Ultra-High Performing
AX3600 Enterprise Wireless for
High-Density Environments
High-Density Connectivity with 4× Increased Capacity
OFDMA* and Uplink & Downlink MU-MIMO** increase network capacity by up to 4× versus Wi-Fi 5 (802.11ac) in high-density environments to connect more devices simultaneously‡. Leverage multi-user capabilities and upgrade your business like never before.
Blazing Fast Speed with 8 Spatial Streams
The Omada Wi-Fi 6 Access Point features the latest 802.11ax technologies like 1024 QAM and Long OFDM Symbol, which allows the EAP to boost overall speeds up to 3550 Mbps (2402 Mbps on a 5 GHz band and 1148 Mbps on a 2.4 GHz band)†. With 8 spatial streams, multi-user throughput is incredibly increased to drive more applications.
Omada SDN—Smarter Cloud Solution for Business Networking
Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.
Optimized Wired Performance with 2.5 GE PoE+ Port
Armed with a 2.5 Gigabit Ethernet Port, the EAP660 HD delivers exceptional multi-gigabit performance to support the insatiable demand for better and faster Wi-Fi. Compatibility with standard 802.3at PoE+ is ideal for flexible deployment.
Seamless Roaming
802.11k/v roaming switches clients automatically to the AP with the optimal signal with a seamless transition when moving.△ This allows sensitive applications like VoIP and video conferences to go uninterrupted.
Boost Network Efficiency in All Aspects
With Rich Advanced Features
Band Steering
Automatically moves dual band devices onto the wider 5GHz band for faster connections.
Load Balance
ensures large numbers of users have smooth network experiences in high-density business networks
Airtime Fairness
Increases average network throughput in heavily congested environments
Funktioner | |
2.4 GHz | Ja |
5 GHz | Ja |
6 GHz | Ingen |
Maksimal dataoverførselshastighed | 2402 Mbit/s |
Maksimal dataoverførselshastighed (2,4 GHz) | 1148 Mbit/s |
Maksimal dataoverførselshastighed (5 GHz) | 2402 Mbit/s |
Ethernet LAN-datahastigheder | 25000 Mbit/s |
Frekvensbånd | 2.4 - 5 GHz |
Netværksstandarder | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Automatisk kanalvalg | Ja |
Automatisk kanalscanning | Ja |
MIMO | Ja |
MIMO type | Multi User MIMO |
Wi-Fi-multimedie (WMM)/(WME) | Ja |
Wi-Fi-roaming | Ja |
VLAN understøttelse | Ja |
Begrænsning af hastighed | Ja |
Trådløs isolation | Ja |
Airtime Fairness (ATF) | Ja |
Servicekvalitet support (QoS) | Ja |
Sikkerhed | |
Sikkerhedsalgoritmer | WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3-Enterprise, WPA3-PSK |
Filtrering af MAC-adresser | Ja |
Service Set Identifier (SSID) funktioner | Multiple SSIDs |
Remote Authentication Dial-In User Service (RADIUS) | Ja |
Administrationsfunktioner | |
Webbaseret administration | Ja |
Syslog | Ja |
Porte & Grænseflader | |
Ethernet LAN-porte (RJ-45) | 1 |
DC-in-stik | Ja |
Strømstyring | |
Strøm over Ethernet (PoE) | Ja |
Udgangsspænding | 12 V |
Udgangsstrøm | 2 A |
Design | |
Placering | Loft |
Produktfarve | Hvid |
Antenne | |
Antenne type | Intern |
Vægt & størrelser | |
Bredde | 243 mm |
Dybde | 243 mm |
Højde | 64 mm |
Emballage indhold | |
Monteringssæt | Ja |
Driftsbetingelser | |
Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
Driftstemperatur (T-T) | 0 - 40 °C |
Opbevaringstemperatur (T-T) | -40 - 70 °C |
Relativ luftfugtighed ved opbevaring (H-H) | 5 - 90% |
Logistik data | |
Harmoniseret systemkode (HS) | 85176990 |
