Superior Wi-Fi Speeds and Performance
QCA enterprise class chipsets, dedicated high-power amplifier and professional antenna along with the latest generation 802.11ac Wave 2 MU-MIMO technology, ensure superior 1750 Mbps Wi-Fi speeds and long-range coverage over 2.4GHz and 5GHz wireless bands.
Seamless Roaming
802.11k/802.11v seamless roaming switches clients automatically to the access point with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.
Secure Guest Network with Facebook W-Fi and SMS Login
Guest Network provides secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.
Multiple PoE Options for Easy Installation
EAP245 supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE adapter. The addition of elegant appearance and simple mounting design for easy attachment to a wall or ceiling further makes deployment effortless and flexible.
Free Cloud Centralized Management
- Anytime, Anywhere
Omada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smartphone or tablet. -
Funktioner 2.4 GHz Ja 5 GHz Ja 6 GHz Ingen Maksimal dataoverførselshastighed 1750 Mbit/s Maksimal dataoverførselshastighed (2,4 GHz) 450 Mbit/s Maksimal dataoverførselshastighed (5 GHz) 1300 Mbit/s Ethernet LAN-datahastigheder 10,100,1000 Mbit/s Frekvensbånd 2.4 - 5 GHz Netværksstandarder IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af Kabelteknologi 10/100/1000Base-T(X) Automatisk kanalvalg Ja Automatisk kanalscanning Ja MIMO Ja MIMO type Multi User MIMO Wi-Fi-multimedie (WMM)/(WME) Ja VLAN understøttelse Ja Vituelle LAN funktioner SSID-based VLAN assignment Begrænsning af hastighed Ja Trådløs isolation Ja Båndstyring Ja Airtime Fairness (ATF) Ja Servicekvalitet support (QoS) Ja Stråleformning Ja Sendeeffekt (CE) 20 - 23 dBm Sendeeffekt (FCC) 24 dBm Transmissionseffekt 27 dBmW Sikkerhed Sikkerhedsalgoritmer 64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK Filtrering af MAC-adresser Ja Service Set Identifier (SSID) funktioner Multiple SSIDs Antal SSID understøttet 16 Port-baseret Network Access Control (PNAC) Ja Adgangskontrolliste (ACL) Ja Protokoller Administrationsprotokoller HTTP/HTTPS Administrationsfunktioner Webbaseret administration Ja Syslog Ja Porte & Grænseflader Ethernet LAN-porte (RJ-45) 2 Antal USB 2.0-porte 0 Strømstyring Strøm over Ethernet (PoE) Ja Power over Ethernet (PoE) -type understøttet Active PoE, Passive PoE Udgangsspænding 12 V Udgangsstrøm 1,5 A Strømforbrug (typisk) 12,7 W Design Placering Loft, Væg Produktfarve Hvid Slot til kabellås Ja Kabellåseslids type Kensington Knap til nulstilling Ja LED-indikatorer Strøm Antenne Antenne type Intern Antenneretningstype Omniretningsbestemt Antennefunktioner Integreret antenne Niveau for antennestyrke (maks.) 4 dBi Præstation Kompatible operativsystemer Microsoft Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10 Godkendelser Compliance-certifikater CE, Federal Communications Commission (FCC), RoHS Vægt & størrelser Bredde 180 mm Dybde 180 mm Højde 47,5 mm Emballeringsdata Pakkebredde 228 mm Pakkedybde 340 mm Pakkehøjde 65 mm Pakkevægt 1,18 kg Emballage indhold Antal pr. pakke 1 stk PoE-adapter inkluderet Ja Kabler inkluderet Vekselstrøm Monteringssæt Ja Hurtig start guide Ja Driftsbetingelser Relativ luftfugtighed ved drift (H-H) 10 - 90% Driftstemperatur (T-T) 0 - 40 °C Opbevaringstemperatur (T-T) -40 - 70 °C Relativ luftfugtighed ved opbevaring (H-H) 5 - 90% Logistik data Harmoniseret systemkode (HS) 85176990 Bæredygtighed Overholdelse af bæredygtighed Ja
