Varenummer: DAP-E3620
Mere information
-
Wi-Fi 7 Technology
Dual-band Wi-Fi 7 (802.11be), BE3600 class (2×2 + 2×2), delivering lower latency and higher efficiency for multi-user traffic
Easy Installation
Flexible ceiling or wall mounting for SMB deployments, while PoE+ simplifies cabling and accelerates installation
Customizable Captive Portal
Per-SSID captive portal support enables branded guest access, promotions, and flexible login workflow
VLAN per SSID
Each SSID to a dedicated VLAN for traffic segmentation, enabling simple separation of networks through policy-based control
Advanced Security
Supports WPA3-Personal/WPA3-Enterprise, 802.1X, and ACL-based access control to help reduce unauthorized access
Centralized Management
Centralized management through Nuclias Unity or Nuclias hardware/software controllers (DNH-1000, DNC-5000)
Faster Wi-Fi 7 for
Better Business Experiences
Dual-band Wi-Fi 7 (802.11be, BE3600 class) built for business environments — more speed, less latency, more devices.
- 5 GHz up to 2882 Mbps + 2.4 GHz up to 688 Mbps — combined throughput for demanding workloads, video collaboration, and dense device environments.
- Multi-Link Operation (MLO) uses both bands simultaneously, cutting latency and keeping connections stable when one band is congested.
- 4096-QAM enables faster data transmission for smoother streaming, gaming, and downloads.
- Designed for offices, hospitality, retail, and SMB deployments, it provides stable, scalable wireless performance for staff, guests, and connected devices—helping improve productivity, user experience, and operational efficiency.
Flexible Deployment for Any Network Need
Deploy in the mode that fits your infrastructure. Switch between access point, wireless bridge, or hybrid coverage without additional hardware.
Access Point Mode
Standard Wi-Fi coverage for wired networks — offices, classrooms, and public hotspots.
WDS with Access Point Mode (Wireless bridging + local coverage)
Extends coverage wirelessly while broadcasting a local SSID — connects floors or buildings without new cabling.
WDS Mode (No AP Broadcasting)
Pure wireless backhaul between two wired networks — no local SSID. Ideal for linking switches, cameras, or servers across sites.
High-Speed 2.5GbE PoE+ Uplink — No Wired Bottleneck
- Full Wi-Fi 7 throughput — the 2.5GbE uplink matches wireless capacity so your wired network never limits wireless performance.
- Single cable for power and data — IEEE 802.3at PoE+ eliminates the need for a separate power adapter, simplifying installation anywhere a switch port can reach. -
Funktioner 2.4 GHz Ja 5 GHz Ja 6 GHz Ingen Maksimal dataoverførselshastighed 2882 Mbit/s Maksimal dataoverførselshastighed (2,4 GHz) 688 Mbit/s Maksimal dataoverførselshastighed (5 GHz) 2882 Mbit/s Ethernet LAN-datahastigheder 2500 Mbit/s Frekvensbånd 2.4 - 5.85 GHz Netværksstandarder IEEE 802.11be, IEEE 802.11ax, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3at MIMO Ja MIMO type Multi User MIMO Båndstyring Ja Sikkerhed Sikkerhedsalgoritmer WPA, WPA2, WPA3, 802.1x RADIUS, AES, WPA-Personal, WPA-Enterprise, WPA3-Personal, WPA3-Enterprise Filtrering af MAC-adresser Ja Service Set Identifier (SSID) funktioner SSID-udsendelse Automatisk trådløs forsendelsessystem (WDS) Ja Remote Authentication Dial-In User Service (RADIUS) Ja Administrationsfunktioner Webbaseret administration Ja Syslog Ja Porte & Grænseflader Ethernet LAN-porte (RJ-45) 1 Antal USB 2.0-porte 0 Strømstyring Strøm over Ethernet (PoE) Ja DC spændingsområde 12 V Indgangsstrøm 2.5 A Strømforbrug (maks.) 14,17 W Design Placering Loft Produktfarve Hvid Knap til nulstilling Ingen LED-indikatorer Strøm, Status, Link, Wi-Fi Antenne Antenne type Intern Antenner, antal 4 Niveau for antennestyrke (maks.) 4 dBi Vægt & størrelser Bredde 186 mm Dybde 186 mm Højde 37 mm Vægt 550 g Emballage indhold AC-adapter inkluderet Ingen Driftsbetingelser Relativ luftfugtighed ved drift (H-H) 10 - 90% Driftstemperatur (T-T) 0 - 40 °C Opbevaringstemperatur (T-T) -20 - 65 °C Relativ luftfugtighed ved opbevaring (H-H) 5 - 95%
