GIGABIT PERFORMANCE The unmanaged switch offers Gigabit speeds to minimize transfer times and greatly enhance the ability to stream high-bandwidth files to connected devices without interference. POWER WHERE YOU NEED IT With PoE+ built-in, networking devices such as network hubs, IP phones, and IP cameras can be located anywhere without the need for AC outlets. PLUG AND PLAY CONVENIENCE The Linksys unmanaged switch offers a quick and easy solution to extend your office network with plug & play installation. QUALITY OF SERVICE (QOS) TRAFFIC PRIORITIZATION QoS traffic prioritization provides the ability to give precedence to particular devices or activities to ensure mission critical data throughput is maintained regardless of network congestion. Auto-sensing ports automatically optimize speed for each connected device.
Administrationsfunktioner | |
Switch-type | Ikke administreret |
Servicekvalitet support (QoS) | Ja |
Porte & Grænseflader | |
Basis omskiftning RJ-45 Ethernet porte, antal | 24 |
Basis omskiftning RJ-45 Ethernet porttype | Gigabit Ethernet (10/100/1000) |
Gigabit Ethernet (kobber) porte, antal | 24 |
Netværk | |
Netværksstandarder | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
Kobber ethernet kabelteknologi | 1000BASE-T, 100BASE-TX, 10BASE-T |
Auto-sensing | Ja |
Dataoverførsel | |
MAC adresselabel | 8000 entries |
Switch kapacitet | 48 Gbit/sek. |
Gennnemløb | 1,488 Mpps |
Design | |
Stativ-montering | Ja |
Formfaktor | 1U |
Produktfarve | Sort |
Husmateriale | Metal |
LED-indikatorer | Aktivitet, Link, PoE, Hastighed |
Antal blæsere | 1 blæser(e) |
Certificering | FCC Class A, CE, UL, CB |
Præstation | |
Plug and play | Ja |
Strømstyring | |
Antal strømforsyninger | 1 |
Vekselstrømsindgangsspænding | 100 - 240 V |
Vekselstrømsindgangsfrekvens | 50 - 60 Hz |
Strømforbrug (typisk) | 17,65 W |
Power over Ethernet (PoE) | |
Strøm over Ethernet (PoE) | Ja |
Power over Ethernet plus (PoE+) porte, antal | 12 |
Total Power over Ethernet (PoE) | 120 W |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 50 °C |
Opbevaringstemperatur (T-T) | -40 - 70 °C |
Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
Relativ luftfugtighed ved opbevaring (H-H) | 10 - 90% |
Vægt & størrelser | |
Bredde | 440 mm |
Dybde | 200 mm |
Højde | 44 mm |
Vægt | 2,76 kg |
Emballeringsdata | |
Kabler inkluderet | Vekselstrøm |
Hurtig start guide | Ja |
Logistik data | |
Harmoniseret systemkode (HS) | 85176990 |
Andre funktioner | |
Båndbredde | 48 Gbit/sek. |
