Varenummer: EAP235-WALL
Mere information
-
Dedicated Complete, Private Wi-Fi Network in Each Room
An EAP in each room allows guests to enjoy their own private Wi-Fi network that’s fast, delivering a strong signal, and providing corner to corner coverage.
MU-MIMO + Dual-Band: Connect Faster and More
802.11ac wave 2 MU-MIMO technology enables multiple users to access the Internet simultaneously, which largely boosts up your network speed of up to 1,200 Mbps. Capable of transmitting in both 2.4 GHz and 5 GHz wireless band, it provides greater compatibility to connect varieties of devices.
Absolute Thinnest, Inconspicuous Design
The thinnest wall plate AP available—only 15 mm—featuring a sleek, minimalist appearance. Designed to blend in with the décor of hotel rooms, hospitals, offices and school dormitories, to deliver powerful Wi-Fi without clashing with the room.
Effortless Deployment with PoE Powered
With 802.3af/802.3at Power over Ethernet supported there’s no need to install additional wiring in the building. Simply plug in existing Ethernet cables and you’re ready to go.
Quick, Simplified Installation
EAP235-Wall is easy to install, so extra cost, time, or professional knowledge are completely unnecessary.
Full Gigabit Ports to Bridge Network
Equipped with four Gigabit data ports (1 uplink + 3 downlink), one downlink port offering PoE pass-through, to connect multiple devices to your gigabit network. Wired devices like VoIP phones can be powered with no need for extra electrical cables.
Cloud Centralized Management Anytime, Anywhere
Omada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.
Easy Management with the Omada App
Follow configuration instructions on the Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet. -
Funktioner 2.4 GHz Ja 5 GHz Ja 6 GHz Ingen Maksimal dataoverførselshastighed 1167 Mbit/s Maksimal dataoverførselshastighed (2,4 GHz) 300 Mbit/s Maksimal dataoverførselshastighed (5 GHz) 867 Mbit/s Ethernet LAN-datahastigheder 10,100,1000 Mbit/s Frekvensbånd 2.4 - 5 GHz Netværksstandarder IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at Kabelteknologi 10/100/1000Base-T(X) Automatisk kanalvalg Ja Automatisk kanalscanning Ja MIMO Ja MIMO type Multi User MIMO Wi-Fi-multimedie (WMM)/(WME) Ja VLAN understøttelse Ja Vituelle LAN funktioner Port-based VLAN, VLAN-kortlægning Begrænsning af hastighed Ja Trådløs isolation Ja Båndstyring Ja Servicekvalitet support (QoS) Ja Stråleformning Ja Sendeeffekt (CE) 20 - 23 dBm Sendeeffekt (FCC) 21 dBm Sikkerhed Sikkerhedsalgoritmer 64-bit WEP, 128-bit WEP, 152-bit WEP, 802.1x RADIUS, HTTPS, SNMP, SNMPv3, SSH, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA2-Enterprise, WPA2-PSK Filtrering af MAC-adresser Ja Service Set Identifier (SSID) funktioner Multiple SSIDs Antal SSID understøttet 16 Remote Authentication Dial-In User Service (RADIUS) Ja Adgangskontrolliste (ACL) Ja Protokoller Universal Plug and Play (UPnP) Ja Administrationsfunktioner Webbaseret administration Ja Syslog Ja Porte & Grænseflader Ethernet LAN-porte (RJ-45) 4 WAN-forbindelse Ethernet (RJ-45) Strømstyring Strøm over Ethernet (PoE) Ja Power over Ethernet (PoE) -type understøttet Active PoE, Passive PoE Strømforbrug (typisk) 24,4 W Design Placering Væg Produktfarve Hvid Slot til kabellås Ja Knap til nulstilling Ja LED-indikatorer LAN, Strøm, Status, WAN, WLAN Antenne Antenne type Intern Antennefunktioner Integreret antenne Antenner, antal 2 Niveau for antennestyrke (maks.) 4 dBi Præstation Kompatible operativsystemer Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10 Godkendelser Compliance-certifikater CE, Federal Communications Commission (FCC), RoHS Vægt & størrelser Bredde 143 mm Dybde 86 mm Højde 20 mm Emballeringsdata Pakkebredde 117 mm Pakkedybde 184 mm Pakkehøjde 33 mm Pakkevægt 300 g Pakketype Kasse Emballage indhold Antal pr. pakke 1 stk Monteringssæt Ja Hurtig start guide Ja Driftsbetingelser Relativ luftfugtighed ved drift (H-H) 10 - 90% Driftstemperatur (T-T) 0 - 40 °C Opbevaringstemperatur (T-T) -40 - 70 °C Relativ luftfugtighed ved opbevaring (H-H) 5 - 90% Logistik data Harmoniseret systemkode (HS) 85176990 Bæredygtighed Overholdelse af bæredygtighed Ja
