsfrekvens | 50-60 Hz |
| Udgangsspænding | 20 V |
| Udgangsstrøm | 5 A |
| Systemkrav | |
| Understøttede Windows-operativsystemer | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64 |
| Understøttede Mac-operativsystemer | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Vægt & størrelser | |
| Bredde | 121 mm |
| Dybde | 72 mm |
| Højde | 22 mm |
| Vægt | 200 g |
| Emballeringsdata | |
| Antal pr. pakke | 1 stk |
| Pakkebredde | 204 mm |
| Pakkedybde | 90 mm |
| Pakkehøjde | 146 mm |
| Pakkevægt | 1,19 kg |
| Logistik data | |
| Hovedkassens bredde (udvendigt) | 460 mm |
| Hovedkassens længde (udvendigt) | 220 mm |
| Hovedkassen højde (udvendigt) | 290 mm |
| Hovedkassens bruttovægt (udvendigt) | 10,7 kg |
| Produkter pr. hovedkasse (udvendigt) | 9 stk |
| Harmoniseret systemkode (HS) | 84718000 |
