The DST-Mini Duo is a high performance and versatile solution for connecting laptops, tablets or smartphones to a range of interfaces including 2 HDMI displays. Featuring all critical interfaces required for a modern workstation, this Mini Docking Station uses a single USB 3.2 Type C cable to connect up to two 4K displays simultaneously*, while improving connectivity to other devices through Gigabit Ethernet and USB 3.2 / 3.1 SuperSpeed 10Gbps and 5Gbps ports.
This Laptop Docking Station enables the connection of an HDMI display to a laptop at resolutions of 8K 7680x4320 30Hz using DisplayPort Alternate Mode through the USB Type C port. It also supports video resolutions of 4K 120Hz, making it the ideal tool for high resolution video editing or game streaming. It features three USB 3.2 Gen 2 Type C and A ports providing 10Gbps high data transfer speeds as well as three 5Gbps USB Type A ports.
This Docking Station also supports Power Delivery 3.0 up to 100W for charging the connected laptop. A power supply is not included. The dock can be used with the power supply supplied with the laptop or a power supply can be purchased separately.
*Please note that Apple computers do not support MST.
| Porte & Grænseflader | |
| Forbindelsesteknologi | Ledningsført |
| Værtsgrænseflade | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| Antal USB 2.0-porte | 0 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 0 |
| Antal HDMI-porte | 2 |
| Mikrofonindgang | Ingen |
| Udgange til hovedtelefoner | 0 |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte | 5 |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) type-C-porte | 1 |
| USB strømforsyning | Ja |
| USB strømforsyning revision | 3.0 |
| USB strømforsyning op til | 100 W |
| HDMI-version | 2.1 |
| HDCP | Ja |
| HDCP-version | 2.3 |
| Netværk | |
| Ethernet LAN | Ja |
| Ethernet LAN-porte (RJ-45) | 1 |
| Ethernet LAN-datahastigheder | 10,100,1000 Mbit/s |
| Kobber ethernet kabelteknologi | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Wake-on-LAN klar | Ja |
| Præstation | |
| Produktfarve | Grå |
| Dataoverførselshastighed | 10 Gbit/sek. |
| HD-type | 8K Ultra HD |
| Maksimal digital opløsning | 7680 x 4320 pixel |
| Husmateriale | Aluminium, Plast |
| Strømstyring | |
| Strømkilde type | USB |
| Strømstik | USB Type-C |
| Strømkabellængde | 0,22 m |
| Software | |
| Understøttede Windows-operativsystemer | Ja |
| Understøttede Mac-operativsystemer | Ja |
| Understøttede Linux-operativsystemer | Ja |
| Understøttede mobile operativsystemer | Android |
| Andre understøttede operativsystemer | ChromeOS |
| Driftsbetingelser | |
| Driftstemperatur (T-T) | 0 - 40 °C |
| Opbevaringstemperatur (T-T) | -10 - 60 °C |
| Relativ luftfugtighed ved drift (H-H) | 10 - 85% |
| Vægt & størrelser | |
| Bredde | 165 mm |
| Dybde | 49 mm |
| Højde | 21,7 mm |
| Vægt | 160 g |
| Emballeringsdata | |
| Antal pr. pakke | 1 stk |
| Pakkebredde | 185 mm |
| Pakkedybde | 80 mm |
| Pakkehøjde | 25 mm |
| Pakkevægt | 200 g |
| Emballage indhold | |
| Brugervejledning | Ja |
| Tekniske detaljer | |
| Compliance-certifikater | CE, Federal Communications Commission (FCC), REACH, RoHS |
| Bæredygtighed | |
| Overholdelse af bæredygtighed | Ja |
