Varenummer: PD45S0FE010000200
Mere information
-
Uniquely designed using minimum internal mechanical parts and an all-metallic frame structure, PD45S is sturdy and durable. This gives our printer a tough, compact, and sleek appearance, suitable for use in a wide range of settings & applications.
The PD45S runs on Arm Cortex-A7 / 800Mhz processor, 128M memory and 128M DDR3 SDRAM. It features a sophisticated industrial print head which supports both direct thermal and thermal transfer printing modes. Honeywell’s patented dual sensor positioning technology supports a dynamic positioning function that ensures a minimum label height of 5mm and vertical position accuracy of 0.5mm. Two sets of adjustable pressure bars and double media guides ensures accurate paper feeding and help to avoid ribbon wrinkles & printing dirt.
Thanks to a very ergonomic design, the print head can be easily switched out and replaced. The front sensor that ensures accurate printing can also be easily removed to facilitate cleaning and replacement of the rubber roller. The PD45S supports multiple printer command languages such as FP/DP/IPL/ZPL/DPL, one-key installation of printer driver and easy windows configuration.
The PD45S comes with a rich selection of accessories and supports wireless network interface card, parallel interface card, labeling machine interface card, industrial GPIO and serial interface card. It also has peeling, rewinding and cutting assemblies to cope with a wide range of application scenarios. -
Printhastighed Udskrivningsteknologi Direkte termisk/termisk overførsel Farve Ingen Maksimal opløsning 203 x 203 dpi Udskrivningshastighed 250 mm/sek. Maksimal udskrivningsbredde 10,8 cm Mindste udskrivningslængde 4,8 m Papirhåndtering Båndbredde 11 cm Båndlængde 450 m Maksimal rullediameter 8 cm Medietykkelse 0.224 mm Porte & Grænseflader Forbindelsesteknologi Ledningsført Ethernet LAN Ja USB-port Ja RS-232-porte 1 Præstation Sidebeskrivelsessprog IPL, DP, Fingerprint (FP), DPL, XML, ZPL II, ZSim2 Intern hukommelse 128 MB Flashhukommelse 128 MB Indbygget processer Ja Design Produktfarve Sort Skærm LCD Indbygget skærm Ja Skærm diagonal 8,89 cm (3.5") Strømstyring Vekselstrømsindgangsspænding 100 - 240 V Vekselstrømsindgangsfrekvens 50 - 60 Hz Driftsbetingelser Relativ luftfugtighed ved drift (H-H) 20 - 85% Relativ luftfugtighed ved opbevaring (H-H) 20 - 85% Driftstemperatur (T-T) 5 - 40 °C Opbevaringstemperatur (T-T) -20 - 70 °C Vægt & størrelser Bredde 249 mm Dybde 438 mm Højde 270 mm Vægt 9,34 kg Logistik data Harmoniseret systemkode (HS) 84433210
